2-Way LCD Paging Alarm & Remote Engine Starting System
CONGRATULATIONS on your choice of the SP-500 by Crimestopper Security Products Inc. This booklet contains the
information necessary for operating your system.
Crimestopper Security Products Inc.
*IMPORTANT INFORMATION: Primary and Optional Features
-PRIMARY: These features must be connected in order for the system to operate properly i.e. Power, Ground, LED,
etc.
-OPTIONAL: Optional features are connected only if desired or agreed upon by the installing dealer i.e. Horn Honk,
Dome light illumination, Door Locks, Trunk Pop, etc. These features may require additional parts and labor charges.
Consult with your installer about these features BEFORE installation!
CONTACT INFORMATION:
TECHNICAL SUPPORT (800)-998-6880
Monday - Friday 8:00am - 4:30pm Pacific
Website: www.crimestopper.com
CRIMESTOPPER
SECURITY PRODUCTS, INC.
1770 S. TAPO STREET
SIMI VALLEY, CA. 93063
SP-500
OPERATING INSTRUCTIONS
INTRODUCTION
REV 12.2008
If any questions arise, contact your installation dealer or
This device complies with FCC Rules part 15. Operation is subject
to the following two conditions: 1) This device may not cause
interference, and (2) this device must accept any interference that
may be received, including interference that may cause undesired
operation. The manufacturer is not responsible for any radio or TV
interference
caused
by
equipment. Such modification could void the user's authority to
operate the equipment.
unauthorized
modification
to
this
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for CrimeStopper SP-500
Summary of Contents for CrimeStopper SP-500
-
Page 1: Operating Instructions
2-Way LCD Paging Alarm & Remote Engine Starting System OPERATING INSTRUCTIONS CONGRATULATIONS on your choice of the SP-500 by Crimestopper Security Products Inc. This booklet contains the information necessary for operating your system. Crimestopper Security Products Inc. *IMPORTANT INFORMATION: Primary and Optional Features -PRIMARY: These features must be connected in order for the system to operate properly i.e. -
Page 2: Table Of Contents
Battery Replacement……………….……………………..………….….…………………………………………….20 OPERATION CAUTIONS & WARNINGS CRIMESTOPPER SECURITY PRODUCTS, INC. and its VENDORS shall not be liable for any accident resulting from the use of this equipment. This system is designed to be professionally installed into a car or vehicle in good running order. Items, such as parking brake, door switches, and all engine safety features, must be in perfect working condition. -
Page 3: The Remote Controls
2-WAY - PAGER / REMOTE TRANSCEIVER: 12:00 DISARM / ARM / UNLOCK LOCK THE REMOTE CONTROLS START / AUX 2 ARM / LOCK 2nd FUNCTION VEH 1 / VEH 2 START CLOCK SET TRUNK 1-WAY - SIDEKICK REMOTE: DISARM / UNLOCK 2nd FUNCTION VEH 1 / VEH 2... -
Page 4: Setting The Clock
1-WAY - SIDEKICK REMOTE: The 1-Way sidekick remote adds flexibility to your system. You can have the convenience of operating your system without needing to carry the larger pager remote. The Sidekick remote has less range and offers all of the same operation features except for page-back confirmation. -
Page 5: Quick Chart Button Functions
QUICK CHART BUTTON FUNCTIONS Button Button Functions Lock Doors & Arm System Unlock Doors & Disarm System Trunk Pop Aux # 1 Start or Stop engine Then Activates Aux #2 Then Activates Aux #3 Then No Function Then Activates Aux #4 CLOCK SETUP: Lock = Increase, Unlock = Decrease, Trunk = Next, Start = Beep with button press, VEH = Exit Button Options... -
Page 6: Operating Instructions - Alarm
OPERATING INSTRUCTIONS - ALARM Arming / Locking: Press the Lock Button on the remote control. The System will arm emit one siren chirp, one light flash, and the LED will begin to flash. Power locks will lock (if equipped). Starter disable circuit will turn on. The 2-Way LCD Pager will beep once while displaying a Locking symbol. - Page 7 OPERATING INSTRUCTIONS - ALARM Prior intrusion Alert This system will notify you if the alarm was triggered while you were away. Upon disarming, there will be four additional siren chirps after the two normal disarm chirps. Check your vehicle for any signs of a break in or tampering.
- Page 8 OPERATING INSTRUCTIONS - ALARM Passive Locking: (Programmable) The system can be programmed to passively lock the doors when the system passively arms. The default setting is OFF because passive locking increases the risk of locking the keys in the vehicle when the system arms/locks passively, without you pressing the remote.
-
Page 9: Operating Instructions - Alarm
OPERATING INSTRUCTIONS - ALARM Dome Light Illumination (Optional) This feature will turn on the vehicle’s dome light upon disarming for 30 seconds or until the key is inserted and turned on. This will provide illuminated entry to your vehicle in dimly lit areas for safety and security. Emergency Override (Disarm) If you have lost the transmitter or it stops working for any reason and the Alarm is armed, you will have to disarm the system manually. -
Page 10: Remote Engine Control
REMOTE ENGINE CONTROL REMO Remote Start & Auxiliary Output – Button Press Selection (Option # 8): To eliminate the possibility of accidentally opening the trunk or starting the vehicle, there are (3) options for button press selection. This option will allow you to change whether the Remote starter and Trunk release activate by a: 4. - Page 11 UNSUCCESSFUL REMOTE START In the event that the engine does not start on the first attempt, the system shuts down for a few seconds, then attempts to restart the engine a 2 time of up to13 seconds maximum. This should provide ample cranking time for difficult starts, but is limited to 13 seconds to help prevent damage to the starter from over cranking.
- Page 12 IDLE DOWN MODE (TAKE-OVER OPERATION) This mode allows the unit to take over operation of your idling, parked vehicle while the ignition key is removed and you exit the vehicle. The vehicle is put into a remote running condition before you exit and it will remain running for the programmed run time, until you return, or until the remote start button is pressed.
- Page 13 REMOTE ENGINE CONTROL TIMED SELF START MODE This mode allows the vehicle to be programmed to self-start every 4 hours and run for the programmed run time. This can be helpful during extremely cold conditions where engine or fluid freeze-up is a concern. !!THE VEHICLE MUST BE OUTDOORS OR IN A WELL VENILATED AREA!! TIMED SELF-START MODE –...
-
Page 14: Anti-Carjack Protection
ANTI CARJACK PROTECTION REMOTE OPERATED CARJACK PROTECTION This feature provides Active Carjack protection through the remote control. When the Ignition is on (vehicle is running), press and hold the #1 LOCK Button and #3 TRUNK Button for 2 seconds. The parking lights will flash 2 times and the LED will begin to flash rapidly to confirm the beginning of a Carjack countdown. -
Page 15: Led And Remote Start Diagnostics
LED DIAGNOSTICS The SP-500 system includes disarm diagnostics, through the BLUE LED light, that will help in determining what caused the last trigger of the alarm system. This is a valuable tool in determining how the vehicle was tampered with or if there is a false alarm problem in which case you can make the necessary adjustments to correct the problem. -
Page 16: Transceiver / Remote Control Programming
TRANSCEIVER / REMOTE CONTROL PROGRAMMING Note: All transmitter codes must be learned at time of programming!! The SP-500 learns up to 4 different transmitter codes. 1. Turn key to the ON position. (Pink wire must be connected.) 2. Press Programming button 4 times, then after a few seconds the unit flashes the parking lights 4 times. -
Page 17: Vehicle Operation
2 VEHICLE CONTROL Your remotes have the ability to control a second vehicle with a Crimestopper system installed. To set up the 2-Vehicle operation you must first program your remotes to Vehicle #2. Follow the “Transmitter Programming” steps (Pg. 16) at the second vehicle and learn YOUR remote, along with vehicle #2’s existing remotes. -
Page 18: Turbo Timer Mode
The optional Turbo Timer mode allows the CoolStart system to keep a Turbo or Turbo Diesel vehicle running for 1 to 5 minutes [selectively] after you remove the key and exit the vehicle. This is handy for turbo cool- down without the need for expensive turbo timers. This mode requires the use of an extra part called a momentary switch/button that is not included with the kit. - Page 19 SETTING THE TURBO TIMER RUN TIME RUNNING AND HOLD LIGHTS FLASH 1-5X CAUTION!! IF YOU PRESS THE TURBO TIMER BUTTON WHEN ENGINE IS NOT RUNNING IT WILL TRIGGER A REMOTE START! MAKE A NOTE OF THIS IF YOU HAVE CHILDREN. CONSIDER THIS WHEN CHOOSING A LOCATION FOR YOUR TURBO TIMER BUTTON.
-
Page 20: Battery Replacement
Phillips screws holding the back cover in place. Insert the new batteries with the (+) end toward the circuit board. Remove 2 Screws Crimestopper Security Products Inc. 1770 So. Tapo Street Simi Valley, CA 93063 ONLINE TECHNICAL SUPPORT (800) 998-6880 www.crimestopper.com...
