DEMO MANUAL DC2142A
Quick start proceDure

parts List

ITEM QTY REFERENCE
Required Circuit Components
1 8 CIN1, CIN2, CIN3, CIN4, CIN5, CIN6,
CIN7, CIN8
2 14 COUT1, COUT2, COUT6, COUT7,
COUT9, COUT12, COUT13, COUT14,
COUT19, COUT20, COUT24, COUT25,
C39, C40
3 12 COUT3, COUT4, COUT5, COUT8,
COUT10, COUT11, COUT15, COUT16,
COUT17,COUT18, COUT22, COUT23
4 3 C3, C25, C29
5 2 C1, C2
6 4 C4, C30, C31, C46
7 1 C5
8 5 C7, C8, C18, C32, C36,
9 6 C10, C12, C20, C24, C33, C35
10 1 C15
11 1 C16
12 1 C34
13 1 D1, D2, D3, D4
14 4 L1, L2, L3, L4
6
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
Figure 7. Transient Performance at V
PART DESCRIPTION
CAP, 1210, 10µF, 20%, 35V X5R
CAP, 1210, 100µF, 20%, 6.3V X5R
CAP, 7343, 330µF, 20%, 6.3V POSCAP
CAP, 0603, 1µF, 20%, 25V X5R
CAP, 270µF, 20%, 16V OSCON
CAP, 0603, 4.7µF, 10%, 10V X5R
CAP, 0603, 10nF, 10%, 16V X7R
CAP, 0603, 0.1µF, 10%, 25V X5R
CAP, 0603, 220nF, 10%, 25V X7R
CAP, 0603, 220pF, 5%, 50V C0G
CAP, 0603, 2.2nF, 5%, 50V C0G
CAP, 0603, 100pF, 10%, 16V X7R
DIODE, SCHOTTKY 30V, 100mA
IND, 0.25µH
V (20MHz BW) [20mV/DIV]
OUT
30A TO 60A LOAD STEP
= 12V, V = 1.0V, I = 30A ~ 60A
IN OUT OUT
MANUFACTURER/PART NUMBER
AVX 1210DD106MAT2A
TDK C3225X5R0J107M
SANYO 6TPF330M9L
AVX 06033D105KAT2A
PANASONIC 16SVPC270M
AVX 0603ZD475KAT2A
AVX 0603YC103KAT2A
AVX 06033C104KAT2A
TDK C1608X7R1E224K
AVX 06035A221JAT2A
MURATA GRM1885C1H222JA01D
AVX 0603YC101KAT2A
CENTRAL SEMI CMDSH-3-TR
WÜRTH ELEKTRONIK 744301025
