Kaadas KA210A Installation Manual

Smart key-free touchscreen lock with fingerprint
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
KA210A
Smart Key-Free
Touchscreen Lock
With Fingerprint
Installation Guide / Quick Start Guide
Thank you for purchasing our products. Please review this manual thoroughly before operating your device.
All pictures in this manual are for illustration purpose only. Actual product may vary due to product upgrade.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KA210A and is the answer not in the manual?

Questions and answers

Related Manuals for Kaadas KA210A

Summary of Contents for Kaadas KA210A

  • Page 1 KA210A Smart Key-Free Touchscreen Lock With Fingerprint Installation Guide / Quick Start Guide Thank you for purchasing our products. Please review this manual thoroughly before operating your device. All pictures in this manual are for illustration purpose only. Actual product may vary due to product upgrade.
  • Page 3 P 13 Module installation and user guide Z-WaveTM handing process Quick Set Up Factory Default Settings Download Kaadas Home App Troubleshooting FCC Statement & Warnings IMPORTANT: Do not use an electronic scewdriver or drill during Do not load batteries until the lock installation.
  • Page 4 INSTALLATION GUIDE Interior Assembly (D) Battery Cover (E) Mounting Plate (C) Exterior Assembly Latch (B) Mounting Plate Screws (G) Interior Assembly Screws (F) Strike Plate (H) Latch Screws Reinforcement Plate (H-1) (Optional) Strike Plate Screws (I)

  • Page 5: Parts List

    Parts List Exterior Assembly x1 Latch x1 Mounting Plate x1 Interior Assembly x1 ⅜ ¾ 2 Battery Cover x1 Interior Assembly Mounting Plate Screws x4 Strike Plate x1 Screws x3 (35mm<door thickness<43mm) Reinforcement Plate x1 (optional) (43mm<door thickness<50mm) Reset Tool Z-Wave Module AA Battery x4 Strike Plate Screws x4...
  • Page 6 STEP Prepare the door and check dimensions 2-3/8" or 2-3/4" (60 or 70mm) Measure to Measure to confirm confirm that the that the backset is bore hole is　 either 2-3/8" or 1-1/2’’ or 2-1/8" 1-1/2" or 2-1/8" 2-3/4" (60 or 70mm) (38mm or 54mm).
  • Page 7 STEP Install the latch and strike Determine backset and adjust the latch. No adjustment is required. Proceed to next step. Slotted hole is NOT centered. Hold the latch in front of the bore hole, Rotate and pull the with the latch face flush against the latch as shown to door edge.
  • Page 8 Use a screwdriver to test if deadbolt works smoothly. IMPORTANT: Install strike on the door frame. Make sure the hole in door frame is drilled a minimum of 1" (25mm) deep. (Optional)

  • Page 9: Install Exterior Assembly

    STEP Install exterior assembly 1-1/2" (38mm) Measure the diameter of the hole in the door. IMPORTANT: Before installation, make sure the latch is fully retracted (in the unlocked position). Remove the fire cup Note:Remove the fire cup 1-1/2" or 2-1/8" may impact fire rating (38 or 54mm) Unlocked...

  • Page 10: Install Interior Assembly

    STEP Install interior assembly Push the battery Insert the cable Keep the thumb turn in the vertical position cover up in the into the connector. and install the interior assembly. direction as Push the illustrated. connector in firmly Horizontal until it is completely attached.
  • Page 11 STEP Insert batteries to calibrate the lock handing process. IMPORTANT: This step is required and crucial for the lock after installation. With the device unlocked, Use the Reset Tool to press and If the reset is successful, the insert 4 AA alkaline batteries hold the Reset Button for more latch bolt will extend on its own into the battery pack.
  • Page 12 QUICK START GUIDE At a Glance Exterior Assembly Interior Assembly Outside Indicator Touchscreen Keypad Battery Cover Reset Button Fingerprint Sensor Z-Wave Module Internal Indicator USB Type-C emergency power port Thumb Turn...
  • Page 13 How to Lock / Unlock Unlocking the door from outside Unlocking the door from inside Master/ Fingerprint Kaadas Home App Rotate the thumb Kaadas Home App User PIN /Z-Wave System App turn to the unlock /Z-Wave System App Code position.
  • Page 14 Low Battery Alarm can set the time delay for 30s, 60s, 120s and 180s in both Master Mode and the Kaadas Home App. If the battery indicator keeps flashing, the batteries are getting low. For the best performance replace with four new AA alkaline batteries.

  • Page 15: Code Format

    Code Format Programming Basics 1. Master PIN Code (4 to 10 digits): The default Master PIN Code is 12345678. Change the default Master PIN Code before programming other codes. 2. User PIN Code (4 to 10 digits): A total of 250 User PIN Codes (including One-Time PIN Code) can be programmed and stored in the lock. 3.
  • Page 16 Module installation and user guide Z-WaveTM (Optional network module required) 1. Make sure the network Module is securely plugged in,see page 7, step 4, section E for details. 2. Open the Z-Wave system's smart home or alarm app on your smartphone or tablet and follow the instructions in the app for adding a new smart lock.

  • Page 17: Quick Setup

    12345678 The default Master Code is IMPORTANT: Quick Set Up It is required that you change it to a code of your own before programming. Change New Master New Master Press Master PIN Code PIN Code Master PIN Code Code Wait for green light to flash Wait for green light to flash Green light will flash...
  • Page 18 Silent Mode disabled Press when green light flashes Silent Master Mode PIN Code Silent Mode enabled Wait for green light to flash when green light flashes Auto Lock disabled when green light flashes Press Auto Master Auto Lock 30s enabled when green light flashes Lock PIN Code Wait for green light to flash...

  • Page 19: Factory Default Settings

    Factory Default Settings How to Reset? Resetting the device will delete all User PIN Codes and Master PIN Code stored in the lock. Step 1. Keep the door open and the lock unlocked (thumb turn will be vertical). Step 2. Using the Reset Tool, press and hold the Reset Button for 5 seconds until you hear the Reset Button "BEEP"...
  • Page 20 Download Kaadas Home App Download the Kaadas Home App from the Apple Store or Google Quick Set Up Tips Play Store. • Create an account in the Kaadas Home App. • Scan the QR Code found on the inside panel of the Battery Cover to add your KA210A to the device list.

  • Page 21: Troubleshooting

    Troubleshooting Problem Solution Make sure the backset on the latch is set to the proper length.Refer to Installation Guide. The latch does not operate Make sure prior to installation the latch bolt is retracted. Refer to Installation Guide. correctly after installation. Please restore to factory default setting and enter the default Master PIN code to set up the lock.

  • Page 22: Fcc Statement

    FCC Statement ISED Statement This equipment has been tested and found to comply with the limits for a English:This device contains licence-exempt transmitter(s)/receiver(s) that Class B digital device, pursuant to part 15 of the FCC Rules. These limits comply with Innovation, Science and Economic Development Canada’s are designed to provide reasonable protection against harmful licence-exempt RSS(s).
  • Page 23 Do not install batteries until the lock is completely installed on door. product and void the factory warranty. • User PIN Codes: Can be 4-10 digits and can be set up in the Kaadas This manufacturer advises that no lock can provide complete security by Home App.
