CrimeStopper LC-1 Installation Instructions Manual

Low current
Hide thumbs
Table of Contents

Advertisement

Quick Links

LC-1 / LC-3 / LC-4 / LC-7
LC-00 (
ADD-ON MODULE
LOW CURRENT
REMOTE START SYSTEM
CONGRATULATIONS on your choice of a "Cool Start" System with Data Port Technology for direct connection to bypass
module by Crimestopper Security Products Inc. This booklet contains the information necessary for installing your remote
starter system. If any questions arise, contact your installation dealer or Crimestopper Security Products Inc. at the Tech
Support number below.
Note: Some features will not be available on units with 1 button, 3 button, and 4 button remotes.
DISCLAIMER:
This installation book is designed for the installer or individual with an existing understanding of automotive electrical
systems, along with the ability to test and connect wires for proper operation. To ease installation, we suggest that you
READ THIS MANUAL before beginning your installation. This book is provided as a GENERAL GUIDELINE and the
information contained herein may differ from your vehicle. Crimestopper Security Products, Inc. and its' vendors shall not
be liable for any accident resulting from the use of this product. This system is designed to be professionally installed into
a vehicle in which all systems and associated components are in perfect working condition.
TECHNICAL SUPPORT: (800) 998-6880
Monday - Friday 8:00am - 4:30pm Pacific Std. Time
Web Site: www.crimestopper.com
E-mail: tech-support@crimestopper.com
CRIMESTOPPER SECURITY PRODUCTS, INC.
1770 S. TAPO STREET, SIMI VALLEY, CA. 93063
REV A 07-2014
)
INSTALLATION INSTRUCTIONS
This device complies with FCC Rules part 15. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any interference that
may be received, including interference that may cause undesired
operation. The manufacturer is not responsible for any radio or TV
interference caused by unauthorized modifications to this equipment.
Such modification could void the user's authority to use the
equipment.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LC-1 and is the answer not in the manual?

Questions and answers

Related Manuals for CrimeStopper LC-1

Summary of Contents for CrimeStopper LC-1

  • Page 1 CONGRATULATIONS on your choice of a “Cool Start” System with Data Port Technology for direct connection to bypass module by Crimestopper Security Products Inc. This booklet contains the information necessary for installing your remote starter system. If any questions arise, contact your installation dealer or Crimestopper Security Products Inc. at the Tech Support number below.

  • Page 2: Table Of Contents

    PLAN OUT YOUR INSTALLATION and determine most suitable locations for all components to be placed. These components include: the module itself, valet/program button, possible relays, and antenna/receiver (LC-1, LC-3, LC-4 and LC-7 only, the LC- 00 model does not include antenna or remotes.) Allow enough wire to create a service loop with strain relief, should servicing be required.

  • Page 3: Installation Cautions & Warnings

    INSTALLATION CAUTIONS & WARNINGS DO NOT extend the Remote start ignition harness length. Mount the module so that main harness reaches all ignition switch wiring. Extending these wires could result in poor or improper performance. DO NOT route any wiring that may become entangled with brake, gas pedals, steering column or any other moving parts in the vehicle.

  • Page 4: Parking Light Wiring

    WIRING – Parking Lights The Parking Light circuit can be connected up as a high current positive or negative trigger. Connect to vehicle parking light circuit at the back of light switch or if this is not possible, connect directly to one of the parking lights at the front of the vehicle.

  • Page 5: Pin Low Current Plug Wiring

    WIRING Low Current 12 Pin Plug YELLOW BLACK OUTPUT: Ground Out when Running (-) 500 milliamp The Ground Out when Running is required by some bypass modules. This wire turns on when the remote start button is pressed and stays on through the duration of the remote start. BROWN: (-) AUX OUTPUT (Trunk POP or Dome Light Illumination) This output is programmable for 2 modes of operation.
  • Page 6 WIRING Low Current 12 Pin Plug GRAY: (-) NEGATIVE HOOD PIN SWITCH Connect the Gray wire to a switch that is at ground when the hood is open. If an existing switch is not available, then we recommend one to be installed. When this wire is grounded, the remote start is inhibited. The unit will not attempt to start if hood is open.
  • Page 7 1. Remote Start thru data (green wire not connected). This feature only works on newer CANBUS vehicle using a Data Module that supports this feature. With this option you can use both the OEM and Crimestopper remote. 2. Connect the Green input wire to the Negative lock signal wire of the factory system. If your Factory OEM system does not have this type of signal, then a relay is required.

  • Page 8: Power Door Lock Wiring

    POWER DOOR LOCK WIRING CONNECTOR BLUE: (-) Negative pulse for UNLOCK Crimestopper Door Lock Accessories: RED: 12V When using external relays (TERM 86) CS-6600DLM: Dual-relay plug-in module for Reverse GREEN: (-) Negative pulse for LOCK Polarity, Positive, or Aftermarket Motors.
  • Page 9 BASIC DOOR LOCK DIAGRAMS NEGATIVE TRIGGER DOORLOCK WIRING POSITIVE TRIGGER DOORLOCK WIRING GREEN GREEN FUSED +12V BLUE BLUE FACTORY FACTORY POWER POWER LOCKING LOCKING RELAYS RELAYS REVERSE POLARITY DOOR LOCK WIRING AFTERMARKET MOTOR/DOOR LOCK WIRING GREEN GREEN FUSED FUSED +12V +12V BLUE BLUE...

  • Page 10: Smart Tachless And Tach Finder Mode

    “SMART TACHLESS” MODE Your CoolStart system includes a unique voltage monitor called “Smart Tachless” mode. This mode allows this unit to efficiently start an engine without the use of a tach signal wire. These modules actively monitor the voltage level of the vehicle to control the starter motor each time a remote start is requested.
  • Page 11 TACH FINDER & USEFUL TIPS TACH FINDER MODE: This Tach Finder mode can assist in locating a Tach source for your installation. When following the steps, the unit will begin to flash the parking lights if you have the Red/White wire connected to a tach source. If lights do not flash, then try another wire until you locate a tach signal that will cause the Parking lights to flash.

  • Page 12: Tach Programming

    TACH PROGRAMMING & TACH SIGNALS INTRODUCTION This system has 3 methods of monitoring the engine running. Option #1 controls how the system monitors the engine running. 1. Tach Reference Mode – Monitors Engine R.P.M. - Most reliable method, see Tach programming below. 2.

  • Page 13: Diesel Glow Plug Delay

    DIESEL GLOW PLUG DELAY This feature provides a solution for diesel vehicles without having to connect to the Glow Plug-Wait to Start Circuit. This may be needed for various reasons. If your vehicle does not have a viable Wait to Start Circuit, or you cannot locate and identify the circuit, then change your system to Diesel Glow Plug Delay mode.

  • Page 14: Option Programming Table

    Unlock, #3 Trunk, #4 Start. (Some option numbers use ALL 4 remote buttons to select settings) 5. For LC-00, LC-1: (No Lock button) Tap the brake pedal to toggle through the option values: Tap brake once (lights flash 1X) Tap the brake pedal again (Lights flash 2X) tap 3 or 4 times for options that have 3 or 4 values.
  • Page 15 Brown wire function Dome Light *Trunk pop* Unlock before Remote Start *OFF* (to Disarm OEM Alarm) Manual Manual Manual Transmission Transmission Type *OFF* Transmission set Transmission with with Remote Control with Hand Brake last door shut down Idle Down Timer 10 Minutes *20 Minutes* 30 Minutes...

  • Page 16: Option Descriptions

    Smart Phone baud rate 9600 (MS-3) 115200 Reset Options to Default (*) Reset Options 1 thru 25 (2 Flashes) OPTION DESCRIPTIONS 1. Engine Monitoring: This option controls how the system monitors the engine running. You can program for Tachless mode that monitors battery voltage, Tach mode in which the unit uses a Tach signal (RPM) or for Timed Crank as an alternative.
  • Page 17 OPTION DESCRIPTIONS 4. PINK / WHITE WIRE SELECTION: This option controls the Pink / White wire function. 1. Pink / White = Accessory 2 2. Pink / White = Ignition 2 - Default. 3. Pink / White = Start 2 5.
  • Page 18 OPTION DESCRIPTIONS 10. UNLOCK BEFORE REMOTE START: This option is used to disarm an OEM Alarm System before Remote Start. Default = OFF 11. TRANSMISSION TYPE: Requires Tach Wire connected and programmed This option selects automatic or manual transmission mode 1.
  • Page 19 1. Remote Start thru Data (green wire not connected). This feature only works on newer CANBUS vehicle using a Data Module that supports this feature. With this option you can use both the OEM and Crimestopper remote. 2. Connect the Green input wire to the Negative lock signal wire of the factory system. If your Factory OEM system does not have this type of signal, then a relay is required.

  • Page 20: Antenna Diagram

    25. ORANGE WIRE SELECTION: AUX 2 or OEM Arm - Default = OEM Arm 26. 1-WAY or 2-WAY SYSTEM: This selects 1-Way or 2-Way antenna system. The 1-Way system uses AM and 2-Way system uses FM. You must select this option using the brake pedal or remote control. If you accidentally change system from 1-Way to 2-Way (or vise versa), you need to use the brake pedal to change option 26 back to correct antenna system.

  • Page 21: Transmitter Programming / 2 Vehicle Programming

    2 times confirming the remote is coded and so on. If all 4 codes are learned, the unit will automatically exit code learning mode, otherwise turn key off. See diagram below. WAIT FOR 4 FLASHES PRESS 4X's LC-1 Only LC-3 thru LC-7 FLASH 2, 3, or 4 X's COMPLETE PRESS...

  • Page 22: Manual Transmission Mode

    MANUAL TRANSMISSION MODE MANUAL TRANSMISSION INSTALLATION: OPTION 11 TACH WIRE = White/Red must be connected and programmed. (Default = Tachless Mode) PINK WIRE = (-) Door Switch (default = Glow Plug) GREEN WIRE = (-) Hand Brake (default = OEM Start) After programming Option 11-1, 11-3 or 11-4 for manual transmission mode, the Door Trigger and Hand Brake wire must be connected for the manual transmission remote start procedure.

  • Page 23: Wiring Diagram

    OVERRIDE/ Low Current Remote Start PROGRAM BUTTON Wiring Diagram (-) LOCK OUTPUT GREEN (-) Start Activation Green +12 VOLT FOR RELAYS (-) UNLOCK OUTPUT BLUE NOTE: The Green wire is programmable for OEM Start activation (default) or (-) Hand Brake (Manual Transmission Mode) STATUS LED ANTENNA (+) Brake Switch...

  • Page 24: Remote Start Diagnostics

    Databus modules are used to communicate with the vehicles computer at the OBD2 Data connector or Canbus wires. This reduces installation error. Crimestopper Systems with DP Series have a direct Data Port Plug-In for the Databus bypass module. This eliminates conventional wiring between the Alarm/Remote Starter and the bypass interface module.
