TDK-Lambda ZWS10C Series Instruction Manual page 14

7-3. Output Derating according to the Input Voltage
Load (%) is percent of maximum output current value in a rated output voltage.
In addition, the input derating curve must be considered, refer to section 7-2. Output Derating curve according to
the Mounting Direction.
ZWS50C
12V/15V/24V/48V
100
80
60
40
20
0
85 105 125 145
7-4. Mounting Method
7-4-1. Mounting method for standard model
Insert the spacer (Maxφ6.2mm) of height more than 8mm to lift the unit. And use all mounting holes for the unit
installation. The vibration spec is specified under this mounting condition.
Recommended torque for mounting screw: M3 screw, 0.59N·m (6.0 kgf · cm).
■ Mounting Holes size
ZWS10C, ZWS15C : 2 HOLES φ3.5mm
ZWS50C : 4 HOLES φ3.5mm
165 185 205 225 245
Input Voltage(VAC)
Height more than 8.0mm
Height more than 8.0mm
<Page> 14/20
Input Voltage(VAC)
85
90 to 265
265
Height more than 8.0mm
ZWS30C : 4 HOLES φ3.5mm
