- Page 1 Model: K20 Pro Max 3D Smart Lock with Camera and Display Screen User Manual www.kaadasgroup.com Shenzhen Kaadas Intelligent Technology co.,Ltd. reserves all rights for the final interpretation for this user manual. And the mannual is subject to be changed without notice.
- Page 2 Dear customers, Thank you for choosing our smart lock. Please check the package content and read the installation instruction carefully before you install this lock, and then install the product according to the instruction. Our company will not assume any responsibility for direct or indirect product problems, other damages and losses if you don't follow the instruction to install.
-
Page 3: Table Of Contents
Contents 1 Important Information 4 Setting your smart lock 6 Other functions Safety instruction WiFi Pairing Restore to factory settings Warning Adding user and user credential System reboot Disposal of used battery and lock Prior to setting up Emergency power supply Replace battery 2 Installing your smart lock 5 Using your smart lock... -
Page 4: Important Information
◆Only use the lithium battery configured in this product. ◆Making sure replacement or maintenace are done by ◆Do not forcibly disassemble this product in order to professional person authorized by Kaadas . avoid alarm sound or damage to the product. ◆Your warranty may invalidate if you used accessories ◆Do not scratch the fingerprint reader with sharp objects,... -
Page 5: Installing Your Smart Lock
2 Installing your smart lock Package contents This package list is for reference only, and all contents are subject to the actual packaging contents. Front panel Back panel Drilling template Mortise Strike Mechanical key (with rubber gasket) (with rubber gasket) Screw pack Monuting plate... -
Page 6: Lock Explosive View
Lock explosive view This lock explosive view is helpful to learn lock's structure. 1、Battery cover 2、Lithium battery 3、M6 screw (2pcs) 4、Back panel 5、M5 screw (2pcs) 6、Monuting plate 7、Mortise 8、Torque blade 9、M5 connecting screw tube(2pcs) 10、M6 connecting screw tube(2pcs) 11、Front panel 12、Rubber plug... -
Page 7: Before Installation
Before installation Latch direction change Check door opening direction prior to installation. 1.Unscrew screws on the face plate 2.Take out latch bolt, turn it 180° of mortise with hexagonal screw- to change latch direction and Right Outward Right Inword driver and remove face plate. put it back. -
Page 8: Installation Steps
Installation steps Front WiFi connection cable Front WiFi connection Torque cable blade connecting Front panel screw bolt connection Mortise cable M5 connecting connection cable screw tube (2pcs) Front panel connection cable connecting screw tube NOTE: Cut proper length torgue blade according to door thickness. - Page 9 Back WIFI Back panel connection connection cable cable interface Mortise connection cable interface Insert front panel connection cable Put back surplus length connection cables Check front panel and back and mortise connection cable to into the hole on the door and insert torque panel after installation and corresponding interface on the blade into emergency konb of back panel,...
-
Page 10: Overview
3 Overview Front panel Back panel Doorbell 3D face recognition Video intercom camera Fingerprint sensor Display screen Open/close indicator Keypad Display awaken button Card reader area Open button Privacy mode Reset button SET button Low battery indicator indicator Emergency knob Close button Awaken sensor Unlocking sensor... -
Page 11: Setting Your Smart Lock
Please ensure latest app version if you already download Kaadas Smart APP on your phone. if QR code on the battery cover can not be scanned, please select" manual add" ，... -
Page 12: Prior To Setting Up
Prior to setting up This lock system can enable/disable dual-verification. When dual-verification is enabled, it is required to verify two type of credentials at same time to unlock, while it only need to verify one type of credential to unlock when dual-verification is disabled. -
Page 13: Using Your Smart Lock
5 Using your smart lock In normal mode (dual-verification is disabled), continuously entering wrong face-recognition, PIN code, fingerprint or card 5 times in a short period of time will make this lock in lockdown for 100 seconds. In safety mode (dual-verificatioin is enabled), continuously entering any wrong two credentials combination 5 times including face-recognition, PIN code, fingerprint or card, will make this lock in lockdown for 100 seconds. -
Page 14: Unlock By Mechanical Key
Unlock by mechanical key Unlock/lock from inside You can unlock by mechanical key if you forget pin code, the battery run out or system error occurs. 1. CLOSE button Press CLOSE button once to lock Long press CLOSE button for 3 seconds to enable privacy mode. -
Page 15: Volume Adjustment
Volume adjustment Emergency knob When system functions is in abnormal, you can rotate emergency knob to unlocking When system is in voice mode, you position to unlock from inside. can long press button to enable mute mode after keypad is waked up. Emergency knob Mute button Doorbell function... -
Page 16: Inside Display Screen
6 Other functions Inside display screen 1. Press awaken button once to wake up display Restore to factory settings screen to see outside situation, pressing awaken If you forget master PIN code, you button again can close display screen and keypad can double press reset button on light. - Page 17 System reboot Emergency power supply When the battery voltage is too low to open the You can plug in a 5V power lock from outside, you can use 5V power bank to bank via Type-C port to charge the door lock via Type-C port. After the reboot the lock system.
