Do you have a question about the ANISE and is the answer not in the manual?
Questions and answers
luqman
February 13, 2025
why my **** is in reverse
1 comments:
Mr. Anderson
February 13, 2025
Your NSB FAN ANISE may be running in reverse because the "Fan Forward/Reverse" function has been activated. This function controls the direction of the ceiling fan. You can check your RF transmitter and press the "Fan Forward/Reverse" button to change the fan's rotation direction.
WARNING: If unusual oscillating movement is observed, immediately stop using the ceiling fan and contact the manufacturer, its service agent or suitably qualified persons. The weight of the appliance in kilograms: . kg Anise: The weight of the appliance in kilograms: 6.6kg...
PARTS & ACCESSORIES Fig.1 Models without lights hook Models with lights(LED) hook ling cover Remote control x 1set Fig.1 Fig.2 Models with lights(LED) hook Remote control x 1set Fig.2...
Page 4
INSTAKK THE DOWNROD ASSEMBLY IMPORTANT: SWITCH OFF THE ELECTRICAL MAINS THE CIRCUIT BREAKER FUSE BOX. Follow the steps below to hang your fan properly. down rod Parts screws(C) Fig.3 Insert the downrod through the canopy and oupling cover(Fig.4) . Align the holes at the bottom of the downrod with the holes in the on top of the fan motor assembly.(Fig.5) Carefully insert the bolt through the holes in the motor shaft and downrod.
Page 5
INSTALLATION OF THE MOUNTING HOOK “J” Hook mounted When mounting the fan, ensure that the safety cable is loop across the “J” hook “U” Hook mounted Remove the bolt, pin, nut, washer and rubber pulley from the downrod. Place the rubber pulley onto “U” hook and fix back the bolt, pin, nut and washer.
ELECTRICAL CONNECTION Warning : To avoid possible electric shock, turn off the electricity at the main fuse box or circuit panel before the fan electrical connection. For safety and best installation result please consult a qualified electrician. 7. Connect wires: As shown in the below (Fig.9) Connect the Black wire from motor to the Black "For Light L"...
Page 7
BLADE INSTALLTION INSTALLATION OF THE MOUNTING HOOK “J” Hook mounted When mounting the fan, ensure that the safety cable is loop across the “J” hook 8. Insert the screws through the motor blade holder then secure the blade to the “U”...
Page 8
INSTALL THE LIGHT KIT & BOTTOM COVER 10. Take off 1 screw from the connection base, and lo sen the other two screws (do not remove). Attach the fan light plate onto the lamp base, and slide through the two key holes on plate by turning clockwise, then bottom cover Fig.11...
USING YOUR REMOTE CONTROL Buttons function description: Installation: nstall the RF Transmitter holder on wall with the 2 Switch OFF the fan screws provided. Switch ON/OFF the light.(Each time the button is Install provided battery into the RF Transmitter. pressed quickly, the LED color changes in sequence: Note: warm white >...
MAINTENANCE Due to fan’s natural movement, connections may get loose after a period of usage. To ensure a proper and safety usage, highly recommended to inspect and tighten all connections every 6 months. CLEANING Clean your fan periodically to prolong its new appearance. Basic cleaning procedures are as follows: Use only lukewarm water.
Need help?
Do you have a question about the ANISE and is the answer not in the manual?
Questions and answers
why my **** is in reverse
Your NSB FAN ANISE may be running in reverse because the "Fan Forward/Reverse" function has been activated. This function controls the direction of the ceiling fan. You can check your RF transmitter and press the "Fan Forward/Reverse" button to change the fan's rotation direction.
This answer is automatically generated
