Everon™ 6000 G2 v1.0
User Manual
Corning Optical
Communications
www.corning.com
Corning Restricted - Controlled content (R2)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Everon 6000 G2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CORNING Everon 6000 G2

Summary of Contents for CORNING Everon 6000 G2

  • Page 1 Everon™ 6000 G2 v1.0 User Manual Corning Optical Communications Corning Restricted - Controlled content (R2) www.corning.com...
  • Page 2 User Manual v1.0 Everon™ 6000 G2 v1.0 User Manual Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 2 of 114...
  • Page 3 Notwithstanding the foregoing, Corning shall have no obligation under the Software Warranty if the Software is modified or used with hardware or software not supplied or approved by Corning or if the Software is subject to abuse, improper installation or application, accident, electrical or environmental over-stress, negligence in use, storage, transportation or handling.
  • Page 4 1. Return authorization is to be received from Corning prior to returning any unit. Advise Corning of the model, serial number, and discrepancy. The unit may then be forwarded to Corning, transportation prepaid. Devices returned collect or without authorization may not be accepted.
  • Page 5 Corning shall not be liable for any other damage including, but not limited to, indirect, special or consequential damages arising out of or in connection with furnishing of goods, parts and service hereunder, or the performance, use of, or inability to use the goods, parts and service.
  • Page 6 The product shall have connection of the device protective earthing conductor to the installation protective earthing conductor (for example, by means of a power cord connected to an electrical outlet with earthing connection). Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021...
  • Page 7 1930-2020 MHz EAWS-band 66 1695-1780 MHz 2110-2200 MHz WCS-band 30 2305-2315 MHz 2350-2360 MHz 2500-band 41 2496-2690 MHz (TDD) 3500-band 77 3450-3980 MHz (TDD) Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 7 of 114...
  • Page 8 User Manual v1.0 Revision History Revision Date Created by Reviewed by Changes Sep 2022 First issue Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 8 of 114...

  • Page 9: Table Of Contents

    2.5.4 Connect the Ground and Antenna Cables ................57 2.5.5 Combiner cables ......................... 58 2.5.6 Verify normal operation ......................59 3. GUI – General Description ......................60 3.1 Screen Layout ..........................60 Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 9 of 114...
  • Page 10 5.4.1 RU -> Overview&Alarm ....................... 90 5.4.2 RU Parameter config ......................91 6. APPENDIX A: Specifications ....................93 7. APPENDIX B: LED Functionality and Colour Definition ............97 Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 10 of 114...

  • Page 11: Introduction

    Carrier-grade network management - Network configuration and management capabilities  enable on-site and remote end-to-end configuration, system diagnostics, maintenance, support management and control by network management system. Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 11 of 114...

  • Page 12: Terminology, Acronyms, And Abbreviations

    Radio Frequency SNMP Simple Network Management Protocol Transmission Control Protocol User Datagram Protocol User Equipment Uplink UTRAN Universal Terrestrial Radio Access Network User Datagram Protocol Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 12 of 114...
  • Page 13 User Manual v1.0 Table 2 Images Abbreviation Image DLRU DMRU DHRU Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 13 of 114...

  • Page 14: Everon™ 6000 G2 Architecture Overview

    1.3 Everon™ 6000 G2 Architecture Overview Figure 1 Architecture diagram Corning Everon™ 6000 G2 features a fully advanced digital system, which incorporates the RIU (Radio Interface Unit), DCU (Digital Conversion Unit), DEU (Distributed Extension Unit) and multi-type of remotes. All the devices in the system are managed via a web session to the DCU, which provides local and remote management capabilities for all connected system devices using both web GUI (HTTPs) and SNMP interfaces.
  • Page 15 Figure 7 and figure 8 shows the RIU interfaces. Table 3 lists the interfaces description. Figure 3. 2 TO 1 matrix Figure 4. 4 TO 1 matrix Figure 5. 8 TO 1 matrix Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 15 of 114...
  • Page 16 User Manual v1.0 Figure 6. RIU monitoring diagram Figure 7. RIU Interface(front view) ⑦Ground Figure 8. RIU Interface (back view) Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 16 of 114...
  • Page 17 Cascade level, displayed as “1” or “2” 1 - First cascade level LED displayer 2 - Secondary cascade level A maximum of 16 devices can be cascaded Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 17 of 114...

  • Page 18: Dcu

    Table 5. Uplink-Downlink configurations Subframe number Uplink-downlink Downlink-to-Uplink configuration Switch-point periodicity 5 ms 5 ms 5 ms 10 ms 10 ms 10 ms 5 ms Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 18 of 114...
  • Page 19 23040 T  4384 T  5120 T  21952 T  24144 T  Normal cyclic prefix in downlink Special subframe configuration DwPTS UpPTS Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 19 of 114...
  • Page 20 User Manual v1.0 Figure 10. DCU Star Connection Figure 11.DCU Daisy Connection Figure 12. DCU Interface (front view) Ground Figure 13. DCU interface (back view) Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 20 of 114...
  • Page 21 SISO/MIMO TX/RX 1~2 300MHz 1710~4000MHz, TDD/FDD SISO/MIMO TX/RX 3~4 300MHz 1710~4000MHz, TDD/FDD SISO/MIMO TX/RX 5~6 200MHz 600~2700MHz, TDD/FDD SISO/MIMO TX/RX 7~8 200MHz 600~2700MHz, TDD/FDD Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 21 of 114...

  • Page 22: Deu

    DCU modules and the remote unit, enabling to receive the operators service signals in CPRI format, and to route these signals to the remote units. The DEU supports all Corning digital remote antenna units’ styles, for all services, power levels and antenna configurations. Each DEU includes 4 F/O CPRI ports connected to the DCUs or cascaded DEUs, and 24 F/O CPRI ports for connection to the remote units.
  • Page 23 10MHz DLRU- 2500M 190MHz 19212325 Table 11. DEU Line Rate Application DEU Line Rate Remote Unit Type DLRU-G2-678/DLRU-G2-17192125/DHRU-G2-600/DHRU-G2-700/DHRU-G2-800/DHRU-G2- 10Gbps 1900/DHRU-G2-2100/DHRU-G2-2300 DLRU-G2-25/DLRU-G2-35/DMRU-G2-678/DMRU-G2-1719/ DMRU-G2-2325/DMRU-G2-25/DMRU- 25Gbps G2-35/DHRU-G2-25/DHRU-G2-35 Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 23 of 114...
  • Page 24 Note: Please check the software release note for the DEU cascading features and limitation of each software version. Figure 16 DEU interfaces Figure 17 ． DEU interface (back view) Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 24 of 114...
  • Page 25 Switch x 1 3A,50/60Hz PSU module POWER PSU Module PSU module with easy assembly installation design MODULE Two holes Connect to the ground M4 x 2 Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 25 of 114...

  • Page 26: Remote Units

    DEU and the UE (User Equipment), enabling to receive the operator service signals in CPRI format, transfer to RF signal and send to UE. Corning digital remote antenna units includes three power level types: DLRU/DMRU/DHRU. The power levels vary from 20dBm to 43dBm to meet different coverage scenarios. The...
  • Page 27 3500 TDD 25Gbps DHRU-G2-06 10Gbps DHRU-G2-07 700L/700U/FirstNet 10Gbps DHRU-G2-08 800/850MHz 10Gbps DHRU DHRU-G2-19 1900(PCS) 10Gbps DHRU-G2-21 2100(EAWS) 10Gbps DHRU-G2-23 2300(WCS) 10Gbps DHRU-G2-25 2500 TDD 10Gbps Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 27 of 114...
  • Page 28 Indicating the operation status of the Status LED indicator STAT equipment Used for grounding the chassis and the GND interface earth, single hole Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 28 of 114...
  • Page 29 LED indicator STAT The operation status of the equipment Power input port, voltage input range AC IN Power input port AC IN 100V~240V, 3A Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 29 of 114...

  • Page 30: System Topology And Gain Assignment

    The RIU high gain mode will add 30dB insert loss while switching to OFF status  The DCU high gain mode will add 12dB insert loss while switching to OFF status  Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 30 of 114...
  • Page 31 (DCU ATT set to 0~3 -7dB to 0~20, IL=7~27dB) -10~0dBm -17~-19dBm (RIU ATT set (DCU ATT set to -10~0dBm -7dBFS 24dBm -7dB +12dB to 0~12, 0~2dB, gain=10~12 IL=7~19dB) Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 31 of 114...

  • Page 32: System Installation

    DRU, see 2.5.  Remote Units Installation:  LRU, see 2.5  MRU, see 2.6.  *Note: Refer to chapter 6 for dimensions and specifications. Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 32 of 114...
  • Page 33 User Manual v1.0 Figure 24 The installation process Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 33 of 114...

  • Page 34: Head End Units - Architecture Example

    Open the package and verify that all items in the table below are available. *Notes: Refer to APPENDIX B: Ordering information for details.  See the example of package unpacking under the table.  Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 34 of 114...
  • Page 35 DC Power Adapter HARDWARE – not provided 4 screws #8 or 4mm (For attachment to rack) SOFTWARE Required TOOLS Cross Screwdriver Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 35 of 114...

  • Page 36: Mount The Riu

    1) Connect the RF cables on the chassis with M3 screws, and sort out the RF cables. Figure 27 RIU rack Installation with cables Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 36 of 114...

  • Page 37: Riu Cable Connection

     Follow these steps to install the DCU: Verify the box contents, see 2.3.1 Mount the DCU, see 2.3.2 Connect the DCU cable, see 2.3.3 Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 37 of 114...

  • Page 38: Verify Box Contents

    (Hot-pluggable optical transceiver module) Support 24.3 Gbps line rate, single mode Optical cables Up to 10km 1~14 LC/UPC SM DX SOFTWARE Required Tools Cross Screwdriver Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 38 of 114...

  • Page 39: Mount The Dcu

    Step 3: Plug in the RF cable plug (RF cable not shown in the below), as shown in Figure 31. Figure 31 DCU RF cable plug installation Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 39 of 114...

  • Page 40: Dcu Cable Connection

     To install the HEU, follow these steps: Verify the box contents, see 2.4.1  Mount the DEU, see 2.4,2  Connect the DEU cable, see 2.4.3  Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 40 of 114...

  • Page 41: Verify Box Contents

    Support for 24.3 Gbps line rate, single mode Optical cables Up to 10k meters LC/UPC SM DX SOFTWARE TOOLS Required Cross Screwdriver Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 41 of 114...

  • Page 42: Mount The Deu

    2. Mount the DEU in the rack with 4 pcs of M6 screws. Figure 33. Rack Installation- Step 2 3. Install the DEU in the rack. Figure 34 Rack Installation Step- 3 Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 42 of 114...

  • Page 43: Deu Cable Connection

    Switch x 1 100V~240V, 1.3A- (indoor) (100V-240V,50Hz/60Hz) (100V-240V,50Hz/60Hz) 0.6A,50/60Hz dLRU/dMRU/dHRU or DEU Fiber Cable Optical port Optical module Optical port DCU or DEU Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 43 of 114...

  • Page 44: Dlru Installation

    Left side brackets for dual-unit configuration Right side brackets for dual-unit configuration dLRU-2.5/3.5 Unit Hinge Combiner – for dual unit configuration RF jumper cables DC power adapter Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 44 of 114...

  • Page 45: Mount The Dlru

    Remove the rubber stopper from the SFP+ connector located in the dLRU cable port. Connect the SFP+ LC/UPC SM DX optic cable to the dLRU optic connector. Power Socket /optical ports in dLRU Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 45 of 114...
  • Page 46 1) Connect the bracket to the wall with 4 screws, as shown in the figure below: 4 screws Figure 36-4 screws 2) mount the LRU on the bracket with 4 screws. Figure 37-4 screws Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 46 of 114...
  • Page 47 Tighten the M6 bracket screws on the left and right sides of the upper part of the dLRU, and then hang the device on the mounting bracket. Lock the device on the mounting frame with M6 combination screws, as shown below Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 47 of 114...
  • Page 48 1) Assembly of right bracket and hinge The installation of the right bracket and hinge is shown in Figure 42. Figure 42 Right bracket and hinge installation Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 48 of 114...
  • Page 49 Otherwise, it is inconvenient to take waterproof measures for the connector after the device is installed. Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 49 of 114...
  • Page 50 Hang the combination of the left and right brackets with four M6 bracket screws, and then use M6×15 pentagonal combination screws to fastened the second dLRU as shown in the figure below. Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021...
  • Page 51 User Manual v1.0 Figure 47 M6 bracket screw holes Figure 48 dLRU installation diagram Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 51 of 114...
  • Page 52 M6 combination screws as shown in Figure 51. Figure 50 Diagram of pole installation for single unit Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 52 of 114...
  • Page 53 M6×15 pentagonal combination screws, as shown in the figure below. Figure 51 Installation diagram of the combiner Figure 52 Installation diagram of dLRU pole Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 53 of 114...

  • Page 54: Power+ Spf+ Cable

    Remove the rubber plug from the SFP+ connector located in the LRU RF port. Connect the SFP+ LC/UPC SM DX optical cable to the LRU optical connector. Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 54 of 114...
  • Page 55 SFP+ Cable SFP+ Pluggable Transceivers Figure 56 Remove rubber plug from the port and insert the SFP+ Pluggable Transceivers (hot-pluggable optical transceiver module) into it. Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 55 of 114...

  • Page 56: Connect The Ground And Antenna Cables

    Prepare the other end of the ground and connect it to an appropriate ground point.  Figure 57 The ground Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 56 of 114...

  • Page 57: Combiner Cables

    2.5.5 Combiner cables Connect the Antenna cables as the figure shows below. Mid-band Combiner in the Low band bracket Combiner Figure 59 Combiner in the bracket Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 57 of 114...

  • Page 58: Verify Normal Operation

    Power on or chip configuration process Green flashes (1time /second) Normal operation Green flashes (2time /second) Identify STAT Red flashes (1time /second) Over temperature alarm Hardware alarm Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 58 of 114...

  • Page 59: Gui - General Description

    The Control board (located on the right down of the window) lists the control functions. Information board Control board Navigation board Figure 62 RIU screen layout Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 59 of 114...

  • Page 60: Function Options

    After the initial configurations are done, it is recommended to establish remote access to the HCM by using the following: LAN Ethernet connection to the HCM with a minimum connectivity and throughput capability of 256 Kbps Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 60 of 114...

  • Page 61: Session Access And First-Time Settings

    When all the system elements are installed, the system administrator can login the system GUI and perform initial configurations. It is recommended to start using Corning ® Everon ™ 6000 and the specific steps are as follows: Open a local session to the DCU, see chapter 4.1.
  • Page 62 User Manual v1.0 Figure 64 Network &Internet setting b. Select Ethernet  Change adapter options Figure 65 Ethernet setting Right click Ethernet 3 and select Properties. Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 62 of 114...
  • Page 63 Select Internet Protocol Version 4（TCP/IPv4）and click Properties Figure 67 Ethernet 3 properties Type in the properties: 192.168.8.3 255.255.0.0  click OK Examples of IP addresses: Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 63 of 114...
  • Page 64 LOCAL port default IP address in the address bar: 192.168.8.3. Ping the IP address also works. See section 4.2 for instructions on how to continue. Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021...

  • Page 65: Commissioning

    Configure the DAS for each frequency during the commissioning process which requires a basic understanding of link, budgets and RF technology. Most system commissioning scenarios are covered and the process should be adjusted based on the site requirements and instructions of Corning Support. webGUI Workflow Figure 69 webGUI Workflow *Note: In order to protect the whole system, please don’t input eNodeB signal before...

  • Page 66: Riu Parameter Config

    High Gain Mode On/Off DL P_in Read only Read only RF Switch On/Off UL ATT 0-30dB DL ATT 0-30dB Figure 71 RIU RF information Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 66 of 114...

  • Page 67: Dcu Config

    Figure 73 DCU alarm info 5.2.2.1 DCU OP Info Click the left navigation button DCUOP Info, as shown in the figure: Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 67 of 114...
  • Page 68 Then click Finish to complete the setting, as shown in the following figure: Figure 75 DCU OP Info  Disable/EnableFinish/Cancel Click OP Info More to view the optical module info, as shown in the figure below: Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 68 of 114...
  • Page 69 User Manual v1.0 DCU OP Info More Figure 76 The optical port source can be select by clicking shown in the figure below: DCU Figure 77 Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 69 of 114...
  • Page 70 FDD (not used in this release) TDD-NR TDD-LTE Choose based on the RIU BTS connections TDD-NR + TDD-LTE RF Switch On/Off Figure 78 DCURF Config1 Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 70 of 114...
  • Page 71 UL/DL Slot Configuration: User-defined parameters are supported, but should be the same as the operator parameters. DCU TDD Info Figure 79 Figure 80 TDD configuration Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 71 of 114...

  • Page 72: Dcu -> Riu

    DCU. (Note: when DCU is in master mode, it can be connected to DEU; when DCU is in slave mode, it fails to connect to DEU and work independently. It can only connect to master DCU for normal use.) Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021...
  • Page 73 Two upgrade modes are supported by 5G digital DAS products of D430 series of the system software of all NE: centralized upgrade and decentralized upgrade. The settings of the two modes can be configured in Control Switch: Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 73 of 114...
  • Page 74 All the slave NE (slave DCU, DEU, DLRU) connected to this seven NE will automatically take the system software to be upgraded independently. Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021...
  • Page 75 10s. Setting to 254 indicates an immediate level alarm; Set to 0 and the alarm will not occur until 3 minutes later; DCU Function  Alarm SettingAlarm Detect Duration Figure 88 Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 75 of 114...
  • Page 76 5.2.4.6 Click Function Log to export the log of DCU for problem analysis, as shown in the figure: DCU Function  Log Figure 90 Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 76 of 114...
  • Page 77 Click Function  Site Report and the site report of DCU enables it to be recognized by NMS, as shown in the following figure: Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 77 of 114...

  • Page 78: Dcu -> Userinfo

    DCUUserPassword Figure 94 5.2.5.2 UserInfo Click User->UserInfo to add a user and set the role and password, as shown in the following figure. Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 78 of 114...
  • Page 79 As shown in figure 91, click User->LoginInfo to set the maximum value of password input attempts. This function indicates that when a user logs in, the system will be locked if the times of password input exceeds the maximum. Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 79 of 114...

  • Page 80: Program

    DCU DCUUserLoginInfo Figure 97 5.2.6 Program Click ProgramSite Management to clear the site ID of the DCU reported to OMC. Figure 98 DCU factory setting Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 80 of 114...

  • Page 81: Deu Config

    NE connected to the DEU unit. And the info query and configuration management page of other NE can be switched to after clicking NE ID in the topology. Figure 100 DEUDashboard 5.3.1.1 Alarm Info Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 81 of 114...
  • Page 82 THR (80 ℃ by default), the alarm will take effect. Digital Unlocked Alarm: when the device is unlocked, the alarm will take effect. 5.3.1.2 OP Info DEUDEUOP Info Figure 102 Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 82 of 114...

  • Page 83: Deu -> Function

    Click Function Device Info to view the time, latitude, longitude, and other information of 10G/25G device. The site info is defined by the user, as shown in the figure below: Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021...
  • Page 84 RU connected to the DEU, as shown in the figure below: DEUFunctionReset Figure 106 5.3.2.3 Export Log Click DEU->Function->Export Log to export the DEU log for problem analysis, as shown in the figure below: Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 84 of 114...
  • Page 85 DEUFunctionImport & Export Figure 108 5.3.2.5 Alarm Setting Click Function  Alarm Setting to set the DEU alarm detect duration, as shown in the figure below: Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 85 of 114...
  • Page 86 Click FunctionSite Report and The NE of DEU can be recognized only after the site report result is reported, as shown in the figure below: Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 86 of 114...

  • Page 87: Deu -> Userinfo

    Click User->Password to reset DEU password, as shown in in the figure below: DEUUserPassword Figure 112 5.3.3.2 UserInfo Click User->UserInfo to add a user to set the role and password, as shown in the figure below. Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 87 of 114...
  • Page 88 DEUUserUserInfoAdd User Figure 114 5.3.3.3 LoginInfo Click User->Login Info to set the max value of entering the password, as shown in in the figure below: Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 88 of 114...

  • Page 89: Dlru Config

    Overflow Alarm  DC Voltage Lower Alarm  Drag the scroll bar to view more information (e.g., Temperature) as shown in the figure below.  Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 89 of 114...

  • Page 90: Ru Parameter Config

    The OP Info list box displays the current optical port connection status and information reading volume of the device, as shown in the figure below: RU9OP Info Figure 118 Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 90 of 114...
  • Page 91 ON/OFF DL ATT (0~20) UL ATT (0~20) Normal Work Mode DL force uplink Normal UL force uplink Figure 119 RF info & OP info Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 91 of 114...

  • Page 92: Appendix A: Specifications

    RF Cluster 3~4: 600~2700 MHz, TDD/FDD Input Power Range -7~ +3 RF Cluster 1~2: 300 MHz Maximum Instantaneous Bandwidth RF Cluster 3~4: 200 MHz VSWR <1.8 Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 92 of 114...
  • Page 93 ≤ 85% Ingress Protection IP30 Cooling Mounting and Installation 19-in Rack mount Regulation EMC FCC 47 CFR Part 15 sub part B Safety UL62368-1 Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 93 of 114...
  • Page 94 ≤ 85% Ingress Protection IP30 Cooling Mounting and Installation 19-in Rack mount Regulation EMC FCC 47 CFR Part 15 sub part B Safety UL62368-1 Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 94 of 114...
  • Page 95 ≤ 85% Ingress Protection IP30 Cooling Mounting and Installation 19-in Rack mount Regulation EMC FCC 47 CFR Part 15 sub part B Safety UL62368-1 Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 95 of 114...

  • Page 96: Appendix B: Led Functionality And Colour Definition

    Red Flash (1Hz, 10s) 3.No alarm 1.The system is up and running Green Flash(1Hz) 2.Software or hardware failure 1.Power on Green Power 2.Power off Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 96 of 114...
  • Page 97 2 x 4.3-10 female to external antenna Dimensions (W x H x D) Inch (mm) 10.6 x 10.6 x 2.95 (270 x 270 x 75) Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 97 of 114...
  • Page 98 Cooling Convection Mounting and Installation Ceiling/Wall/Shell Regulation EMC FCC 47 CFR Part 15 sub part B Safety UL62368-1 Radio FCC CFR 47, Part 27 Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 98 of 114...
  • Page 99 VSWR ≤ 1.6 EVM (256 QAM) (TM3.1A @ Rated power) < 3.5 3GPP TS 36.106; 3GPP TS 38.104 V15.5.0 (sections Spurious Emission 6; 7) Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 99 of 114...
  • Page 100 Cooling Convection Mounting and Installation Ceiling/Wall/Shell Regulation EMC FCC 47 CFR Part 15 sub part B Safety UL62368-1 Radio FCC CFR 47, Part 27 Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 100 of 114...
  • Page 101 ≤1.5 EVM (256 QAM) (TM3.1A @ Rated power) < 3.5 3GPP TS 36.106; 3GPP TS 38.104 V15.5.0 (sections Spurious Emission 6; 7) Coupling value Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 101 of 114...
  • Page 102 Mounting and Installation Wall/19-in Rack mount Regulation EMC FCC 47 CFR Part 15 sub part B Safety UL62368-1 Radio FCC CFR 47, Part 27 Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 102 of 114...
  • Page 103 ≤1.5 EVM (256 QAM) (TM3.1A @ Rated power) < 3.5 3GPP TS 36.106; 3GPP TS 38.104 V15.5.0 Spurious Emission (sections 6; 7) Coupling value Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 103 of 114...
  • Page 104 Mounting and Installation Wall/19-in Rack mount Regulation EMC FCC 47 CFR Part 15 sub part B Safety UL62368-1 Radio FCC CFR 47, Part 27 Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 104 of 114...
  • Page 105 Weight (approx.) Lbs (kg) 13.2 (6) Powering 48V DC Power Consumption Watt Operating Temperature -10°C to +45°C (14°F to 113°F) Operating Humidity ≤ 85% Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 105 of 114...
  • Page 106 User Manual v1.0 Ingress Protection IP30 Cooling Mounting and Installation 19-in Rack mount Regulation EMC FCC 47 CFR Part 15 sub part B Safety UL62368-1 Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 106 of 114...
  • Page 107 Weight (approx.) Lbs (kg) 13.2 (6) Powering 48V DC Power Consumption Watt Operating Temperature -10°C to +45°C (14°F to 113°F) Operating Humidity ≤ 85% Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 107 of 114...
  • Page 108 User Manual v1.0 Ingress Protection IP30 Cooling Mounting and Installation 19-in Rack mount Regulation EMC FCC 47 CFR Part 15 sub part B Safety UL62368-1 Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 108 of 114...
  • Page 109 ≥50@3450-4000 ≥50@2496-2690 Maximum Input Power (Per Port, Average) -155 (@ 2x10W) Return Loss ≥18 Isolation ≥40 Port Type 4.3-10 F Impedance  Mechanical Characteristics Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 109 of 114...
  • Page 110 -40°C to +85°C (-40°F to 185°F) Ingress Protection ≤ 95% Environmental IP66 Regulation EMC FCC 47 CFR Part 15 sub part B Safety UL62368-1 Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 110 of 114...
  • Page 111 ≤ 4 Ripple (p-p) 5/10/15/20 for 4G Channel 5/10/15/20 Bandwidth 40 or 60 for 5G Uplink Noise Figure (typical) Uplink IIP3 (typical) VSWR ≤ 1.8 Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 111 of 114...
  • Page 112 OEU (Optical Expansion Unit) – Consumption connected to RFU’s (Typical) Watt RFU (RF Unit) – MIMO 2:2 for the bands 600,700,800/850, 1700. 1900, 2300, 2500TDD AC voltage 100-240 Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 112 of 114...
  • Page 113 Insertion Loss ≤0.3 Port Isolation ≥50 Return Loss ≤20 Pass band ripple ≤0.2 ≤155@2×43dBm Power Capacity Watt 250 per port Interface Connector 4.3-10 Mini DIN-Female Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 113 of 114...
  • Page 114 ≤ 0.2 ≤155@2 ×43 dBm Power Capacity Watt 250 per port Interface Connector 4.3-10 Mini DIN-Female *Technical specs are subject to change without notice. Corning Restricted - Controlled content (R2) UM_-_Everon_6000_DAS_-_22-JUNE-2021 - no comments| June 2021 |Page 114 of 114...
