Read instructions carefully before attempting to assemble, install, operate or service this pressure
washer. Failure to comply with instructions could result in personal injury and/or property damage!
MODEL:
SERIAL NUMBER:
DATE PURCHASED:
FOR SALES AND SERVICE, PLEASE CONTACT:
MODELS 555HE, 555SS,
560SS, 680SS
OPERATING INSTRUCTIONS
AND PARTS MANUAL
9.808-383.0 - A
(10/23)
Advertisement
Table of Contents
Related Manuals for Hotsy 555HE
Summary of Contents for Hotsy 555HE
- Page 1 MODELS 555HE, 555SS, 560SS, 680SS OPERATING INSTRUCTIONS AND PARTS MANUAL Read instructions carefully before attempting to assemble, install, operate or service this pressure washer. Failure to comply with instructions could result in personal injury and/or property damage! MODEL: SERIAL NUMBER:...
- Page 3 555HE 555SS Flow Rate At Pump Head: 2.2 gpm/132 gph Flow Rate At Pump Head: 2.2 gpm/132 gph ■ ■ Pressure At Pump Head: 1300 psi Pressure At Pump Head: 1300 psi ■ ■ Burner Type: Fuel Oil Fired, 185,000 BTU/Hr.
-
Page 4: Table Of Contents
The model and serial numbers will be found on a decal attached to the pressure washer. You should record both serial number and date of purchase and keep in a safe place for future reference. Manual Hotsy, 500 Series • 9.808-383.0... -
Page 5: Important Safety Information
2. Know how to stop the machine and bleed pressure quickly. Be thoroughly familiar with the controls. del cable de alimentación. Si no se cumple este requisito se puede producir una descarga eléctrica. 3. Stay alert — watch what you are doing. Manual Hotsy, 500 Series • 9.808-383.0... - Page 6 (Safety glasses do not provide d'incendie —Ne pas ajouter full protection.) de carburant pendant que la RISK OF FIRE. machine fonctionner ou est DO NOT ADD FUEL WHEN OPERATING encore chaude. MACHINE. Manual Hotsy, 500 Series • 9.808-383.0...
- Page 7 áreas de agarre designadas de la pistola rociadora y la varilla. No coloque las manos o los pies en áreas sin aislamiento de la lavadora a presión. Manual Hotsy, 500 Series • 9.808-383.0...
- Page 8 Mantenga el freno activado durante la máquina avoir une pente et un drainage adéquats pour operación y almacenaje. réduire la possibilité d'une chute due à une surface glissante. Follow the maintenance instructions specified in the manual. Manual Hotsy, 500 Series • 9.808-383.0...
-
Page 9: Component Identification
Unloader Valve — Safety device which, when the than 2 minutes, water will leak from the pump spray gun closes, prevents over pressurization (Not protector. Warm water will discharge from pump Shown.) protector onto floor. This system prevents internal pump damage. Manual Hotsy, 500 Series • 9.808-383.0... -
Page 10: Assembly Instructions
2. Install pressure hose on machine as shown in Figure 1. Handle Relief Valve Pressure Hose Bolts, Washers and Nut Figure 3 - Handle Installation Figure 1 - Pressure Hose Installation Manual Hotsy, 500 Series • 9.808-383.0... -
Page 11: Installation Instructions
Proper combustion can only be obtained when there is a sufficient supply of oxygen available for the amount of fuel being burned. If it is necessary to install the machine in a poorly ventilated area, outside fresh air Manual Hotsy, 500 Series • 9.808-383.0... -
Page 12: Operation Instructions
Lorsqu'une prise correctement mise à la masse n'est Lock pas disponible, il incombe au propriétaire d'en faire installer une. Toujours débrancher l'alimentation avant d'effectuer des opérations d'entretien sur la Figure 4 - Nozzle Installation/Trigger Lock laveuse à pression. Manual Hotsy, 500 Series • 9.808-383.0... -
Page 13: General Cleaning Techniques
High pressure wash a These chemicals will harm the machine and will dam- small area, then check the surface for damage. If age the surface being cleaned. no damage is found, continue to pressure wash- ing. Manual Hotsy, 500 Series • 9.808-383.0... -
Page 14: Storage
La alteración Figure 5 - Pump Lubrication del ajuste de fábrica puede causar lesiones perso- nales y/o daños materiales y anula la garantía del fabricante Manual Hotsy, 500 Series • 9.808-383.0... - Page 15 These deposits will insulate the coil. This will restrict the air flow through the coil, further aggravating the soot buildup. Contact your local service center when desooting is needed. Manual Hotsy, 500 Series • 9.808-383.0...
-
Page 16: Troubleshooting
Clogged fuel filter. Clean fuel filter. BURNER SMOKES Air intake adjustment needs to be Readjust air intake per the oil burner section OR HAS adjusted. of this manual. OBNOXIOUS ODOR. Improper fuel. Use proper fuel. Manual Hotsy, 500 Series • 9.808-383.0... - Page 17 IMPORTANT If the pressure washer demonstrates other symptoms or the corrective actions listed do not correct the problem, contact the local authorized Hotsy Service Center. The Hotsy Service Center can be identified by visiting www.hotsy.com. When ordering from your dealer, please provide the following:...
