TECHNICAL SPECIFICATIONS

AD Converter: 24 Bit @ 48 kHz 125 dB–A Dynamic Range – 0.00x % THD+N
Audio
Crosstalk (1 kHz) – 60 dB
DA Converter: 24 Bit @ 48 kHz 115 dB–A Dynamic Range – 0.00x % THD+N
Max output level 1.44 Vrms
2.5 ms end–to–end latency
AES67 network audio (with optional encryption)
Connectivity 1 x Front panel accessible Microphone input
1 x Rear Aux microphone station input
2 x Balanced audio output
2 x Protected GPIO
1 x USB–A
2 x LAN RJ45 1000 Mbps with PoE
Built–in web–based graphical DSP pipeline designer
DSP
60+ Component library
Extended precision fixed point processing
API library
User Interface 8" Capacitive touch screen, (1920 x 1200) WUXGA
Web–based interface
Cloud–connected
Secure boot
Security
Encrypted firmware
Tamper sensing
Secure enclave chip
AES256–GCM encryption for AES67
Onboard microSD card slot, included 32 GB card
Storage
Environmental Operating temperature range 32 °F – 122 °F (0 °C – +50 °C)
Storage temperature range 14 °F to 140 °F (–10 °C – +60 °C)
Power IEEE 802.3af power over Ethernet (PoE), Power consumption: typical 8 W, max 15 W
290 mm (W) x 27 mm (D) x 145 mm (H) (without Desk Stand)
Dimensions
1 630 g without mounting kit
Wall mount
Accessories
Handheld microphone
Desk Stand (optional)
Micnode AUX Station (optional)
