  • Page 1 All manuals and user guides at all-guides.com Operating Instructions Non-Contact Safety Switch CES-AH-C03-AH-SM (Unicode)

  • Page 2: Table Of Contents

    Carrying out teach-in for a new actuator ................15 9.3. Functional check ...........................16 System status table .................... 17 Technical data ....................18 11.1. Technical data for safety switch CES-AH-C03-AH-SM ................18 11.2. Typical system times ........................19 11.3. Dimension drawing ........................20 (translation of the original operating instructions) 106595-08-03/17...
  • Page 3 All manuals and user guides at all-guides.com Operating Instructions Non-Contact Safety Switch CES-AH-C03-AH-SM 11.4. Technical data for actuator CES-A-BBA/CES-A-BCA ................21 11.4.1. Dimension drawing CES-A-BBA ..................21 11.4.2. Dimension drawing CES-A-BCA ..................21 11.4.3. Switching distances ......................22 11.5. Technical data for actuator CES-A-BPA ....................23 11.5.1.

  • Page 4: About This Document

    1. About this document 1.1. Scope These operating instructions are valid for safety switch CES-AH-C03-AH-SM. These operating instructions, the document “Safety information and maintenance” and any enclosed data sheet form the complete user information for your device. 1.2. Target group Design engineers and installation planners for safety devices on machines, as well as setup and servicing staff possessing special expertise in handling safety components.

  • Page 5: Correct Use

    EN 60204-1, Safety of machinery – Electrical equipment of machines. The safety switch is only allowed to be operated in conjunction with the intended EUCHNER CES actuators and the related connection components from EUCHNER. On the use of different actuators or other connection components, EUCHNER provides no warranty for safe function.

  • Page 6: Description Of The Safety Function

    All manuals and user guides at all-guides.com Operating Instructions Non-Contact Safety Switch CES-AH-C03-AH-SM Table 1: Possible combinations for CES components Actuator Safety switch CES-AH-C03-... Combination possible, typ. switch-on distance 20 mm Combination possible, guard locking for process protection Key to symbols...

  • Page 7: General Safety Instructions

    Prior to use, read the operating instructions and keep these in a safe place. Ensure the operating instructions are always available during mounting, setup and servicing. EUCHNER cannot provide any warranty in relation to the readability of the CD for the storage period required. For this reason you should archive a printed copy of the operating instructions.

  • Page 8: Function

    All manuals and user guides at all-guides.com Operating Instructions Non-Contact Safety Switch CES-AH-C03-AH-SM 6. Function Safety switch CES-AH-C03-AH-SM complies with the following safety requirements: Ì Category 3 according to DIN EN ISO 13849-1 Ì This means that the safety system still functions even if an internal component fails Ì...

  • Page 9: Mounting

    All manuals and user guides at all-guides.com Operating Instructions Non-Contact Safety Switch CES-AH-C03-AH-SM 7. Mounting CAUTION Risk of damage to equipment as a result of incorrect installation. Safety switches must not be used as a mechanical end stop. Ì Fit an additional end stop for the movable part of the safety guard.

  • Page 10: Electrical Connection

    All manuals and user guides at all-guides.com Operating Instructions Non-Contact Safety Switch CES-AH-C03-AH-SM 8. Electrical connection 8.1. General notes CAUTION Risk of damage to equipment or malfunctions as a result of incorrect connection. Ì To avoid faults, the cable must be laid with protection.

  • Page 11: Safety In Case Of Faults

    All manuals and user guides at all-guides.com Operating Instructions Non-Contact Safety Switch CES-AH-C03-AH-SM DANGER Danger due to automatic start/restart. An automatic start/restart can occur: Ì On closing the safety guard Ì On switching on the power supply Ì On automatic restart after the detection of a fault Ì...

  • Page 12: Connection Cables And Plug Connectors

    Ì Use EUCHNER connectors. Ì If other connection components are used, the following recommendations apply. EUCHNER pro- vides no warranty for safe function in case of failure to comply with these requirements. Ì The maximum cable length should not exceed 50 m.

  • Page 13: Connector Assignment

    All manuals and user guides at all-guides.com Operating Instructions Non-Contact Safety Switch CES-AH-C03-AH-SM 8.9. Connector assignment View of connection side Figure 1: Connector assignment of safety switch CES-AH-C03-AH-SM Designation Description Not used * Start Start input Safety output, channel 1...

  • Page 14: Connection Example

    All manuals and user guides at all-guides.com Operating Instructions Non-Contact Safety Switch CES-AH-C03-AH-SM 8.10. Connection example Within the device, the shutdown of the two outputs LA and LB is dual-channel. As such, each of the outputs represents a separate safety output.

  • Page 15: Setup

    All manuals and user guides at all-guides.com Operating Instructions Non-Contact Safety Switch CES-AH-C03-AH-SM 9. Setup 9.1. LED indicators Color State Significance illumi- Normal operation nated STATE green Teach-in operation or power-up flashing (for further signal function see status table) illumi-...

  • Page 16: Functional Check

    All manuals and user guides at all-guides.com Operating Instructions Non-Contact Safety Switch CES-AH-C03-AH-SM 9.3. Functional check After installation and any fault, the safety function must be fully checked. Proceed as follows: WARNING Danger of fatal injury as a result of faults in installation and functional check.

  • Page 17: System Status Table

    All manuals and user guides at all-guides.com Operating Instructions Non-Contact Safety Switch CES-AH-C03-AH-SM 10. System status table LED indicator, output Operating mode State 10 Hz Self-test Self-test after power-up (3 s) closed Normal operation, door closed Normal operation open Normal operation, door open...

  • Page 18: Technical Data

    11. Technical data NOTICE If a product data sheet is included with the product, the information on the data sheet applies in case of discrepancies with the operating instructions. 11.1. Technical data for safety switch CES-AH-C03-AH-SM Value Parameter Unit min.

  • Page 19: Typical System Times

    All manuals and user guides at all-guides.com Operating Instructions Non-Contact Safety Switch CES-AH-C03-AH-SM 11.2. Typical system times Please refer to the technical data for the exact values. Ready delay: After switching on, the unit carries out a self-test. The system is ready for operation only after this time.

  • Page 20: Dimension Drawing

    All manuals and user guides at all-guides.com Operating Instructions Non-Contact Safety Switch CES-AH-C03-AH-SM 11.3. Dimension drawing Read surface LEDs 23,3 45,5 (translation of the original operating instructions) 106595-08-03/17...

  • Page 21: Technical Data For Actuator Ces-A-Bba/Ces-A-Bca

    All manuals and user guides at all-guides.com Operating Instructions Non-Contact Safety Switch CES-AH-C03-AH-SM 11.4. Technical data for actuator CES-A-BBA/CES-A-BCA Parameter Value Unit min. typ. max. Housing material - CES-A-BBA Fortron, reinforced thermoplastic, fully encapsulated - CES-A-BCA PE-HD plastic without reinforcement, fully encapsulated...

  • Page 22: Switching Distances

    All manuals and user guides at all-guides.com Operating Instructions Non-Contact Safety Switch CES-AH-C03-AH-SM 11.4.3. Switching distances Operating distance for center offset m = 0 (only in combination with actuator CES-A-BBA/CES-A-BCA) Parameter Value Unit min. typ. max. Switch-on distance Assured switch-on distance s...

  • Page 23: Technical Data For Actuator Ces-A-Bpa

    All manuals and user guides at all-guides.com Operating Instructions Non-Contact Safety Switch CES-AH-C03-AH-SM 11.5. Technical data for actuator CES-A-BPA Parameter Value Unit min. typ. max. Housing material Dimensions 40 x 40 x 10 Weight 0.025 Ambient temperature - 25 + 70 °C...

  • Page 24: Switching Distances

    All manuals and user guides at all-guides.com Operating Instructions Non-Contact Safety Switch CES-AH-C03-AH-SM 11.5.2. Switching distances Operating distance for center offset m = 0 (only in combination with actuator CES-A-BPA on surface mounting) Parameter Value Unit min. typ. max. Switch-on distance...

  • Page 25: Technical Data For Actuator Ces-A-Brn

    All manuals and user guides at all-guides.com Operating Instructions Non-Contact Safety Switch CES-AH-C03-AH-SM 11.6. Technical data for actuator CES-A-BRN Parameter Value Unit min. typ. max. Housing material Dimensions 80 x 40 x 15 Weight 0.06 Ambient temperature - 25 + 70 °C...

  • Page 26: Switching Distances

    All manuals and user guides at all-guides.com Operating Instructions Non-Contact Safety Switch CES-AH-C03-AH-SM 11.6.2. Switching distances Operating distance for center offset m = 0 (only in combination with actuator CES-A-BRN) Parameter Value Unit min. typ. max. Switch-on distance Assured switch-on distance s...

  • Page 27: Ordering Information And Accessories

    106 597 Tip! Suitable accessories, e.g. cables or assembly material, can be found at www.euchner.de. To order, enter the order number of your item in the search box and open the item view. Accessories that can be combined with the item are listed under “Accessories”.

  • Page 28: Declaration Of Conformity

    All manuals and user guides at all-guides.com Operating Instructions Non-Contact Safety Switch CES-AH-C03-AH-SM 15. Declaration of conformity (translation of the original operating instructions) 106595-08-03/17...
  • Page 29 All manuals and user guides at all-guides.com Operating Instructions Non-Contact Safety Switch CES-AH-C03-AH-SM 106595-08-03/17 (translation of the original operating instructions)
  • Page 30 All manuals and user guides at all-guides.com Operating Instructions Non-Contact Safety Switch CES-AH-C03-AH-SM (translation of the original operating instructions) 106595-08-03/17...
  • Page 31 All manuals and user guides at all-guides.com Operating Instructions Non-Contact Safety Switch CES-AH-C03-AH-SM 106595-08-03/17 (translation of the original operating instructions)
  • Page 32 Edition: 106595-08-03/17 Title: Operating Instructions Non-Contact Safety Switch CES-AH-C03-AH-SM (translation of the original operating instructions) Copyright: © EUCHNER GmbH + Co. KG, 03/2017 Subject to technical modifications; no responsibility is accept- ed for the accuracy of this information.
