Smart Lock Manual
Electronic Keypad Deadbolt Lock
1
2
4
5
7
8
*
0
Note：
1. This lock is equipped with mechanical keys for manual unlocking. Remove mechanical
keys from the package and keep them in a safe place and always have access to them.
2. To power on the lock, four alkaline AA batteries (not included) are required. Non-alka-
line and rechargeable batteries ARE NOT RECOMMENDED.
3. This lock is used outdoors and indoors, it is designed to be exposed to direct sunlight or rain.
The waterproof rating: IP45
4. The operation of setting lock has a stand-by time limit of 8 seconds; Without any
activity, lock will shut after 8 seconds.
5. Keep your fingers clean when using this lock.
Please read this manual before operating your Smart Lock, and keep it for further reference.
3
6
9
#
Advertisement
Table of Contents
Related Manuals for Kaadas S110B-F
Summary of Contents for Kaadas S110B-F
- Page 1 Smart Lock Manual Electronic Keypad Deadbolt Lock Note： 1. This lock is equipped with mechanical keys for manual unlocking. Remove mechanical keys from the package and keep them in a safe place and always have access to them. 2. To power on the lock, four alkaline AA batteries (not included) are required. Non-alka- line and rechargeable batteries ARE NOT RECOMMENDED.
-
Page 2: Door Preparation
Contents Door Preparation 1. Check door thickness and Door Frame. Door drill hole map Door frame≧4 (110mm) Door thickness: (38-48mm) 2. Check door open direction. Door Preparation......01 (１ ０ｍｍ) Packing List........01 （6 8ｍｍ) (5 4ｍｍ) （ ２5ｍｍ） Installation Diagram....02-04 （5 8ｍｍ） （6 0ｍｍ）... -
Page 3: Installation Diagram
Installation Diagram Install the deadbolt (E) with screws (J) on the door. Step 2 Note: The deadbolt has TWO backset options: 70mm or 2⅜”(60mm) 2¾”(70mm) 60mm, please adjust it by yourself. Note: DO NOT Push the latch out before installation. Install outdoor unit(A) with cylindrical sleeve bolt(Ｆ)and gasket(B) on outdoor unit(A). -
Page 4: Product Profile
Product Profile Install indoor unit(D) with M4 cross flat head bolts(I、 G) on the door. Step 5 Specifications Material Zinc Alloy Model NO. S110B-F Door thickness 38mm-48mm Code Length 6~9 digits Working Temperature -20°C~70°C Working Humidity 20%~80%RH Static Power Consumption ＜30uA... - Page 5 App Operation Guide 3.6. IC Cards: Can add and delete IC cards on the App, place card in the sensor area of the electronic digital keyboard, and add IC cards according to the voice prompt to 1. App Installation and Registration successfully add IC cards to unlock.Note: can add 300 IC cards.
- Page 6 3.11.6. Transfer gateway: This function is used to transfer the gateway. Once trans- 3. Modify the Administrator’ s Unlocking Passcode ferred, you will lose the right for managing the gateway. Open the App - locate the lock you want to change admin passcode - click Setting - click 3.11.7.
-
Page 7: Important Safeguards
（2） Reset on the lock Q: The smart lock has started beeping whenever I lock or unlock the door. ① Remove one of batteries ② Put the battery back, and keep pressing the privacy button (right below the knob) on A：This is an indication your battery is low;...
