Installation:
PM235 can be installed on a horizontal surface or vertically on a wall. Please see following instructions:
Figure 10 Installation of PM235 (Unit: mm)
3.2 LED Display
10
35
128 55
Figure 9 Dimension of PM235 (Unit: mm)
23.62
150
90
Figure 11 Dimension of PMSWELD (Unit: mm)
300
264
Ensure clearance on both sides of PM235 unit
upon installation. A recommended clearance of
5cm on each side.
7.97
M4
164
