- Page 1 Corning Mid-Power Remote Unit (MRU) User Manual T a bl e of Co nt en ts CMA -xxx- A E N P a ge 1...
-
Page 2: Preface Material
Hardware Corning warrants to the original purchaser (“Customer”) that for the duration of the warranty period, one (1) year, commencing on the date of shipment of the Hardware, unless otherwise agreed in writing by Corning (the “Hardware Warranty Period”), the Hardware furnished by Corning shall be free in all material respects from defects in material and workmanship, and shall conform to the applicable portions of the Specifications, as defined below (the “Hardware Warranty”). -
Page 3: Software Warranty
Warranty, Corning shall correct such defects or failure and ensure that the Software conforms with, and performs the functions set forth in, the Specifications. Customer will allow Corning to inspect the Software at Customer’s location or to return it to Corning’s’... -
Page 4: Limitations Of Liabilities
Corning shall not be liable for any other damage including, but not limited to, indirect, special or consequential damages arising out of or in connection with furnishing of goods, parts and service hereunder, or the performance, use of, or inability to use the goods, parts and service. -
Page 5: Rf Safety
• Corning ONE Wireless platform MRU has been tested and certified as a Class 1 Laser product to IEC/EN 60825-1 (2007). It also meets the requirements for a Hazard Level 1 laser product to IEC/EN 60825-2: 2004 to the same degree. -
Page 6: Table Of Contents
Preface Material ..............................2 About This Manual ..............................2 Hardware ................................2 Software Warranty ..............................3 Returns .................................. 3 Limitations of Liabilities ............................4 Reporting Defects ..............................4 Warnings and Admonishments ..........................4 Regulatory Compliance Information ........................4 RF Safety ................................5 Laser Safety ................................ - Page 7 RF Coaxial Cable Guidelines ........................18 3.5.1 General RF Cable Installation Procedures ..................18 3.5.2 RF Rules ............................18 3.5.3 Coax Cable Lengths and Losses ..................... 18 Antenna Specifications and Guidelines ....................... 20 3.6.1 Authorized Antennas and Required Specifications ................20 3.6.2 General Installation Guidelines ......................
- Page 8 Verifying Normal Operation ......................... 41 Appendix A: Specifications .......................... 42 Supported Services .............................. 42 RF Parameters ..............................42 Coupling Specifications ............................43 Environmental ..............................43 Standards and Approvals ............................. 43 Optical ................................. 43 Physical Specifications ............................44 Appendix B: Ordering Information ....................... 45 MRU Assembly Configurations ..........................
-
Page 9: Introduction
Introduction The MRU is a mid-power (2 W) remote solution for the Corning ONE™ Wireless Platform system. The MRU provides remote indoor and outdoor coverage. It is a fiber-fed, compact and scalable multi-service solution designed to complement the Corning ONE Wireless platform by providing complete RF open space coverage for large-scale public venues such as campus applications. -
Page 10: General System Specifications And Requirements
General System Specifications and Requirements 1.2.1 Environmental and Regulatory Specifications Operating Storage Temperature -40° C to +65° C (-40°F to 149°F) -30° to 85°C (-22° to 185°F) Table 1-1. Temperature and Humidity Specifications 1.2.2 Safety and Regulatory Approvals Regulation/Standard Approval Category Laser Safety FDA/CE 21 CFR 1040.10 and 1040.11 except for deviations pursuant to laser notice no. -
Page 11: System Architecture
System Architecture Figure 1-2 illustrates the MRU system architecture. In the downlink, at the headend, the BTS/BDA signal is conditioned at the headend unit (e.g. integrated headend unit IHU)), by the service specific radio interface modules (RIM), ensuring a constant RF level. -
Page 12: System Monitoring And Management
System Monitoring and Management The MRU is centrally managed via the headend control module SW management application (v1.6 and higher). Figure 1-3 shows the management tabs of the selected MRU unit. Refer to the HCM and Web Management User Manual (v1.6 and higher) for information on how to configure and manage the MRU remote unit. -
Page 13: Mru Interfaces
Power amplifier modules (PAM) – internal service specific power amplifier module that interfaces to an optical interface module (OIM) at the headend site via an SMF pair and supports one service. MRU supports up to five SISO bands. The PAM provides the additional amplification on the DL signals routed from the OIM towards the multiplexer; PAMs are pre-installed in designated slots according to supported band. - Page 14 DC models - two types of terminal block connectors: • CLASS2 (default) – two “DC In” 8-pin terminal block connectors for remote feed: one pair for each PAM ( total of five pairs) and one pair for the FAM+OPTM; one RSV pair •...
- Page 15 Steady green: All four fans are operating at normal speed (fan alarms clear) Steady red: Fault detected in at least one fan (fan alarm set) LINK Steady green: Optical link level from optical module above normal threshold Steady red:...
-
Page 16: Installation Guidelines
Installation Guidelines This chapter provides installation guidelines for the Corning ONE™ wireless platform MRU. The following installation rules are based on the assumption that the site survey and installation planning (including power requirements) have been completed. This includes planning the distribution of antennas to provide the required coverage, as well as planning the layout of the devices and cables in the telecom closet or shaft. -
Page 17: Rack Safety Instructions
Install external over-current protective devices for the system according to the power specifications described in 1.2.3. 3.4.2 Types of Power Supplies Corning supplies various power supplies that can be installed in a rack or mounted on a wall, depending on your configuration. 3.4.3 Circuit Breakers Calculate the required fuse protection while referring to power specifications described in Appendix A: Specifications. -
Page 18: Cable Routing
Use coax RG-223, 50 ohm, male-to-male N-type to QMA for RF connections from the RIMs to the BTS/RBS and to the MRU. • When using the Corning remote unit in an environment in which other indoor coverage systems are installed, it is recommended (where possible) that the antennas are placed at least two meters apart •... - Page 19 Coax Length Coax Loss Connector Total Loss Loss (900 MHz) I nst al l ati o n G u id e li n es CMA -XXX- A E N P a ge 1 9 Draft...
-
Page 20: Antenna Specifications And Guidelines
• Max. VSWR/Return Loss:12 dB • Max. Insertion Loss (dB): 0.2 • Number of antennas that can be connected (with cables/splitters) – it is not recommended to connect more than one antenna per connector since 1:1 connectivity is reduced with each split. •... -
Page 21: Fiber Optic Requirements
Fiber Optic Requirements 3.7.1 Authorized Optic Cables The following specified optic cables are authorized for use with the MRU product: • Composite plenum tether assemblies • Fiber: LC APC, 2 – 24 fibers • 16 AWG, 14 AWG, 12 AWG; 2 – 12 Conductors •... -
Page 22: Installation
Installation This document describes the installation procedure for the Corning ONE™ wireless platform mid-power remote unit (MRU). Please refer to Chapter 3 - Installation Guidelines for specific guidelines on infrastructure planning, design and installation or please consult with a Corning product line manager or Corning approved Installer. -
Page 23: Mounting The Mru
2. Referring to Figure 4-1, secure the units’ rack ears to the rack frame as follows: • Insert two screws half-way into the rack frame (one on each side) • Position the bottom half slots of the chassis rack ears on to the screws •... -
Page 24: Wall Mount Installation
2. Verify that all the items listed in Table 4-2 are included in the wall-mount bracket package. If any of the listed items are missing, contact your Corning representative. 3. Check for signs of external damage. If there is any damage, call your Corning representative. Item... -
Page 25: Mounting Mru On Wall
4.2.2.2 Mounting MRU on Wall 1. Assemble wall-mount bracket to MRU underside. Figure 4-2. Assembling Bracket onto MRU 2. Select location and mark and drill appropriate holes in wall. IMPORTANT! MRU is installed belly-to-the-wall with door opening rightward. If installed near a right facing wall, make sure that there is at least 16 inches of clearance to open the door to the right and to successfully remove and replace all modules. - Page 26 3. Insert anchors in wall, hang unit and tighten to secure. Figure 4-4. Mounting MRU on Wall I nst al l ati o n CMA - XXX- A E N P a ge 2 6 Draft...
-
Page 27: Outdoor Installation
Assorted cable ties ◦ • right angle 4.3-10 type male connector coax cables – one for antenna connection and one for external 2.5 GHz RF source connection (if relevant) • Recommended - Flexible cable conduits for routing connections cables through cabinet knockouts; refer to Figure 4-6 for relevant knockouts;... -
Page 28: Pre-Installation Procedures
4.2.3.2 Pre-Installation Procedures 1. Remove each rack ear and reassemble according to position shown in Figure 4-5. Figure 4-5. Required Position of MRU Rack Ears 2. Referring to Error! Reference source not found. for relevant knockouts, use appropriate knockout tools to punch out knockouts for routing connection cables. -
Page 29: Install Mru In Cabinet
4.2.3.3 Install MRU in Cabinet 1. Carefully lay cabinet on backside (so door faces upwards) and open door. ATTENTION! Make sure that the door hatch lock into the door rail. See Figure 4-7. Note: Push hatch inwards towards the door to release and close the cabinet. Figure 4-7. - Page 30 2. Insert one 8 mm self-tapping screw (provided with the cabinet) half way into the bottom hole of each rail. Refer to Figure 4-8. Figure 4-8. Inserting Self-Tapping Screw in each Rail Note: An extension bar may be required to access the screws due to narrow space between chassis and cabinet rails.
- Page 31 For cabinet grounding instructions - refer to the manufacturers installation guide for instructions on cabinet grounding • Using one of the grounding cables provided with the cabinet, ground the MRU chassis via the two-hole, standard barrel grounding lug located on the front panel to one of the cabinet grounding bolts. Refer to Figure 4-10.
- Page 32 A. Connect the external alarms cable (provided with the MRU) to the chassis’s DB-9 ‘External Alarms’ connector. The connector provides indications for door opening, heat exchanger (HEX) and one additional input for future use. Refer to Table 4-5 and to Figure 4-12 for MRU ‘External Alarms’ connector pin out.
- Page 33 Figure 4-12. Location of External Alarms Connector and Cabinet Alarms Block B. Route the cable alarm wires to the alarm block, located on the upper right corner of the cabinet. C. Connect the external alarm connections to the cabinet according to the following: Refer to Table 4-6 for External Alarms cable wiring description.
-
Page 34: Grounding Mru Chassis
Figure 4-13. Example of External Alarm Wiring Connections 10. Verify that fans are operational and refer to status LEDs on the inside of the cabinet door and verify that all show green Grounding MRU Chassis The grounding connection is performed via a two-hole, standard barrel grounding lug located on the front of the MRU chassis (see Figure 4-14). -
Page 35: Fiber Connections
Fiber Connections To connect optic fiber 1. Remove the LC APC connector plugs. 2. Using Corning® SMF-28® fiber (or compatible), connect the MRU LC APC fiber connector towards the ICU. See Figure 4-15. Figure 4-15 Fiber Connections Towards ICU I nst al l ati o n CMA - XXX- A E N... -
Page 36: Rf Antenna Connections
See Figure 4-16. Figure 4-16 Example of MRU Connections to Broadband Antennas (Via Splitter) The MRU includes one 4.3-10 Type RF port used for connecting to a 2.5 GHz external RF source (e.g. picocell). External Alarm Connections A DB-9 female pin “External Alarms” connector (located on optical module below RJ45 ports) provides support for up to three external dry contact alarm connections from external sources (incoming outputs). - Page 37 Connect the open wire dry contact cable (ordered separately) to the MRU ‘External Alarms’ port and to the external input sources. Refer to Table 4-8 and to Figure 4-18 for pin out information. Description Common Not connected Not connected Not connected Not connected Door alarm HEX (heat exchange) alarm...
-
Page 38: Power Connections
CLASS 2 (default) – two eight pin terminal block connectors for remote feed (see section 4.7.2.1). • CLASS 1 – one two pin terminal block for local plant feed. To use CLASS1 user must change default connector mode from CLASS 2 to CLASS 1 (see section 4.7.2.2). - Page 39 • DC class 2: 24 VDC / 48 VDC (20-60 VDC)1.75 A maximum per pair • Power amplifier consumption per pair: 50 W • Maximum power consumption: 330 W • Maximum current consumption: 1.75 A per pair To perform CLASS2 DC connector wiring – for each DC pair: 1.
-
Page 40: Class1 Connector (Local Plant Feed)
4.7.2.2 CLASS1 Connector (Local Plant Feed) Note: In order to power the MRU via the CLASS1 connector (2 pole terminal plug), the DC bridge must be moved from the default CLASS2 mode position to CLASS1. DC CLASS1 power specs: • Power input: 48 VDC (40-60VDC) •... -
Page 41: Verifying Normal Operation
3. Push PEM back in slot and close captive screws. 4. Identify the positive and negative terminals for the DC pair to be wired on the CLASS1 connector feed positions. The wiring sequence is positive to positive and negative to negative. 5. -
Page 42: Appendix A: Specifications
Appendix A: Specifications Supported Services Frequency Range (MHz) Technology Service/Band Uplink (UL) Downlink (DL) 700 MHz Lower ABC 698-716 728-746 700 MHz Upper C 776-787 746-757 ESMR 800 817-824 862- 869 CDMA/LTE CELL 850 824-849 869-894 CDMA/GSM/LTE/UMTS CDMA/LTE/GSM/UMTS PCS + G 1900 1850-1915 1930-1995 AWS 2100... -
Page 43: Coupling Specifications
Optical Connector LC APC SM ® ® Fiber Type Corning SMF-28 fiber or compatible 1310 ± 10nm (@ 25 ◦ C) Wavelength A p pe n di x A: S p ecif ic ati o ns CMA -XXX- A E N... -
Page 44: Physical Specifications
One DC In two pin ‘Class 1’ terminal block Two “DC In” eight pin “Class 2” terminal block connectors: one pair for each PAM ( total of five pairs) and one pair for the FAM+OPTM; one RSV pair One QMA input connector for EXP UL... -
Page 45: Appendix B: Ordering Information
Appendix B: Ordering Information MRU Assembly Configurations Part Number Description MRU: Mid-power remote unit assembly; support for up to five service specific PAM modules; Includes OPTM, FAM, mid-plane and cavity filter; includes AC power cord (for AC models only) MRU-78171923-DC MRU-DC assembly with five PAM modules supporting LTE700,ESMR,PCS, AWS and WCS MRU-781719-DC MRU-DC assembly with four PAM modules supporting LTE700,ESMR,PCS and AWS... -
Page 46: Cable Assembly
866-436-9266 • FAX: 703-848-0280 • Tech Support Hotline: 410-553-2086 or 800-787-1266 • www.corning.com/opcomm Corning Optical Communications Wireless reserves the right to improve, enhance and modify the features and specifications of Corning Optical Communications Wireless products without prior notification. All other trademarks are the properties of their respective owners. Corning Optical Communications Wireless is ISO 9001 certified.
