Announcement Triggering
Once the network settings and configuration including zones are set in Q-Sys designer, Live paging can be triggered with
the PTT button.
IMPORTANT: Which mode is used depends on Paging configuration of your micnode2 device in Q-Sys designer.
A. Select zone/s:
• Green zones are
selected for paging,
• Grey are not
selected for paging.
B. Talk/Start button
Press the Talk/Start button on the microphone side.
Using Q-Sys UCI
To use a Q-Sys UCI for paging from the micnode2 device, create the UCI parameters in Q-Sys designer.
1. Create your UCI (User Control Interface) and drag and drop the buttons from the plugin.
2. In Q-Sys Core Manager find in section System management / User Control Interfaces your UCI:
a. Click in right upper corner on Open UCI in New Window – new window opens,
b. Copy the UCI URL,
3. Paste the URL back Q-Sys designer in micnode2 configuration or in nnounce configuration UI in section Device
interface, see more in chapter Extern application configuration below.
:
IMPORTANT UCI shall be designed for resolution 1920 x 1200 resolution.
Using External Application Configuration
You can add any external web application which will manage the paging process from your micnode2 paging station.
1. Open the nnounce configuration UI.
2. Navigate in the left-hand Menu to the Device interfaces section.
