Ulvac DISL-102 Instruction Manual

Oil-free scroll vacuum pump
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
.
Instruction Manual (Original Instructions)
Oil-free Scroll Vacuum Pump
DISL-102
This instruction manual includes very important warnings, cautions and operating
procedure in order to operate this pump safely and efficiently.
Be sure to read this instruction manual thoroughly and fully understand before
operation.
After reading it, store it in a convenient place for immediate and future reading.
※Before use, be sure to fill in the blank spaces below for future repair and after-service.
Serial No.
Who sold it to you
Purchase date
When you began
operation
No.４６５１０－２－０２－１
CA72161368

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DISL-102 and is the answer not in the manual?

Questions and answers

Related Manuals for Ulvac DISL-102

Summary of Contents for Ulvac DISL-102

  • Page 1 CA72161368 Instruction Manual (Original Instructions) Oil-free Scroll Vacuum Pump DISL-102 This instruction manual includes very important warnings, cautions and operating procedure in order to operate this pump safely and efficiently. Be sure to read this instruction manual thoroughly and fully understand before operation.

  • Page 2: Important Information

    Important information Be sure to read this instruction manual to understand how to operate equipment correctly. Only operators, who fully understand warnings, cautions and instructions, are to operate the equipment. Improper operation (mishandling) can cause serious bodily injury, death, fire or explosion. Store this manual in a convenient place for immediate and future reference.

  • Page 3: For Safe Operation

    Danger of electric shock Be careful to install vacuum pump using Install in an area which is not exposed to motor handle (DISL-102 mass 17kgs) moisture such as rain or steam. while paying attention to stability of If moisture comes into and tact with the suspended load.
  • Page 4 For safe operation WARNING Danger of short-circuit and Danger of electric shock electric shock Connect earth cord to earth terminal in motor terminal box. The power-supply conductor shall be free If not, it can cause bodily injury from from strain including twisting by using cord Protect cable electric shock.
  • Page 5 For safe operation CAUTION Danger of overheating Danger of overheating Install in a well-ventilated area. Operate at ambient temperature of 5℃ Poor ventilation can disrupt cooling and cause ~40℃. accident, failure or bodily injury such as burns Operating at a temperature range other since this vacuum pump is an air-cooled type.
  • Page 6 For safe operation CAUTION Danger of foreign matter entering Danger of vacuum break and inlet pollution If you use the seal material or the Be sure to close isolation valve between adhesive, etc. to prevent Leak of the joint vacuum pump and vacuum system when piping with internal screw of inlet, be (chamber) during start-up and stop.
  • Page 7 Where to attach warning stickers Where to attach warning stickers Always keep warning stickers clean and legible. If they become dirty or detached, replace them with new ones. If you need replacement stickers, contact our sales branches who sold the vacuum pump to you. Protection Cover Main Cover Condenser Cover...

  • Page 8: Table Of Contents

    Contents Important information ......................... 1 For safe operation ........................2 Contents ............................7 1. Before use ..........................8 1.1 Check the product ......................8 2. Name and structure of each section ................... 10 3. Installation ..........................11 3.1 Wiring ..........................12 3.2 Test operation ........................

  • Page 9: Before Use

    1. Before use 1.1 Check the product ・Check that the package is right-side-up before opening. ・Check that the model of the product is the same as the one you ordered. How to read model name DISL：model D I S L – 1 0 2 Displacement (swept volume) 10:100L/min at 50Hz Motor ・Check that there is no damage.
  • Page 10 Open package WARNING Danger of cargo collapse Hold the motor handle of the product (DISL-102 mass 17kgs) firmly, when installing vacuum pump. Be careful about If not, it can cause damage, failure or bodily injury from falling vacuum pump, or by being lifting caught between vacuum pump and other material.

  • Page 11: Name And Structure Of Each Section

    2. Name and structure of each section Motor Inlet NW25 Handle (Internal screw size Rc3/8) Terminal Box Outlet NW16 Bracket Air Flush Port (Rc1/8) (It is closed by plug when shipping from factory.) Housing Fixed Scroll FS Orbiting Scroll OS Handle Motor Back-up -Seal...

  • Page 12: Installation

    3. Installation WARNING Danger of electric shock Install in an area which is not exposed to moisture such as rain or steam. If moisture comes into and tact with the electric source connection, it can cause fire or Avoid moisture bodily injury due to short-circuit or electric shock.

  • Page 13: Wiring

    3.1 Wiring WARNING Danger of short-circuit and electric shock Ask a qualified electrician to perform electrical wiring. If not, short-circuit or electric shock can cause fire or bodily injury. Ask qualified electrician Danger of electric shock and entanglement Be sure to turn off electric source on building site before wiring. If not, it can cause electric shock or bodily injury due to turning objects.
  • Page 14 Danger of restart Be sure to switch off electric source before maintenance or inspection. Single-phase motor has a thermal protector. Vacuum pump restarts become cool without warning after vacuum pump. With a thermal protector CSA Requirement Thermally protected automatic reset. TYPE TP212. Motor restart without warning after protector trip. Min.
  • Page 15 Activate the emergency stop by electric source switch or protective device. Avoid motor burnout by protective device (chart 1). Use rated over 10A electric source cable and earth cord. Use round type terminal. Fit cable-gland. Connect earth cord to earth terminal. Chart－1 Recommended breaker (or Voltage...
  • Page 16 How to wire ① Remove 1pcs. of M5 bolt at motor terminal box and remove protection cover. ※Be sure to keep M5 bolts and washer, which were removed from the protection cover. ② Wiring diagram is shown inside protection cover. ③...

  • Page 17: Test Operation

    3.2 Test operation CAUTION Danger of cap to fly Remove cap from inlet and outlet. Operation with cap being fitted can cause cap to fly by intake or exhaust impetus, Remove cap resulting in accident, failure, or bodily injury from contact with flying objects. Danger of human body parts contacting vacuum At starting up of the vacuum pump and during operation, be careful not to enter human body into the inlet.

  • Page 18: Connection To Vacuum System (Chamber)

    In order to keep condensation away from feeding into the exhaust port, take proper measure. It causes exhaust disturbance. Drain condensations periodically by using valve separately arranged. Leak valve Chamber Vacuum pump Outlet duct Inlet Outlet Isolation valve (Automatic valve) DISL-102 Drain condensation -17-...

  • Page 19: Operation

    4. Operation Be sure to use the procedure below to start up or shut down the pump. ・When you do not use air-flush device, proceed 4.1 Air-flush closed operation [page 20]. ・When you use air-flush device, proceed 4.2 Air-flush opened operation [page 21]. WARNING Danger of explosion and ignition Do not evacuate gas which is hazardous to humans or explosive, flammable, or...
  • Page 20 CAUTION Danger of vacuum break and pollution Be sure to close isolation valve between vacuum pump and vacuum system (chamber) during start-up and stop. Start or stop after Start-up or stop with isolation valve in the open position can draw back gas and debris closing isolation attached to inside of vacuum pump to vacuum chamber due to pressure differential, valve...

  • Page 21: Air-Flush Closed Operation

    4.1 Air-flush closed operation 4.1.1 Start-up ① Check that caps of inlet and outlet is removed. ② Close isolation valve in order to prevent the drawback of debris attached to the inside of vacuum pump into vacuum chamber due to pressure differential, resulting in vacuum break and pollution.

  • Page 22: Air-Flush Opened Operation

    4.2 Air-flush opened operation This pump is equipped with air-flush port. Before evacuating vapor, read precautions below completely and be sure to understand the contents. Purpose of air-flush Evacuating moisture or humid gas by vacuum pump can cause condensed water to remain in pump.

  • Page 23: Start-Up And Shut-Down

    4.2.2 Start-up and shut-down ① Start vacuum pump according to 4.1.1 Operation [page 20]. ② Stop vacuum pump according to 4.1.2 Shut-down[page 20]. Important Continuous evacuating of humid gas When evacuating vacuum chamber while humidity in chamber is high, moisture volume drawn into pump differs according to temperature and pressure in chamber.

  • Page 24: Maintenance And Inspection

    Replace Exhaust valve Dirty, clogged Blowing air, clean Electric source cable Deteriorated Replace Upon start-up or during operation of DISL-102, it is normal that grease marks may be found at the noted area. Bearing Inlet Outlet Possible grease marks -23-...

  • Page 25: Maintenance

    5.2 Maintenance When maintenance interval has elapsed, be sure to contact our distributor who sold it to you. This vacuum pump requires maintenance conducted only by our authorized specialist. Never try to disassemble, reassemble or alter on user’s side. We are not responsible for any accidents caused by disassembly, reassembly or alteration which was done by the user or non-specialist.

  • Page 26: Problems And Remedies

    6. Problems and remedies If something goes wrong, refer to the following chart and remedy problems. If you cannot solve your problems, please contact either our sales branches who sold it to you or local sales. Problems Causes Remedies Protective device (or breaker) ※Inspect and repair.

  • Page 27: Specifications

    8. Specifications 8.1 Specifications Model DISL-102 Back-up material Fluorine rubber 50Hz Displacement L/min 60Hz Ultimate pressure Pa ≦20 Max. inlet pressure Atmospheric pressure Ambient operating temperature ℃ 5～40 Single-phase induction motor 2P,Totally-enclosed,Insulation Class B, Type Capacitor start, run, Thermal Protector TP212, Automatic reset type, IP44...

  • Page 28: Dimensions

    8.2 Dimensions 8.3 Performance data -27-...

  • Page 29: Warranty And After-Sales Service

    Then attach the complete sheet to the vacuum pump and send it to the service representative. However, please note that ULVAC KIKO cannot repair or inspect the vacuum pump if any gas prohibited in this manual or any gas that gives an adverse effect to the service person was sucked in the vacuum pump.

  • Page 30: Vacuum Pump Check Sheet For Repair

    ６． Miserenious information. Please describe any information if necessary. ７． Send to □Ulvac Kiko,Inc. CS Center. Yokohama Service Dep. 【Address】1-10-4, Kitashinyokohama, Kohoku-ku, Yokohama City, Kanagawa Prf, Japan TEL:045-533-0509 FAX:045-533-0512 □Ulvac Kiko,Inc. CS Center. Miyazaki Service Dep. 【Address】291-7, Chausubaru, Saito City, Miyazaki Prf. Japan TEL:0983-42-4135 FAX:0983-43-2159 ※...
