CORNING Everon 6000 v1.0 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Everon™ 6000 v1.0
User Manual
Corning Optical
Communications
www.corning.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Everon 6000 v1.0 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CORNING Everon 6000 v1.0

Summary of Contents for CORNING Everon 6000 v1.0

  • Page 1 Everon™ 6000 v1.0 User Manual Corning Optical Communications www.corning.com...
  • Page 2 User Manual v1.0 Everon™ 6000 v1.0 User Manual...
  • Page 3 Intended Users and Scope This manual is intended for Corning system installers, technicians and users. It is assumed that the user is familiar with the system and its units, and understands the basic functionality of the system. Contacting Technical Support HelpDesk Corning technical support contact information: email: cmatsg@corning.com...
  • Page 4 The purchaser shall not modify the software in any way. It is strictly forbidden to use this product for any purpose other than originally designated for or stipulated by Corning. Conventions Important information is highlighted in a frame, as explained below: Warning Actions requiring special attention to avoid serious bodily injury;...
  • Page 5 Notwithstanding the foregoing, Corning shall have no obligation under the Software Warranty if the Software is modified or used with hardware or software not supplied or approved by Corning or if the Software is subject to abuse, improper installation or application, accident, electrical or environmental over-stress, negligence in use, storage, transportation or handling.
  • Page 6 Corning shall not be liable for any other damage including, but not limited to, indirect, special or consequential damages arising out of or in connection with furnishing of goods, parts and service hereunder, or the performance, use of, or inability to use the goods, parts and service.
  • Page 7 User Manual v1.0 RF Safety To comply with FCC RF exposure compliance requirement, adhere to the following warnings: Warning! Antennas used for this product must be fixed mounted on indoor permanent structures, providing a separation distance of at least 120 and above cm from all persons during normal operation. Warning! Each individual antenna used for this transmitter must be installed to provide a minimum separation distance of 380 cm or more from all persons and must not be co-located with any other antenna for meeting RF exposure requirements.
  • Page 8 Warning! Only use a special DC supply cable with connector Warning! Always keep DC IN connectors connected during the product operation Company Certification Corning products have met the approvals of the following certifying organizations: Certification Certification No.: 88061; Certification Issue Date: 26/06/2019 Initial Certification Date: 29/04/2007;...
  • Page 9 User Manual v1.0 UM - Everon 6000 DAS - 14-APR-2021 - clear of comments.docx| March 2021 |Page 9 of 202...
  • Page 10 Industrial Boosters may only be used by FCC licensees or those given express (individualized) consent of license. Corning Optical Communications Wireless certifies all of the VARs listed as licensed installers for Corning. For the list of licensed VARs, please contact the Technical Support Team at: onesupport@corning.com or + (1) 833 4CORNING (833-426-7646)
  • Page 11 User Manual v1.0 Revision History Revision Date Created by Reviewed by Changes Mar 2021 Yoni Henya Moti Shalev First issue Aloomit Godfarb Gila Shmueli UM - Everon 6000 DAS - 14-APR-2021 - clear of comments.docx| March 2021 |Page 11 of 202...

  • Page 12: Table Of Contents

    User Manual v1.0 Table of Contents Introduction ........................15 Key Features and Capabilities ....................15 Terminology, Acronyms, and Abbreviations ................16 Applicable Documents ......................19 Everon™ 6000 1.0 Architecture Overview ................20 1.4.1 External Interfaces and Use Cases - Example ..............20 1.4.2 Internal sub-units ......................
  • Page 13 User Manual v1.0 2.6.2 LRU Dimensions [mm] ....................62 2.6.3 LRU Interfaces ....................... 63 2.6.4 Combiner Interfaces ...................... 64 2.6.5 Fully connected system diagram ..................65 2.6.6 Connect under-lid cables ....................66 2.6.7 Mount the LRU ......................68 2.6.8 Connect the rest of the Cables ..................70 2.6.9 Combiner cables ......................
  • Page 14 User Manual v1.0 5.2.1 Set Site config – auto set ....................126 5.2.2 Power Sharing ......................130 5.2.3 Run time options ......................131 5.2.4 TDD Config ........................132 5.2.5 Adjustment ......................... 133 Using the System Graphical User Interface (GUI) ............134 Main GUI Options ......................

  • Page 15: Introduction

    Corning Everon 6000 high bandwidth distribution architecture provides preparedness for future radio technologies, broader spectrum, and new frequency bands. Due to its modular design and configuration flexibility, Corning Everon 6000 is highly scalable in terms of supported capacity (number of sectors, frequency bands, channels) and remote units (coverage), and can be easily configured to support a large variety of deployment scenarios including single and multi-building (“Campus”) network topologies.

  • Page 16: Terminology, Acronyms, And Abbreviations

    User Manual v1.0 1.2 Terminology, Acronyms, and Abbreviations Table 1 Abbreviations Abbreviatio Description Picture Chassis HEU — Headend unit IHU — Integrated headend unit Chassis RIM —Radio modules interface module OIM — Optical interface module HCM — Headend control module ACM —...
  • Page 17 User Manual v1.0 Abbreviatio Description Picture Remote units LRU Remote Antenna Unit: Medium Band / Low Band MRU — Mid-power remote unit HRU –High-power Remote Unit Network Operation Center Small Medium Venues CPRI Common Public Radio Interface UM - Everon 6000 DAS - 14-APR-2021 - clear of comments.docx| March 2021 |Page 17 of 202...
  • Page 18 User Manual v1.0 Abbreviatio Description Picture Digital Signal Processing EARFCN E-UTRA Absolute Radio Frequency Channel Number Evolved Packet Core EUTRA Evolved Universal Terrestrial Radio Access EUTRAN Evolved Universal Terrestrial Radio Access Network FPGA Field Programmable Gate Array GE / GigE Gigabit Ethernet Global Positioning System...

  • Page 19: Applicable Documents

    User Manual v1.0 Abbreviatio Description Picture UTRAN Universal Terrestrial Radio Access Network User Datagram Protocol 1.3 Applicable Documents Table 2: References Document Name Document # MN0020801 Everon 6000 UM UM - Everon 6000 DAS - 14-APR-2021 - clear of comments.docx| March 2021 |Page 19 of 202...

  • Page 20: Everon™ 6000 1.0 Architecture Overview

    User Manual v1.0 1.4 Everon™ 6000 1.0 Architecture Overview Corning Everon™ 6000 allows combining between Optical Network Evolution (ONE) platform, and the fully digital Corning Building Wireless System (BWS) platform, which incorporates the digital distribution units – Digital Router Unit (DRU) and remotes.
  • Page 21 User Manual v1.0 IHU and HEU - pair to provide all services: single DRU, connected Remote Units (LRU, MRU, HRU), where the number of connected remote units depends on the number of links the specific remote unit has (e.g. DLRU low band has only one CPRI link were the DLRU mid band has 3 CPRI links);...

  • Page 23: Internal Sub-Units

    CPRI format, and to route these signals to the remote units. The DRU supports all Corning digital remote antenna units’ flavours, for all services, power levels and antenna configurations (SISO or MIMO). Each DRU includes 4 F/O CPRI ports connected to the DCMs and 32 F/O...
  • Page 24 User Manual v1.0 CPRI ports for connection to the remote units. When additional remote antenna units are needed, the system scales up easily by adding additional system modules. DRU supports both AC and DC. 1.4.2.3 Remote Units LRU Digital Remote Antenna Unit: Medium Band / Low Band The LRU is a remote antenna unit with 20 dBm per MIMO stream per band output RF power and native support of 2x2 MIMO antenna scheme.
  • Page 25 User Manual v1.0 HRU – Digital High-power Remote Unit The HRU is a high power modular remote antenna unit which provides 43 dBm output RF power per service module, and native support of 2x2 MIMO antenna scheme. The HRU modular structure enables set ups of up to 8 service modules in 600/700 MHz Low/700 MHz High/FirstNet, 800/850 MHz, EAWS, PCS, WCS and 2.5GHz TDD.

  • Page 26: System Installation

    User Manual v1.0 2. System Installation This chapter provides installation instructions for the system units. Refer to the specific elements required in your deployment: Head End (HEU, HIU), see 2.1 DRU, see 2.5 Remote units Installation: LRU, see 2.6 MRU, see 2.7 HRU, see 2.8 Note: for dimensions and specifications refer to chapter 8.

  • Page 27: Head End Units - Architecture Examples

    User Manual v1.0 2.1 Head End Units – Architecture Examples Example 1: SISO ERFCxx Up to 7ACMs per 1 HCM 10MHz clock sync Optical cables Up to 4 DRUs per DCM (transform RF Remotes connected to DRU to CPRI) (combination of all remote types).
  • Page 28 User Manual v1.0 NOTEs: 1. The example above shows SISO configuration. For MIMO 2x2, there is a need to add an additional pair of IHU-HEU, where the DCMs for the 2 pair will be connected to the same DRU. To support 4x4 configuration, there is a need to add 2 additional pairs of IHU-HEU, and DRUs and remote units.

  • Page 29: Integrated Headend Unit (Ihu) Installation

    User Manual v1.0 2.2 Integrated Headend Unit (IHU) Installation The IHU chassis is supplied empty and only includes the factory assembled Fan Module (FAM) + additional modules according to the ordered PN. All other modules are ordered separately and must be installed. Example of system connection See 2.1 for example rack installations (SISO, MIMO).

  • Page 30: Verify Box Contents

    User Manual v1.0 2.2.1 Verify Box Contents Open the package and verify all elements are available according to the following table. Notes: * for details refer to APPENDIX B: Ordering information *see an example of package unpacking underneeth the table Table 3: HEU Package Items List Item Quantity...
  • Page 31 User Manual v1.0 Item Quantity Image reference clock signal connections between RIX modules. *Additional lengths can be ordered: • PCKC20: L=20 in • PCKC63: L=63 in • PCKC79: L=79 in ERFC (Expander Cable) - RF interface cable to HEU; 9 pin SMP to SMP connector Available in five different lengths: •...
  • Page 32 User Manual v1.0 Item Quantity Image Controller Module Kit (HCM or ACM - according to order) dHCM Kit (Headend Control Module) – installed in Main HEU unit; enables remote/local management of all hosted units ACM Kit (Auxiliary Control Module) – installed in Auxiliary HEU units;...

  • Page 33: Ihu Interfaces And Slots

    User Manual v1.0 2.2.2 IHU Interfaces and Slots The following figure shows the internal positions of IHU HCM/ACM DCM 2 RIM Slots 1-8 Figure 4: IHU Interfaces and Slots IHU Slots NOTE: If DCM cards are available, ensure they are installed in the IHU only (not in the HEU)! Each IHU includes 14 slots supporting the following modules (see Figure 4: IHU Interfaces and Slots ) Remove blank panel and slide in the relevant module (chassis slots are 100% mistake proof): 1 HCM (for Standalone/Master HEU units) / (One) ACM (for Auxiliary HEU unit)

  • Page 34: Mount The Chassis In A Rack

    User Manual v1.0 2.2.3 Mount the Chassis in a Rack Notes: • One HEU supports connections to up to four IHUs • IHU chassis requires 4U rack height availability • Rack nuts and screws not provided Determine the location of the HEU in the rack while considering additional HEU and IHU units and the lengths of the available ERFC cable.

  • Page 35: Install The Modules In The Chassis

    User Manual v1.0 2.2.4 Install the Modules in the Chassis Note: For modules with ejectors (i.e. RIM, RIX OIM, OIX, DCM and HCM/ACM) – verify that the ejectors are completely open when inserting in dedicated slot and then push in until the module clicks in to the backplane.

  • Page 36: Connect The Cables

    User Manual v1.0 2.2.5 Connect the Cables 2.2.5.1 Ground The grounding connection is performed via a two-hole, standard barrel grounding lug located on the HEU rear panel. • For use with stranded copper wire conductors • 10-14 AWG • Holes - 1/4 inch Grounding Lug (Chassis Rear) Grounding Lug (C 2.2.5.2 Connect RIMS to RF Source(S)
  • Page 37 REF OUT and REF IN ports of each of the RIX modules in the HEU chassis. See Error! Reference source not found. Note: use SFP+ from the approved list provided by Corning. Remove the rubber stopper from the source port.
  • Page 38 User Manual v1.0 2.2.5.4 RIX to OIX Connections Note: Each RIX module supports connections to up to two IHU. Using the appropriate length ERFC cable (according to distance of available OIX port) connect the HEU RIX module 9-Pin connector to the corresponding connector on the IHU OIX module. Refer to TBD for schematic diagram of coax connections in a maximum HEU-OIU configuration of 4x4 where all HEU units are connected to all IHU units.
  • Page 39 User Manual v1.0 2.2.5.5 Management Connections Notes: • One RJ45/RJ45 management cable is provided with each headend unit (i.e. HEU/IHU). • Up to 7 ACMs are connected to a single HCM, where the connection between the units is using RJ45 cables. For HCM modules only - using the provided RJ45/RJ45 communication cable, connect the HCM LAN port to the corporate LAN: HCM LOCAL Port to ACM Port LOCAL Management Connection...

  • Page 40: Power On

    User Manual v1.0 2.2.6 Power ON For PSM-AC modules – connect supplied power cable (100-240 VAC) connector to the PSM input connector and to the AC outlet and switch on. For PSM-DC modules – refer to Quick Start Guide provided with module for wiring pinout. Verify that the Power Status LED on each PSM shows green.

  • Page 41: Verify Nornal Operation

    User Manual v1.0 2.2.7 Verify NORNAL Operation If RF source is operational, verify that the RIM, DCM and HCM/ACM LEDs indicate normal operation UM - Everon 6000 DAS - 14-APR-2021 - clear of comments.docx| March 2021 |Page 41 of 202...

  • Page 42: Head End Unit (Heu) Installation

    User Manual v1.0 2.3 Head End Unit (HEU) Installation The HEU chassis is supplied empty and only includes the factory assembled Fan Module (FAM) + additional modules according to the ordered PN. All other modules are ordered separately and must be installed. NOTE: If DCM cards are available, ensure they are installed in the IHU only (not in the HEU)! Interfaces The following figure shows the internal positions of HEU...

  • Page 43: Verify Box Contents

    User Manual v1.0 To install the HEU, follow these steps: Verify box contents, see 2.3.1 Mount the chassis, see 2.3.2 Insert the modules into the chassis, see 2.3.3 Connect the cables, see 2.3.4 Power On, see 2.3.5 Verify normal operation, see 2.3.6 2.3.1 Verify Box Contents Open the package and verify all elements are available according to the following table.
  • Page 44 User Manual v1.0 Item Quantity Image RIX Module Kit 1 or 2 Radio Expander Module – expands (according the RF sources to the OIU to order) Pilot Transport Cable (P/N: PCKC47*) – Single QMA to QMA cable; L = 47 in; used for passing reference clock signal connections between RIX modules.
  • Page 45 User Manual v1.0 Item Quantity Image Controller Module Kit (HCM or ACM - according to order) dHCM Kit (Headend Control Module) – installed in Main HEU unit; enables remote/local management of all hosted units ACM Kit (Auxiliary Control Module) – installed in Auxiliary HEU units;...

  • Page 46: Mount The Chassis

    User Manual v1.0 2.3.2 Mount the Chassis Notes: • One IHU supports connections to up to seven Head-end units (HEUs or IHUs) in a single stack, where there in a single HCM per stack, and all the others have ACMs. •...

  • Page 47: Install The Modules In The Chassis

    User Manual v1.0 2.3.3 Install the Modules in the Chassis Note: For modules with ejectors (i.e. RIM, RIX and HCM/ACM) – verify that the ejectors are completely open when inserting in dedicated slot and then push in until the module clicks in to the backplane.

  • Page 48: Connect The Cables

    User Manual v1.0 2.3.4 Connect the Cables 2.3.4.1 Ground The grounding connection is performed via a two-hole, standard barrel grounding lug located on the HEU rear panel. • For use with stranded copper wire conductors • 10-14 AWG • Holes - 1/4 inch Grounding Lug (Chassis Rear) Grounding Lug (C 2.3.4.2 Connect RIMS TO RF Source(S)
  • Page 49 User Manual v1.0 2.3.4.3 RIX TO OIX Connections Note: Each RIX module supports connections to up to two IHU. Using the appropriate length ERFC cable (according to distance of available OIX port) connect the HEU RIX module 9-Pin connector to the corresponding connector on the IHU OIX module. Refer to TBD for schematic diagram of coax connections in a maximum HEU-OIU configuration of 4x4 where all HEU units are connected to all IHU units.

  • Page 50: Power On

    User Manual v1.0 2.3.4.5 Management Connections Notes: • One RJ45/RJ45 management cable is provided with each headend unit (i.e. HEU/IHU). • Up to 7 ACMs are connected to a single HCM, where the connection between the units is using RJ45 cables. For HCM modules only - using the provided RJ45/RJ45 communication cable, connect the HCM LAN port to the corporate LAN: HCM LOCAL Port to ACM Port LOCAL Management Connection...

  • Page 51: Verify Nornal Operation

    User Manual v1.0 2.3.6 Verify NORNAL Operation If RF source is operational, verify that the RIM, DCM and HCM/ACM LEDs indicate normal operation UM - Everon 6000 DAS - 14-APR-2021 - clear of comments.docx| March 2021 |Page 51 of 202...

  • Page 52: Additional Stack And Dru Connections

    User Manual v1.0 2.4 Additional stack and DRU connections For connections to additional IHU or HEU and DRU units: Using the appropriate length ERFC cable (according to distance of available OIX/RIX port) connect remaining IHU RIX and OIX module connectors as follows: •...

  • Page 53: Dru Installation

    User Manual v1.0 2.5 DRU Installation 2.5.1 Verify box contents The following table indicates the included and required items for installing the DRU unit. Item Quantity Image Part Number HARDWARE – provided in the box DRU unit 703A045402 AC Power Cord 708A042301 DC Power Adapter 255760003...

  • Page 54: Dru Interfaces

    User Manual v1.0 Item Quantity Image Part Number Grounding cable Clock 10Mhz input clock 10Mhz output clock USB to mini-USB cable Note: for technical support usage only. Required Tools Screwdriver 2.5.2 DRU Interfaces The following images indicate the DRU interfaces Front view 2 RJ45: LAN for DCM (capacity)

  • Page 55: Dru Dimensions [Mm]

    User Manual v1.0 2.5.3 DRU Dimensions [mm] Attribute Description Height 1U (44.45 mm) Width 19" (482.6 mm) Depth 16.5" (419 mm) Weight 9 kg (max) UM - Everon 6000 DAS - 14-APR-2021 - clear of comments.docx| March 2021 |Page 55 of 202...

  • Page 56: Mount The Dru In The 19'' Rack

    User Manual v1.0 2.5.5 Mount the DRU in the 19’’ Rack Determine the location of the DRU in the rack while considering additional units (e.g. power supply). Position the two brackets located on the DRU sides to fit in to the rack rail. Slide the DRU module into the selected slot on the 19”...
  • Page 57 User Manual v1.0 2.5.6.2 Power Use your selected power source (DC or AC); Connect the power-unit's cable to the DRU front panel. 2.5.6.3 Source (DCM) Connect an SFP+ Pluggable Transceiver to each source port to be used: Remove the rubber stopper from the SFP connector. Remove the rubber stopper from the source port (Figure 9).

  • Page 58: Verify Normal Operation

    User Manual v1.0 2.5.7 Verify Normal Operation SFP LED Behavior The following tables describe the DRU LEDs and the LED behaviour: LEDs Description and Behavior Picture Type Remote Description: A pair of LEDs (Orange; Green) (LPR) LEDs describes each port: the right pair relates Right pair: relates to the upper slot;...
  • Page 59 User Manual v1.0 LEDs Description and Behavior Picture Type Power LED Lit after SW initialization and during operation. RUN LED STAtus LED (Ethernet) General During power up all LEDS are lit system LED After SW initialization only power, run and behaviour LAN are lit (The optical LEDS are off) The following tables describe the DRU LEDs and the LED behaviour:...

  • Page 60: Lru Installation

    User Manual v1.0 2.6 LRU Installation Commented [RR1]: ‫להחליף לתמונות של ארז‬ 2.6.1 Verify box Contents Open the package and verify all elements are available according to the following table: Table 5: LRU Package Items List Item Quantity Image Part Number HARDWARE –...
  • Page 61 User Manual v1.0 Item Quantity Image Part Number RF Jumper cables DC Power Adapter 255760003 HARDWARE – not provided 4 screws #8 or 4mm (for attachment to ceiling) SFP+ Pluggable Transceivers (hot-pluggable optical transceiver module); Support for option 8 line-rate 10.1 Gbps, single mode Optical cables Up to 900 meters...

  • Page 62: Lru Dimensions [Mm]

    User Manual v1.0 2.6.2 LRU Dimensions [mm] Physical Dimensions Dimension (W x H x D) Inch 9.84 x 10.63 x 2.75 (250 x 270 x70) (mm) Weight 13 (6) (Kg) UM - Everon 6000 DAS - 14-APR-2021 - clear of comments.docx| March 2021 |Page 62 of 202...

  • Page 63: Lru Interfaces

    User Manual v1.0 2.6.3 LRU Interfaces SFP+ Management port Power Antenna Ground Connectors CPRI Port 1, SFP+ 10.1Gbps Antenna Ports 2, 4.3-10 female UM - Everon 6000 DAS - 14-APR-2021 - clear of comments.docx| March 2021 |Page 63 of 202...

  • Page 64: Combiner Interfaces

    User Manual v1.0 2.6.4 Combiner Interfaces The combiner has a total of 6 input ports and 2 output ports. 2 antenna ports SFP+ CPRI ports: 1 for low band, 3 for mid-band Notes: 1. To avoid MIMO disruption, ensure the antennas are connected correctly according to the combiner labels.

  • Page 65: Fully Connected System Diagram

    User Manual v1.0 Combiner Connection Interfaces Diagram The combiner connects between units: Mid-band LRU Low-band LRU (In the future: High-band (CBRS) LRU) The antennas are MIMO1, MIMO2 2.6.5 Fully connected system diagram The following figure shows the connections in a system that includes two units and a combiner. Connected Cables UM - Everon 6000 DAS - 14-APR-2021 - clear of comments.docx| March 2021...

  • Page 66: Connect Under-Lid Cables

    User Manual v1.0 2.6.6 Connect under-lid cables For each of the units, open the cover by removing 4 screws: Unscrew and open cover Fiber Optic jumper example (not provided) For each of the units connect the internal (under-cover) cables as follows: Power, See 2.6.6.1Error! Reference source not found.
  • Page 67 User Manual v1.0 2.6.6.1 Power Connect the DC wire pair (48V) to the LRU connectors panel, via the DC power adapter (terminal block connector 2.6.6.2 SFP+ Cables Remove the rubber stopper from the SFP+ connector located in the LRU RF port Connect the SFP+ LC/UPC SM DX optic cable to the LRU optic connector.

  • Page 68: Mount The Lru

    User Manual v1.0 2.6.7 Mount the LRU The LRU may be mounted on a wall or on a pole; single or dual. Select the configuration relevant to your deployment. Note: For dual-unit installations, the internal RF connections must be connected before connecting between the units.
  • Page 69 User Manual v1.0 For a dual unit: Connect the combiner to the mounted bracket using 4 screws. Combiner in bracket Connect between the low band and mid-band units, using the side-bracket: Mid-band Low band Note: Ensure the low band device is connected at the bottom, and the mid-band on top! Connect between the two devices and the base bracket (already carrying the combiner), using 4 screws, as shown below: Mid-band...

  • Page 70: Connect The Rest Of The Cables

    User Manual v1.0 2.6.8 Connect the rest of the Cables For each of the units, connect the cables as follows: Ground, see 2.6.8.1 Antenna, see 2.6.8.2 2.6.8.1 Ground Note: Ground according to local regulations The following additional (not supplied) tools and components are required for connecting the system ground: Grounding wire - grounding wire should be sized according to local and national installation requirements.
  • Page 71 User Manual v1.0 2.6.8.2 Antenna Connect the MRU male 4.3-10 Type duplexed RF “ANTENNA” port to the broadband antenna(s) using appropriate coax cables. Notes: 1. To avoid MIMO disruption, ensure the antennas are connected correctly according to the combiner labels. 2.

  • Page 72: Combiner Cables

    User Manual v1.0 2.6.9 Combiner cables Connect the Antenna cables according to the figure below. NOTE: C-Band is for future use. Mid-band Combiner in bracket Low band Combiner Fiber optic cable example (not provided) UM - Everon 6000 DAS - 14-APR-2021 - clear of comments.docx| March 2021 |Page 72 of 202...
  • Page 73 User Manual v1.0 Fully connected system Notes: 1. To avoid MIMO disruption, ensure the antennas are connected correctly according to the combiner labels. 2. There may be some configurations/use-cases where a combiner is not required, as there is only one type of unit (either low or mid band) UM - Everon 6000 DAS - 14-APR-2021 - clear of comments.docx| March 2021 |Page 73 of 202...

  • Page 74: Verify Normal Operation

    User Manual v1.0 2.6.10 Verify normal operation The following table describes the LRU LED behaviour. UM - Everon 6000 DAS - 14-APR-2021 - clear of comments.docx| March 2021 |Page 74 of 202...

  • Page 75: Mru (Digital Medium-Power Remote Unit) Installation

    User Manual v1.0 2.7 MRU (Digital Medium-power Remote Unit) Installation dMRU Notes: * Equipment with permanently connected to PE, conductor for installation of this conductor is carried by a skilled person. * The shield of the coax cable shall be connected to PE . * Equipment for use in locations where children not likely to be present.
  • Page 76 User Manual v1.0 Item Description Flavor Image dMRU-AC supported dMRU-67819-AC assembly with three dPAM modules - 600/700, 800/850 and dMRU-AC supported dMRU-6781923- assembly with four dPAM modules - 600/700, 800/850, PCS and WCS DC Chassis dMRU Chassis dMRU-ASM-DC Assembly with: DOPTM, FAM, Mid- Plane, Cavity Filter, MUX and DC power...
  • Page 77 User Manual v1.0 Item Description Flavor Image dMRU-DC supported dMRU-6781923- assembly with four dPAM modules - 600/700, 800/850, PCS and WCS dMRU CHASSIS dMRU-CHS-ASM ASSEMBLY WITH: DOPTM, FAM, MID- PLANE, CAVITY FILTER, MUX Brackets Wall mount bracket for dMRU BR-dMRU-W Screws, flathead,8-32X3/8 (Quantity: 11) DC connector...
  • Page 78 User Manual v1.0 Example Package Unpacking For an ordered package of PN : Open the box and verify the following units are available: dMRU-ASM-AC DOPTM, FAM, Mid-Plane, Cavity Filter, MUX and AC power supply. The units are to be entered into the chassis according to the installation instructions below. UM - Everon 6000 DAS - 14-APR-2021 - clear of comments.docx| March 2021 |Page 78 of 202...

  • Page 79: Mru Interfaces

    Reference source not found.). Any attempt to pull out the module without first releasing may cause damage. Corning will not be liable for damage of products resulting from improper handling during installation or repair. PAMs are entered to their relevant slots by matching the color of the PAM and the color on top of the slot.

  • Page 80: Mount Chassis In 19-In Rack

    User Manual v1.0 2.7.3 Mount chassis in 19-in Rack Note: for dimensions and specifications refer to chapter 8 Before mounting the chassis: unwrap each of the PAMs, and enter each PAM to its dedicated slot inside the chassis, according to the color-codes: Determine the location of the MRU in the rack while considering additional units (e.g.

  • Page 81: Wall Mount

    Reference source not found.). Any attempt to pull out the module without first releasing may cause damage. Corning will not be liable for damage of products resulting from improper handling during installation or repair. Caution: Due to the chassis + 6 DPAMS weight, it is recommended the unit is carried by two persons, to avoid damage to the system.
  • Page 82 User Manual v1.0 Assemble the wall-mount bracket to MRU underside Insert anchors in wall, hang unit and tighten to secure Minimum 16-in clearance Figure 13. Example of MRU Chassis wall Installation UM - Everon 6000 DAS - 14-APR-2021 - clear of comments.docx| March 2021 |Page 82 of 202...

  • Page 83: Ground Mru Chassis

    User Manual v1.0 2.7.5 Ground MRU Chassis The grounding connection is performed via a two-hole, standard barrel grounding lug located on the front of the MRU chassis. Required tools and components The following additional (not supplied) tools and components are required for connecting the system ground: Grounding wire - grounding wire should be sized according to local and national installation requirements.

  • Page 84: Connect Fiber Sfp

    User Manual v1.0 2.7.6 Connect Fiber SFP+ Note: use SFP+ from the approved list provided by Corning. Remove the rubber stopper from the source port. Push the SFP+ connector into the port, until it clicks (note that there is only one correct direction for plugging-in).

  • Page 85: Connect Antenna

    User Manual v1.0 2.7.7 Connect Antenna NOTE: The MRU has one output, that can be split via passive splitters. Connect the MRU male 4.3-10 Type duplexed RF “ANTENNA” port to the broadband antenna(s) using appropriate coax cables. Note: The test port is used for coupling; used for measuring the power without disconnecting the power without isco conn nnec...

  • Page 86: Connect Power & Power Up

    User Manual v1.0 2.7.9 Connect Power & POWER UP The MRU PSM is located on the bottom right of the chassis front. The PSM type (AC/DC) is model dependent. Refer to section 2.4.7.1 for AC models. Refer to section 2.4.7.2 for DC models 2.7.9.1 AC models WARNING! Approved power cable –...
  • Page 87 User Manual v1.0 2.7.9.2 DC Models DC model includes Class 1 terminal block connector: Power input: 36-60VDC Power consumption: 580W (maximum) Maximum DC current consumption: 16A Open PSM captive screws and pull-out module from chassis. hassis. Set DC input source type to “CLASS1” connector and secure PSM module back in place. See Figure 8. ecure PSM module back in place.

  • Page 88: Verify Normal Operation

    User Manual v1.0 2.7.10 Verify Normal Operation LEDs Verify that fans are operational. Refer to status LEDs on the top-left of the chassis door and on each PAM to confirm normal system operation according to the following table: Table 7: MRU Chassis and DOPTM LEDs Table 8: PAM LEDs UM - Everon 6000 DAS - 14-APR-2021 - clear of comments.docx| March 2021 |Page 88 of 202...
  • Page 89 User Manual v1.0 Table 9: SFP LEDs UM - Everon 6000 DAS - 14-APR-2021 - clear of comments.docx| March 2021 |Page 89 of 202...

  • Page 90: Hru Installation

    User Manual v1.0 2.8 HRU Installation dHRU comes in various formats, according to customer needs. An example is brought bellow: To install the dHRU, follow these steps: Verify your box contents, according to the specific model ordered, see 2.8.1 Review the system elements and interfaces, see 2.8.2 Install the system, see 0 UM - Everon 6000 DAS - 14-APR-2021 - clear of comments.docx| March 2021 |Page 90 of 202...

  • Page 91: Verify Box Contents

    User Manual v1.0 2.8.1 Verify Box Contents Open the package and verify all elements are available according to the following table. Notes: * for details see APPENDIX B: Ordering information * See unpacking example underneeth the table. Table 10: dHRU Package Items List Item Description Flavor Image...
  • Page 92 User Manual v1.0 Item Description Flavor Image dHRU-dHPAM-19 HRU Digital High Power Amplifier Module supporting PCS dHRU-dHPAM-17 HRU Digital High Power Amplifier Module supporting AWS dHRU-dHPAM-23 HRU Digital High Power Amplifier Module supporting WCS dHRU-dHPAM-25 HRU Digital High Power Amplifier Module supporting TDD 2500, 100MHz contiguous BW HRU combiner module...

  • Page 93: Dhru Interfaces, Connections, Dimensions

    User Manual v1.0 2.8.2 dHRU Interfaces, Connections, Dimensions This section details the interfaces of the system sub-elements, as well as the fully connected system internal and external interfaces: OEU interfaces, see 2.8.2.1 RFU interfaces, see 2.8.2.2 Fully connected system interfaces, see 2.8.2.3 System connection architecture, see 2.8.2.4 2.8.2.1 OEU interfaces Top panel...
  • Page 94 User Manual v1.0 OEU Dimensions 2.8.2.2 RFU Interfaces Bottom Panel CPRI Optical AC power Local debug Interface, To OEU (from OEU) port, RJ45 External Interface: Top Panel Coupling (power check 4.3-10 Mini Din without disconnecting from internet) UM - Everon 6000 DAS - 14-APR-2021 - clear of comments.docx| March 2021 |Page 94 of 202...
  • Page 95 User Manual v1.0 Mechanical dimensions UM - Everon 6000 DAS - 14-APR-2021 - clear of comments.docx| March 2021 |Page 95 of 202...
  • Page 96 User Manual v1.0 2.8.2.3 Full System Interfaces The system includes two combiners and several band modules. Note: There are labels on the combiners, indicating the RFU band names, to which they connect (two of each, as this is MIMO) RF connections and combiner Bottom connections: 7 CPRI ports: from OEU to each unit...
  • Page 97 User Manual v1.0 UM - Everon 6000 DAS - 14-APR-2021 - clear of comments.docx| March 2021 |Page 97 of 202...
  • Page 98 User Manual v1.0 2.8.2.4 System Connection Architecture Note: all internal connectors from OEUs to RFUs are provided. All external SFPs (OEUs to DRU) are purchased seperately. The following figure indicates the system internal and external interfaces. The system includes two combiners: 1) Low band: Ports for: 600, 700, 850 + a port that that receives the combined RF signal from the mid-band combiner (entry coming from the Mid-band) 2) Mid band: Ports: sums all bands –...

  • Page 99: Installation Steps Overview

    User Manual v1.0 2.8.3 Installation steps Overview 1) Mount the system , see 2.8.3.1 2) Connect the internal cables (CPRIs, RFs), see 2.8.3.2 3) Connect external cables (OEUs to DRUs) see 2.8.3.3 4) Connect the other cables (ground, power), see 2.8.3.4 5) Power up and verify normal operation, see 0 UM - Everon 6000 DAS - 14-APR-2021 - clear of comments.docx| March 2021 |Page 99 of 202...
  • Page 100 User Manual v1.0 2.8.3.1 Mount chassis on the wall Note: for dimensions and specifications refer to chapter 8 Mount each of the two brackets (Low and Mid) on the wall, and connect the modules to the bracket using screws as follows: Before mounting the dHRU: unwrap each of the elements.
