SERIES IV
RS900/RS901
RS999 FM FLASHBACK™
REMOTE ENGINE STARTING SYSTEM
INSTALLATION INSTRUCTIONS
To ease installation, we suggest that you READ THIS MANUAL and consider the following points before
beginning your installation:
BEFORE BEGINNING, check all vehicle manufacturer cautions and warnings regarding electrical service (AIR BAGS,
ABS BRAKES, ENGINE / BODY COMPUTER AND BATTERY).
PLAN OUT YOUR INSTALLATION and determine most suitable locations for all components to be placed. These
components include: the module itself, valet/program button, possible relays, and antenna/receiver (RS900/999FM only,
RS901 model does not include antenna or remotes.) Allow enough wire to create a service loop with strain relief, should
servicing be required. This will also allow easier access and mounting.
DAMAGE resulting from incorrect installation or failure to follow guidelines stated in this book will not be covered under
warranty and subject to repair or replacement charges.
USE A VOLT/OHM METER to test and locate all connections. Test Lights can damage a vehicle's computer systems.
ADDITIONAL PARTS, which are not included with this unit, may be needed for your particular vehicle. . These items may
include extra relays (Part#CS-402A), General Motors Anti-Theft System Bypass modules for Vats / Passkey® / Passlock®
Systems, (Part# CS-GMATA II) or Transponder Anti-Theft Adapter modules (Part # CS-TATA).
TECHNICAL SUPPORT: (800) 998-6880
Monday - Friday 8:00am - 4:30pm Pacific Std. Time
Web Site: www.crimestopper.com
E-mail: tech-support@crimestopper.com
CRIMESTOPPER SECURITY PRODUCTS, INC.
1770 S. TAPO STREET, SIMI VALLEY, CA. 93063
REV A - 8.2001
PRE-INSTALLATION CONSIDERATIONS
This device complies with FCC Rules part 15. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any interference that
may be received, including interference that may cause undesired
operation. The manufacturer is not responsible for any radio or TV
interference caused by unauthorized modifications to this equipment.
Such modification could void the user's authority to use the
equipment.
Advertisement
Table of Contents
Related Manuals for CrimeStopper RS900/RS901
Summary of Contents for CrimeStopper RS900/RS901
- Page 1 Monday - Friday 8:00am - 4:30pm Pacific Std. Time Web Site: www.crimestopper.com E-mail: tech-support@crimestopper.com CRIMESTOPPER SECURITY PRODUCTS, INC. 1770 S. TAPO STREET, SIMI VALLEY, CA. 93063 REV A - 8.2001 This device complies with FCC Rules part 15. Operation is subject to...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Pre-Installation Considerations…………….………...……...………………………………………………………Front Cover Cautions & Warnings…….………………….………..…..………………………………………………………………………2 Wiring……..……………………………………………...……………………………………………………………….…….3-5 Ignition Switch Wiring………………….…..………………………………………………………………………….………….6 Power Door Lock Wiring...……………………………………………………….………….……..…………...……..………7-8 Jumper Pin Diagram……………………….………………………………………………………………………………...……8 Improved “Smart Tachless”, Tach Reference, & Tach Finder Modes…………………………..…..……………………9-10 Transmitter / Transceiver Programming…………………………………………….…………………………...………...….11 2 Vehicle Operation.…………………………………….…………………………………..…………….………….…………12 Programming Options……...…………………………………….……………………………………….…………………12-15 Troubleshooting “Before You Call” Section……………..………………………………………….…………………...…….15 System Wiring Diagram……………………………………………………………………………………….………...………16 INSTALLATION CAUTIONS &... -
Page 3: Wiring
WIRING INSTRUCTIONS PROGRAM/OVERRIDE SWITCH: 2 PIN PLUG This switch is used for programming features, transmitters, valet mode, and to override the optional starter disable (if installed) in the event of a non-operating remote control. LED: 2 PIN PLUG The LED is used as a VALET/PROGRAMMING indicator and it will also FLASH for use as security deterrent when the optional ANTI-GRIND/STARTER DISABLE output is programmed. - Page 4 PIN 4: YELLOW/BLACK FOR NEGATIVE IGNITION OUTPUT: YELLOW/BLACK PIN 4: YELLOW/BLACK: FOR ANTI-GRIND/STARTER DISABLE OUTPUT: (Relay not included) IGN 1 IGN 2 MOTOR START WIRING INSTRUCTIONS 3rd IGN (If needed) BROWN YELLOW/BLACK MAKE CERTAIN TO CONNECT "BROWN" START OUTPUT WIRE TO MOTOR SIDE OF ANTI-GRIND/START DISABLE RELAY.
-
Page 5: Wiring
WIRING INSTRUCTIONS PIN 5: TAN: (-) AUX OUTPUT (TRUNK POP) This output will provide a ground pulse when button #3 (Trunk) on the remote transmitter is pushed to activate a factory electric trunk release or other optional accessory. Note: this is a momentary output that will stay on as long as the remote button is pressed and held. -
Page 6: Ignition Switch Wiring
6 PIN HIGH-CURRENT CONNECTOR: PIN 1: BROWN 14 GA.: STARTER OUTPUT (30A) PIN 2: GRAY 14 GA.: ACCESSORY / IGNITION 2 (30A) PIN 3: RED 12 GA.: BATTERY CONSTANT FUSED (30A) PIN 4: RED 12 GA.: BATTERY CONSTANT FUSED (30A) PIN 5: PINK 14 GA.: IGNITION (30A) PIN 6: PINK/WHITE 14 GA.: IGN 2 or ACC 2 (30A) (See Page 8) -
Page 7: Power Door Lock Wiring
3 PIN DOOR LOCK PLUG: PIN 1: GREEN: (-) Negative pulse for LOCK PIN 2: RED: +12V Coil Power for external relays TERM 86. PIN 3: BLUE: (-) Negative pulse for UNLOCK COMMON DOOR LOCK TYPES: Negative Trigger (-): Many Imports, Late Model Ford & General Motors Positive Trigger (+): Many GM, Chrysler/Dodge/Plymouth models: Reverse Polarity: Many Ford/Lincoln/Mercury, Dodge/Chrysler/Plymouth,... -
Page 8: Jumper Pin Diagram
REVERSE POLARITY DOOR LOCK WIRING GREEN BLUE MASTER SWITCH Jumper pins are used to change/configure the settings of the on board IGN2/ACC2 (PINK/WHITE) and the Parking Light (WHITE) output relays. Snap open the door on the top of the control module to access these jumper pins. CONTROL MODULE JP1 JUMPERS: ON BOARD IGN2/... -
Page 9: Improved "Smart Tachless", Tach Reference, & Tach Finder Modes
IMPROVED “SMART TACHLESS” MODE This RS900/901/999FM systems includes a unique voltage monitor system called “Smart Tachless” mode. This mode allows this unit to efficiently start an engine without the use of a tach signal wire. These modules actively monitor the voltage reference on the vehicle every time remote start is requested. - Page 10 TACH FINDER & TACH PROGRAMMING TACH FINDER MODE: This system now includes a Tach Finder mode to assist in locating a valid or viable tach source for your installation. Follow the Tach Finder steps to locate and /or verify a tach signal. When following the steps, the unit will begin to flash the parking lights if you have the Red/White wire connected to a valid tach source.
-
Page 11: Transmitter / Transceiver Programming
900 IV TRANSMITTER / 999FM TRANSCEIVER CODE LEARNING Transmitter/Transceiver Code Learning: (Excludes RS901) Note: All transmitter codes must be learned at time of programming!! The RS900 IV system allows storage of up to 4 different transmitter codes. 1. Open hood (ground the Gray hood pin wire if no hood pin is installed.) 2. -
Page 12: Vehicle Operation
An RS900 Series IV remote control can be used to Remote Start a second vehicle with an identical RS900 Series IV system installed. Follow these steps on Vehicle #2: 1) Open hood (ground the Gray hood pin wire if no hood pin is installed.) 2) Turn Key to the ON position. - Page 13 Option # Option Description Tach Learning Autolock with Ignition Door Lock Pulse Time Double Unlock Pulse OEM Interface Passive Starter Disable Horn Chirps on remote start ON or OFF Lock During and After Remote Start Abort Smart Tachless Reference Voltage Setting #9 Smart Tachless Reference Voltage Setting #10 NOT USED...
- Page 14 PROGRAMMABLE OPTIONS 2. Auto Lock/Unlock with Ignition: Controls whether the doors will automatically lock when the ignition is turned on and will unlock when turned off. 3. Door Lock Pulse Time: Controls the amount of time (0.75 sec. or 3 sec.) for the lock/unlock pulse. The standard setting is .75 which covers for most vehicles.
-
Page 15: Troubleshooting "Before You Call" Section
12. Yellow/Black (-) Negative IGN or ANTI-GRIND Output: This option controls the units Negative multi-function output. Default: It is a Negative IGN output that turns ON and stays on for the duration of the remote start. Use this wire to turn on Anti-theft bypass adapters for GM or Transponder systems. When changed to an Anti-Grind, this output activates and deactivates with Lock/Unlock buttons on the remote. -
Page 16: System Wiring Diagram
ENGINE TRANSMISSION COIL IGN2 / PARKING JUMPERS RS900/901 SERIES IV RS999FM ANTENNA/ RECEIVER PLUG ANTENNA (OPTIONAL) (-) UNLOCK OUTPUT PROGRAM +12 V FOR RELAYS SWITCH (-) LOCK OUTPUT NOTE: USE EXTERNAL RELAYS FOR HIGH-CURRENT FUEL PUMP H/V/AC CONTROL BROWN GRAY PINK PINK/WHITE BLACK...
