INTRODUCTION:
CONGRATULATIONS on your choice of a Remote Keyless Entry System by Crimestopper Security Products
Inc.
This booklet contains the information necessary for installing, and operating your system.
questions arise, contact your installation dealer or Crimestopper Security Products Inc. at the Tech Support
number below.
*IMPORTANT INFORMATION: Primary and Optional Features
-PRIMARY FEATURES: These are features that must be connected in order for the system to operate
properly i.e. Power & Ground, along with the Primary features of Power Locks & Flashing Lights.
-OPTIONAL FEATURES: Optional features are connected only if desired or agreed upon by the installing
dealer i.e. Driver's Separate Unlock, Horn Chirp, Dome light illumination, Trunk Pop, etc. These features may
require additional parts and labor charges. Consult with your installer and come to an agreement about your
optional features before installation. NOTE: The LED is required for programmable options. See page 10.
TECH SUPPORT
Mon-Fri 8:00 AM-4:30 PM Pacific Time
(800) 998-6880
www.crimestopper.com
email@crimestopper.com
REV. A 03.2003
REMOTE KEYLESS ENTRY SYSTEM
INSTALLATION & OPERATING INSTRUCTIONS
This device complies with FCC Rules part 15. Operation is subject to the
following two conditions: 1) This device may not cause interference, and (2)
this device must accept any interference that may be received, including
interference that may cause undesired operation. The manufacturer is not
responsible for any radio or TV interference caused by unauthorized
modification to this equipment. Such modification could void the user's
authority to operate the equipment.
CS-865RKE
If any
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for CrimeStopper CS-865RKE
Summary of Contents for CrimeStopper CS-865RKE
- Page 1 Inc. This booklet contains the information necessary for installing, and operating your system. If any questions arise, contact your installation dealer or Crimestopper Security Products Inc. at the Tech Support number below. *IMPORTANT INFORMATION: Primary and Optional Features -PRIMARY FEATURES: These are features that must be connected in order for the system to operate properly i.e.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Pre-Installation & Component Mounting……………………..……………………………………………………2-3 Wiring……..……………………………………………………………………………………………………….…….3-4 Power Door Lock Wiring……………………………………………………….………..………………….…..……4-6 Jumper Diagram………………………………………………………………………………………………………….7 System Wiring Diagram.………………………………………………..………………………………………...…….8 Transmitter Programming………………………………………………………………………………………………9 Option Programming…………………………………………….……………………………….………….…...…9-10 Option Reset……………………….…………………………….……………………………….……………..………10 Operating Instructions………………………..……………………………………………………………..…….11-12 PRE-INSTALLATION CONSIDERATIONS To ease installation, we suggest that you READ THIS MANUAL before beginning your installation. BEFORE BEGINNING, check all vehicle manufacturer cautions and warnings regarding electrical service (AIR BAGS, ABS BRAKES, ENGINE / BODY COMPUTER AND BATTERY). -
Page 3: Wiring
COMPONENT MOUNTING CONTROL MODULE: Locate the module underdash as high as possible. Driver’s Side usually provides an easy location for the majority of the wiring connections. The antenna wire should be routed away from any metal if possible. DO NOT alter the length of the antenna wire, or ground the antenna wire. OVERRIDE / PROGRAM BUTTON: Mount the button in a hidden but accessible location. -
Page 4: Power Door Lock Wiring
WIRING ORANGE WIRE: NEGATIVE ARMED OUTPUT This wire provides a constant GROUND output when system is locked with the remote transmitter. This output can used for a starter disable relay, or a device such as a window roll-up module. See System Wiring Diagram. -
Page 5: Power Door Lock Wiring
POWER DOOR LOCK WIRING NEGATIVE TRIGGER DOORLOCK WIRING POSITIVE TRIGGER DOORLOCK WIRING BLUE/BLACK BLUE/BLACK FUSED VIOLET VIOLET +12V BROWN/BLACK NOT USED NOT USED BROWN/BLACK GREEN/BLACK GREEN/BLACK VIOLET/BLACK VIOLET/BLACK WHITE/BLACK NOT USED WHITE/BLACK NOT USED FACTORY FACTORY LOCK WIRE LOCK WIRE POWER POWER LOCKING... - Page 6 CS-865RKE SEPARATE DRIVER’S DOOR UNLOCK DIAGRAMS DRIVER PRIORITY UNLOCK with NEGATIVE TYPE DOOR LOCKS VIOLET VIOLET / BLACK BLUE / WHITE FUSED +12V WHITE / BLACK NOT USED GREEN / BLACK BROWN / BLACK BLUE / BLACK DRIVER'S DOOR MOTOR...
-
Page 7: Jumper Diagram
Relay outputs (White & Black/White wires). Use the jumper pins to change the Positive or Negative Polarity of the outputs as required for your particular installation. (Default = Positive for Parking Light and Negative for Dome Light) See diagram below. CS-865RKE MODULE JUMPER SIDE VIEW... -
Page 8: System Wiring Diagram
LOCK Normally Open (Terminal 87 On-Board Lock Relay) Parking Lights LEGEND: +12V or (-) Neg. Parking Light WHITE Output. (On-board 10A Relay) CS-865RKE Module +12V or (-) Parking Light Output (-) AUX. OUTPUT #3 BLACK / YELLOW 12 PIN MAIN BLACK / WHITE HARNESS +12V or (-) Neg. -
Page 9: Transmitter Programming
CS-865RKE TRANSMITTER PROGRAMMING 1. Turn Ignition ON and OFF 3 times quickly, leaving it ON the 3 time. (ON/OFF, ON/OFF, ON) 2. Lights should flash 3 times & horn will chirp 3 times if horn feature is installed. 3. Push and hold the Program/Override Button for about 5 seconds until you get 3 lights/LED flashes & 3 Horn chirps. -
Page 10: Option Reset
OPTION PROGRAMMING cont. 1. AUTOLOCK / UNLOCK WITH IGNITION Controls whether the doors will automatically lock when the ignition is turned on and will unlock when the ignition is turned off. Note: When Separate Driver’s Door Unlock feature is installed, only driver’s door will unlock when IGN. -
Page 11: Operating Instructions
OPERATION REMOTE LOCK To lock the doors, press the #1 (Lock Symbol) button on the transmitter. Lights will flash once and LED will LOCK UNLOCK begin flashing. You will also hear a single horn chirp (if optional horn chirp feature is installed). Optional: If starter disable is installed, it will also become active. - Page 12 OPERATION IGNITION TRIGGER (OPTIONAL REQUIRES HORN HONK FEATURE) This optional feature allows the unit to activate the panic mode if an unauthorized operator turns the Ignition ON after the vehicle had been locked using the remote control. This is not alarm system that can be triggered when opening the door, however with this feature is will trigger if the Ignition is turned on if you choose.
