4. Technical Specifications
Table 1-15 Technical Specifications
Class
Physical
characteristics
Ports
Power supply
Reliability
1.5

Power Module

The smart power module for the RG-S6930-2C supports power consumption management and hot swapping. It
can obtain the output power, output current, and operating temperature in real time.
Caution

To improve system stability and availability, you are advised to configure 2+2 power redundancy. The
chassis configured with power redundancy works in current-sharing mode.

At least two power modules are required. If any slot is unoccupied, install a filler panel to enable proper
airflow and to keep dust out of the chassis.

Unplug the power cord before installing or removing the power module.
LED Description
Solid green: The port made a successful 100/200 Gbps link.
Blinking green: The port is sending and receiving traffic at 100/200
Gbps.
Off: No link is detected for the port.
QSFP28 port
LED
Item
Dimensions (W x
D x H)
Net weight
Port density
Max. power
consumption
Hot swapping
Caution
The QSFP28 port can be split or aggregated, as shown in

When a port split from the QSFP28 port has made a successful
link, the LED is solid green. When a port split from the QSFP28
port is sending and receiving traffic, the LED is blinking green.

If the aggregated QSFP28 port is available, the LED indicates
the status of the 200GE QSFP28 port. If not, the LED is off.
Specification
Without packing materials: 399.6 mm x 398.6 mm x 66.4 mm
(15.73 in. x 15.69 in. x 2.61 in.)
With packing materials: 590 mm x 555 mm x 238 mm (23.23
in. x 21.85 in. x 9.37 in.)
10.65 kg (23.48 lbs.)
72 x 100GE QSFP28 ports. See
and splitting.
1,092 W
Supported
16
Table
Table 1-13 for port aggregation
Overview
1-9.
