System Pressures
Technicians with R-22 experience will need to become familiar working with high and low
side pressures that are much higher when using R-410A. A typical R-22 system operates
normally with a high side pressure of approximately 260 psi @ 120°F condensing
temperature, and a low side pressure of approximately76 psi @ 45°F evaporator
saturation temperature.
A normally operating R-410A system with the same condensing temperature of 120°F and
45°F evaporator saturation temperature will have a high side pressure of approximately
500 psi, and a low side pressure of approximately 150 psi.
• 5/16" socket or drive (most screws are 5/16" hex head)
• 1/4" socket or drive (ground screws and control assembly use 1/4" machine thread screws)
• 3/8" socket or drive (for outdoor fan blade removal)
• 4 mm Allen wrench (for indoor fan blade removal)
• Volt-Ohm meter
• Amp probe
• Needlepoint meter leads
• Sealed system and R-410A recovery equipment
• Thermal paste - WX5X8927
• Extension needed for condenser shroud screws
• Voltage rated pliers (for discharging the capacitor)
Additional Safety Requirements

Tools Required
