  • Page 1 Instruction Manual MODEL: TEEGA...
  • Page 2 Tables of Contents Item Page NO. 1. Safety Precautions....................... 2. Parts & Accessories..................... 3. Installation Instructions....................3-5 a. Fan Mounting.....................3 b. . Blades.........................4 c. Wiring Connection....................5 4. Power Supply Connection....................6-7 5. Circuit Diagram......................6. Technical Specifications....................7. Maintenance........................11 Safety Precaution IMPORTANT: PLEASE READ BEFORE INSTALLATION 1.
  • Page 3 Parts & Accessories Item 1. Canopy 2. Dow Rod 3. Down rod Jointer Cover 4. Blade 5. Fan Host Component Canopy Down Rod Down rod Jointer Cover Blade Fan Host Component 1H 4H 8H Receiver Transmitter Note: The Illustrations in this manual are for explanation purposes only and may differ from the actual unit.
  • Page 4 Installation Instructions IMPORTANT: SWITCH OFF THE ELECTRICAL MAINS AT THE CIRCUIT BREAKER FUSE BOX. Step 1 - Tighten the Ceiling Canopy Top Cover Component, Sealed Pads and Hanger Bracket with screws provided. Step 2 - Remove the Fan Host Ring Cover.
  • Page 5 Installation Instructions Step 3 - Tighten the blades with screws provided. Each blade uses 3 pieces of screws. Ensure the screws (9 pcs) for securing the blades are tightly screwed. Step 4 - Fix back the Fan Host Ring Cover.
  • Page 6 Installation Instructions Step 5 - Connect wiring as show. Step 6 - Tighten the ceiling canopy component with screws provided.
  • Page 7 Remote Control Insert 2x1.5V AAA battery (provided) into the transmitter. Function Transmitter - Turn the fan on/off - 1 for low speed, 6 for high speed - Controls the fan direction, forward or reversed - Turn on the light - Turn off the light 1H 4H 8H - Fan stop after 1hr - Fan stop after 4hr...
  • Page 8 Power Supply Connection IMPORTANT: DO NOT CONNECT THIS REMOTE CONTROL CEILING FAN TO DIMMER SWITCH OR WALL REGULATOR.
  • Page 9 Circuit Diagram BROWN LIVE BLUE NEUTRAL PINK PINK MOTOR YELLOW/GLEEN GRAY GRAY YELLOW/GLEEN RECEIVER BLUE BLUE WHITE WHITE Maintenance Due to the fan’s natural movement, connections may get loose after a period of usage. To ensure a proper and safety usage, it is highly recommended to inspect and tighten all connections every 6 months.
  • Page 10 Technical Specifications More than 1M Teega Model No. of Blades Voltage 240V / 50Hz Motor...
  • Page 11 Balancing DYNAMIC BLADE BALANCING KIT PREFACE Sometimes, your ceiling fan have wobbling problems when operating due to irregularity in the blades of the blade holders Also, improper assembly in the mounting system or crooked bearing may cause some additional problems. This balancing kit can be used to fix wobbling problems.
  • Page 14 Customer Service Centre If you need any Technical assistance or to report a fault, please contact our customer service centre at:...
