1.2 LED Display

N O LABEL
1 Water Pump
2 Night Mode
3 Load
4 Fresh Water Tank
5 Tap Water Tank
6 Waste Water Tank
7 Service Battery
8 Service Battery
N LABEL
O
1 Main
2 PV
3 Fault

1.3 Water Tank Probes

A maximum of up to 3 probes can be monitored by the system.
NOTE: Always check the probe required for the water tank before purchase. If the probe included does not fit the water tank,
please contact the seller.
There are 2 probe styles:
PMWS200:
• Side installation
• Suitable for water tank
• Depth >200mm
6
4 5
1
Table 1 Front panel of PMSWLED-2
DEFINITION
DC load control
Scene mode
DC load control
Sensor
Sensor
Sensor
SOC
Voltage
Table 2 LED indication of PM235
COLOUR STATUS
ON
Green Flash
OFF
Solid
Green Flash
OFF
ON
1 Flash
2 Flash
Red 3 Flash
4 Flash
5 Flash
6 Flash
Figure 4 PMWS200
6 7 8
2 3
DESCRIPTION
Load control, on/off control
Refer to 2.10
Load control, on/off control. Refer to 2.7
Detect the level of fresh water tank
Detect the level of tap water tank
Detect the level of waste water tank
Detect the state of the charge of service battery
Detect the voltage of service battery
DESCRIPTION
Battery charged or power supply mode
Battery charging under grid electricity
NO AC input
Battery charged
Battery charging under solar energy
NO solar input / AC charging / Aux charging
Short circuit
Service battery voltage low
Service battery voltage high
Over temp (heat sink)
Bulk charge timeout
VCR anomaly
Over temp (environment)
PMWS400:
• Side installation
• Suitable for water tank
• Depth 300-400mm
Figure 3 PMSWLED-2 switch panel
Figure 5 PMWS400
