Instruction and Installation Manual
RS-3 and RS-4
1-WAY REMOTE START SYSTEM
CONGRATULATIONS on your choice of a Cool Start™ Remote Engine Starter and Keyless Entry with DP
Technology by Crimestopper Security Products Inc. This booklet contains the information necessary for operating
your system. If any questions arise, contact your installation dealer or Crimestopper Security Products Inc.
*IMPORTANT INFORMATION: Primary and Optional Features
-PRIMARY: These are features that must be connected in order for the system to operate properly i.e. Remote
Start connections, Flashing lights, and Brake Reset. For programming, the hood pin and program button are
required.
-OPTIONAL: These features are to be connected only if desired or agreed upon by the customer and the installing
dealer i.e. Door Locks, Trunk Pop, Dome Light Illumination, Horn-Honk, Anti-Grind, etc. These features may also
require additional parts and/or labor fees. Consult with your installer beforehand to be sure of what is going to be
installed with your particular system.
CRIMESTOPPER SECURITY PRODUCTS, INC.
1770 S. TAPO STREET, SIMI VALLEY, CA. 93063
REV B 11-2008
OPERATING INSTRUCTIONS
This device complies with FCC Rules part 15. Operation is
subject to the following two conditions: 1) This device may not
cause interference, and (2) this device must accept any
interference that may be received, including interference that
may cause undesired operation.
responsible for any radio or TV interference caused by
unauthorized modification to this equipment. Such modification
could void the user's authority to operate the equipment.
The manufacturer is not
Advertisement
Table of Contents
Related Manuals for CrimeStopper COOL START RS-3
Summary of Contents for CrimeStopper COOL START RS-3
- Page 1 CONGRATULATIONS on your choice of a Cool Start™ Remote Engine Starter and Keyless Entry with DP Technology by Crimestopper Security Products Inc. This booklet contains the information necessary for operating your system. If any questions arise, contact your installation dealer or Crimestopper Security Products Inc. *IMPORTANT INFORMATION: Primary and Optional Features -PRIMARY: These are features that must be connected in order for the system to operate properly i.e.
-
Page 2: Table Of Contents
OPERATION CAUTIONS & WARNINGS CRIMESTOPPER SECURITY PRODUCTS, INC. and its VENDORS shall not be liable for any accident resulting from the use of this equipment. This system is designed to be professionally installed into a car or vehicle in which all items, such as parking brake and all associated components, door switches, transmission shift linkage, throttle linkage, and all engine safety features, are in perfect working condition. -
Page 3: Using The Remote Transmitter
The transmitter supplied with this system has 3 buttons and a car 2 side button. The button configuration is Factory- set and unchangeable. See Page 13 for additional information on how to use your remote to operate a second vehicle equipped with an RS-3 series system. For RS-4 The transmitter supplied with this system has 4 buttons and a car 2 side button. -
Page 4: Status Led
STATUS LED LED Operation: (Optional, requires Installation of LED) LED will flash when locking your doors with remote. LED will remain solid in Valet Service Mode. REMOTE ENGINE CONTROL Remote Start & Auxiliary Output – Button Press Selection (Option # 6): To eliminate the possibility of accidentally opening the trunk or starting the vehicle, there are (3) options for button press selection. - Page 5 REMOTE ENGINE CONTROL REMOTE ENGINE STARTING - UNSUCCESSFUL START In the event that the engine does not start on the first attempt, the system shuts down for a few seconds, then attempts to restart the engine a 2 and 3 time.
- Page 6 REMOTE ENGINE CONTROL IDLE DOWN MODE: This mode allows the unit to take over operation of the parked vehicle while the ignition key is removed and you exit the vehicle. The vehicle is put into a remote running condition before you exit and it will remain running for the programmed run time or until you come back.
- Page 7 REMOTE ENGINE CONTROL INFINITY RUN MODE This mode can only be activated with "Idle Down" procedure. The Infinity Run mode allows the vehicle engine to remain running INDEFINITELY after the programmed run time elapses. This mode will allow the vehicle to be left running and unattended without the ignition key in the switch preventing the vehicle from being stolen.
-
Page 8: Turbo Timer Mode
TURBO TIMER MODE (OPTION #22) The optional Turbo Timer mode allows the CoolStart system to keep a Turbo or Turbo Diesel vehicle running for 1 to 5 minutes [selectively] after you remove the key and exit the vehicle. This is handy for turbo cool-down without the need for expensive turbo timers. - Page 9 SETTING THE TURBO TIMER RUN TIME PRESS TURBO RELEASE TIMER BUTTON PRESS RUNNING BRAKE 1-5 TIMES AND HOLD BRAKE LIGHTS REMOVE KEY FLASH 1-5X REMAIN RUNNING 1-5 MIN. EXIT VEH.
-
Page 10: Convenience And Safety Features
CONVENIENCE AND SAFETY FEATURES KEYLESS ENTRY (POWER DOOR LOCK CONTROL, Optional) This system enables you to remotely lock and unlock the vehicle’s doors (if equipped with power locks) via remote control for safety and convenience. Note: This feature may require extra labor and/or parts to install. Press the Lock or Unlock transmitter button as you leave or come near the vehicle. - Page 11 CONVENIENCE AND SAFETY FEATURES VALET MODE / REMOTE START DISABLE (Requires Installation of Valet Switch) Before servicing your vehicle or handing the keys over to a Valet we recommend putting the unit into Valet Mode. The remote start function WILL NOT operate when in Valet Mode. To enter Valet mode, turn the key to the ON position, press and hold Program/Valet switch for 5-6 seconds.
-
Page 12: Transmitter Programming
TRANSMITTER PROGRAMMING Note: All transmitter codes must be learned at time of programming!! The RS-4 learns up to 4 different transmitter codes. 1. Turn key to the ON position. (Pink wire must be connected.) 2. Press Programming button 4 times, then after a few seconds the unit flashes the parking lights 4 times. 3. -
Page 13: Vehicle Operation
2-VEHICLE OPERATION & PROGRAMMING A single Remote Control can control two different vehicles. SETUP: Follow the “Transmitter Programming” steps on the second vehicle below. Program Car #2’s existing remotes, then quickly press the Car #2 side button on your remote before pressing the lock button on your remote to program it to Car #2. -
Page 14: No Factory Keyless Entry After Remote Start
Remote Started. To resolve this problem, have your installer connect the door locks to the Remote Start Keyless Entry. The Remote Starter with Re-Lock the doors after remote starting. Model RS-3 and RS-4 When you return to a remote started vehicle, just press the Unlock button on the remote control. -
Page 15: Battery Replacement
BATTERY REPLACEMENT To replace the battery: Simply remove the 3 screws on back of the transmitter and open the case. Remove the battery and replace. The replacement battery is GP23A. Remove 3 Screws... -
Page 16: 2-Way Data Port
Databus modules are used to communicate with the vehicles computer at the OBD2 Data connector or Canbus wires. This reduces installation error. Crimestopper Systems with DP Series have a direct Data Port Plug-In for the Databus bypass module. This eliminates conventional wiring between the Alarm/Remote Starter and the bypass interface module. - Page 17 © 2008 Crimestopper Security Products...
