Operation guide
3.

Technical data

© Danfoss | 2023.12
Installation, Operation and Maintenance Manual for PAHT 20-90 pumps
It is always the system builders´ responsibility
that the system design does not cause any kind
of hazard and is adapted to local regulations and
standards.
Proper installation, proper start up and shut-
down devices as well as high-pressure protection
equipment is essential.

2.3 Commissioning and servicing the unit

It is recommended that commissioning and
servicing are carried out by a minimum of two
people, where one is acting as a supervisor.
2.4 Adhere to the following important
points
• Before using the pump/pump unit it is very
important to read and understand this user
manual.
3.1 Approved applications and operational
limits for the pumps
The pump and the pump units are designed for
the use in systems with technical water.
The PAHT pumps must not be used for other
purposes than those recommended and
speci ed without rst consulting your local
pump distributor.
Use of the pump in other applications not
suitable for the pump unit can cause damages
to the pump unit, with risk of personal injury.
For system integration of the pumps, please
see appendix 1, Data sheet and appendix 2,
Instruction.
• Do not try to lift the pump unit manually;
most of the pumps weigh more than
20 kilos, see speci c weight for the pump
in the appendix 1, Data sheet.
• Always bleed the pump prior to initial
start-up.
• Do not mount the pump without the bell
housing and a exible coupling.
• Do not try to start the unit before the
system components are mounted, bleeded
and adjusted.
• Flush the system throughly before
connecting the pump or pump unit.
• Check rotation direction of the motor
before mounting the pump.

2.5 In case of doubt

Please contact Danfoss A/S in case of doubt.
Contact information are listed in section 1.3,
Manufacturer and customer service address.

3.2 Application range

See appendix 1, Data sheet.

3.3 Electric motor data

See recommended motor in appendix 1, Data
sheet or appendix 3, IOM for motors. The motors
mentioned are the most common used motors
by Danfoss High Pressure Pumps.

3.4 Noise and vibration

Noise level for a pump unit with a "standard"
motor measured according to EN ISO 3744:2010,
see appendix 1, Data sheet. Possibilities to
reduce noise and vibration are described in the
same Data sheet.

3.5 Dimension drawings

Dimensions of the di erent pumps can be found
in appendix 1, Data sheet.

3.6 Space requirement

When doing service or replacing the complete
pump unit, it is recommended to have su cient
space available around the pump in order to
ensure easy access. Su cient space means at
least 1 meter/40 inches around the pump. When
working with high pressures, it is important to
have the right space available around the pump
as stated in the safety requirements.
180R9288_AQ109686503100en-001301 | 7
