1800/5700 Series
Hot Water - Electric - Oil Fired
Operator's Manual
WARNING:
This product and accessories may contain a chemical
State of California to cause cancer and birth defects or other
reproductive harm.
For more information about this regulation:
Stationary Pressure Washer
known
to the
www.P65Warnings.ca.gov
MODELS:
1.109-665.0
1.109-666.0
1.109-658.0
1.109-659.0
For the Hotsy Dealer nearest you,
consult our web page at
www.hotsy.com
8.916-831.0-D
1830SS
1833SS
5730SS
5733SS
05/20/18
Advertisement
Table of Contents
Related Manuals for Hotsy 1830SS
Summary of Contents for Hotsy 1830SS
- Page 1 1.109-665.0 1833SS 1.109-666.0 5730SS 1.109-658.0 5733SS 1.109-659.0 For the Hotsy Dealer nearest you, consult our web page at WARNING: www.hotsy.com This product and accessories may contain a chemical known to the State of California to cause cancer and birth defects or other reproductive harm.
-
Page 2: Machine Data Label
If the pressure washer demonstrates other symptoms or the corrective actions listed do not correct the problem, contact the local authorized Hotsy Service Center. The Hotsy Service Center can be identified by visiting www.hotsy.com. When ordering from your dealer, please provide the following:... -
Page 3: Table Of Contents
Heating Coil ......16 Troubleshooting ......17 MANUAL, OPERATOR, HOTSY, STAT ELECTRIC, OIL 8.916-831.0 - D... -
Page 4: How To Use This Manual
• Troubleshooting Model: Date of Purchase: Serial Number: Dealer: Address: Phone Number: Sales Representative: The model and serial number of your machine is located on the back of the machine. MANUAL, OPERATOR, HOTSY, STAT ELECTRIC, OIL 8.916-831.0 - D... -
Page 5: Safety
When ordering parts, please specify model and serial number. Use only identical replacement parts.This machine is to be used only by trained operators MANUAL, OPERATOR, HOTSY, STAT ELECTRIC, OIL 8.916-831.0 - D... -
Page 6: Important Safety Information
DO NOT ADD FUEL WHEN OPERATING 6.Oil burning appliances shall be d'électrocution. Vérifier auprès d'un électricien MACHINE. installed only in locations where qualifié ou du personnel d'entretien si vous avez MANUAL, OPERATOR, HOTSY, STAT ELECTRIC, OIL 8.916-831.0 - D... - Page 7 Ne pas 13. Inlet water must be clean fresh water and no hotter placer les mains ou les pieds sur des endroits non then 90°F. isolés de la laveuse à pression. MANUAL, OPERATOR, HOTSY, STAT ELECTRIC, OIL 8.916-831.0 - D...
- Page 8 18” or more above the floor. Install on non combustible flooring and have a 36” minimum working clearance. 22. Do not allow acids, caustic or abrasive fluids to pass through the pump. MANUAL, OPERATOR, HOTSY, STAT ELECTRIC, OIL 8.916-831.0 - D...
-
Page 9: Operations
L 51” X W 31” X H 54” 5730SS 1471 Lbs 12” L 51” X W 31” X H 54” 5733SS 1471 Lbs 12” L 51” X W 31” X H 54” MANUAL, OPERATOR, HOTSY, STAT ELECTRIC, OIL 8.916-831.0 - D... -
Page 10: Component Identification
Exhaust Vent High Pressure Nozzle Pressure Relief Valve Wand High Pressure Hose Fresh Water Inlet Pump Switch Burner Switch Chemical Valve Garden Hose Thermostat Trigger (not included) Detergent Bucket (not included) MANUAL, OPERATOR, HOTSY, STAT ELECTRIC, OIL 8.916-831.0 - D... -
Page 11: Assembly Instructions
Pressure Hose, Trigger Gun and Wand 1. When assembling, use teflon tape on all plumbing connections to prevent leakage. 2. Install the pressure hose on the pressure washer as shown. Pressure Hose MANUAL, OPERATOR, HOTSY, STAT ELECTRIC, OIL 8.916-831.0 - D... -
Page 12: Installation Instructions
CAUTION: All venting must be in accordance with applicable federal and state laws, and local ordi- nances. This machine is not to be connected to a type B gas vent. Consult local heating contractors. MANUAL, OPERATOR, HOTSY, STAT ELECTRIC, OIL 8.916-831.0 - D... -
Page 13: Oil Burner
It is important that the licensed contractor consult local altitude. For every 500 ft altitude above sea level, the building codes. Hotsy can only make recommendations boiling point of water goes down 1 °F. At high altitude and the selection of the venting must take into account... -
Page 14: Operation Instructions
2. If burner was used, turn OFF burner switch and allow pump to run cold water through coil for several Manual Trigger Lock minutes. MANUAL, OPERATOR, HOTSY, STAT ELECTRIC, OIL 8.916-831.0 - D... -
Page 15: Cleaning Techniques
• Produits à base de tripolyphosphate de sodium garantie du fabricant. • Ammoniac ou produits à base d'acide These chemicals will harm the machine and will damage the surface being cleaned. MANUAL, OPERATOR, HOTSY, STAT ELECTRIC, OIL 8.916-831.0 - D... -
Page 16: Maintenance
Ce dispositif de sécurité doit être inspecté et testé une fois par année. NOTE: This valve must be inspected and tested annually by a certified Hotsy technician. Unloader Valve WARNING: The unloader valve on this pressure Proper Pump Care: washer has been factory set and sealed and is a field nonadjustable part. -
Page 17: Troubleshooting
Fuel Pressure is too high for clean burn (fuel PSI above 140 and Reduce fuel pressure PSI/Increase air band set for below 200) and smokes when cleaner without max water heat loss burner is off MANUAL, OPERATOR, HOTSY, STAT ELECTRIC, OIL 8.916-831.0 - D... - Page 18 If you need SERVICE on your pressure washer, contact your local Hotsy dealer or visit www.Hotsy.com. Smart phone users scan the code below to link directly to the Service Request page. To REGISTER your pressure washer, please visit our Warranty Registration page at www.hotsy.com/WarrantyRegistration.aspx or scan the code...
