Hardware Installation and Reference Guide
1.3.4

Cooling

The S6930-2C adopts the front-to-rear airflow. Air flows in through the ports and out through the power module,
as shown in Figure
Caution

Maintain a minimum clearance of 200 mm (7.87 in.) around the equipment for air circulation.

At least seven fan modules are required. If any slot is unoccupied, install a filler panel to enable proper
airflow and to keep dust out of the chassis.

Dust the equipment every three months to avoid blocking the ventilation openings on the housing.
Figure 1-5 Front-to-Rear Airflow
1.3.5

Technical Specifications

Table 1-7 Technical Specifications
Class
Technical
indicators
Physical
characteristics
1-5.
Item Specification
CPU 2.9 GHz quad-core
Memory 16 GB, DDR4 (compatible with 32 GB)
Flash memory NOR flash:
SSD 240 GB
Dimensions
(W x D x H)
Weight
16 MB (for BootROM)
Without packing materials: 442 mm x 760 mm x 175 mm
(17.40 in. x 29.92 in. x 6.89 in., 4 RU)
With packing materials: 600 mm x 980 mm x 407 mm (23.62
in. x 38.58 in. x 16.02 in.)
Chassis and modules (eight fan modules and four power
modules) without packing materials: 33.55 kg (73.97 lbs.)
Chassis and modules (eight fan modules and four power
modules) with packing materials: 43.15 kg (95.13 lbs.)
7
Overview
