7. TROUBLE SHOOTING

7.1 L.E.D Display on PM235 Unit
No. LED
1 Mains
2 Str Bat
3 PV
4 Fuse L.E.D
5 FAULT
Table 17 Error LED indicator of PM235
18
COLOUR STATUS
GREEN Quick Flashing
(flash twice every second)
GREEN Quick Flashing
(flash twice every second)
GREEN Quick Flashing
(flash twice every second)
RED OFF
ON
1 Flash
2 Flash
3 Flash
RED
4 Flash
5 Flash
6 Flash
8 Flash
DESCRIPTION
AC input abnormal
The Starter Battery is 2~13.4V or >16.0V, while AC
power is connected.
Solar input voltage error – Solar input >30Vdc
Fuse blown, need to check load and replace fuse
Short circuit
Service battery voltage low
Service battery voltage height
Over temp (heat sink)
Bulk charge timeout
VCR anomaly
Over temp (environment)
BMS Over-Voltage Protection
