1. Model name identification method
ZWS 10C - 5 /
2. Terminal Explanation
ZWS10C/ZWS15C
CN1
1
L
3
INPUT
OUTPUT
1
2 N
CN2
3
4
1 L : Input terminal Live line (Fuse in line) (CN1)
2 N : Input terminal Neutral line (CN1)
: Earth ( ) Terminal (CN2)
3
Mounting hole (hole diameter : φ3.5mm)
4
This hole is electrically connected to terminal of CN2.
The mounting surface of the spacer should be within Maxφ6.2mm.
Mounting hole (hole diameter : φ3.5mm)
5
These holes are used for support the unit.
6 + : + Output Terminal (CN51)
– : – Output Terminal (CN51)
7
□
Option (*1)
Rated Output Voltage
Series Name
Output Power type
Series Name
5
CN51
7
-
1
+
2
6
COMPONENT SIDE
<Page>
(*1) Blank : Standard type.
/L
/A
/CO2 : With coating on both sides of
ZWS30C
5
CN1
1
L
3
INPUT
1
N
2
CN2
3
4
