- Page 1 L8 User Manual www.kaadasgroup.com Shenzhen Kaadas Intelligent Technology Co.,Ltd reserves all rights for the final interpretation to this user manual All design and specifications are subject to change without notice.
-
Page 2: Table Of Contents
Content Cautions This section contains important information to ensure the user's safety and prevent potential damage to property. Please, read this section carefully and use the product accordingly. 1 How to install 5 Other Features Package Content Restore to Factory Setting Explosive View Emergency Power Supply Before Installation... -
Page 3: How To Install
1 How to install Package Content This described package content is for reference only, All package contents are subject to the final real packing. If some components lost, please check with the sellers. Outside escutcheon Inside escutcheon Installation Mortise Strike Plate Mechanical Key and with rubber gasket with rubber gasket... -
Page 4: Explosive View
Explosive View Notice: the pressure spring have to screw in the square shaft. 1.Inside escutcheon cover 4.Pressure spring （2pcs） 7.Mortise (1pcs) 10.Screw for mortise (2pcs) 2.Mounting screw(3pcs) 5.Square shaft （2pcs） 8.Connecting screw bolt(M6)（3pcs） 11.Connecting screw bolt(M5) (2pcs) 3.Inside escutcheon assembly 6.Mounting plate (1pcs) 9.Outside escutcheon assembly... -
Page 5: Before Installation
Before Installation Check Door Open Direction Change latch bolt direction Right-out Right-in 1. Move the latch bolt 2. Push the latch switcher to the other bolt inside the end as the arrow shows. mortise. Directional screws Left-out Left-in 4. Let the latch bolt eject. - Page 6 Change Handle Direction Change Outside escutcheon Handle Direction Screws Screws Positional Component Positional Component Cable Taking out screws, positional Rotating the handle to the other end. Put the cable into the right end, component and shield sleeve then place shield sleeve and in proper order.
- Page 7 Screws Screws Positional Component Positional Component Taking out screws and positional Rotating the handle to the other end. Place positional component and component in proper order. fasten the screws. Notice: Default screw pack for door is thickness 38-60mm, please contact our dealer if other screw pack required.
-
Page 8: Installation Steps
Installation Steps Do not make the Cable mortise deadbolt Connecting come out. screw bolt Screw Square shaft Cylinder (Notice: the pressure spring have to screw Pressure spring in the square shaft) Connecting screw bolt Mortise cable Mortise screws Notice: Make sure the mortise cable through Notice: Choose the square shaft and connecting the hole as the picture shows. - Page 9 Notice：According to the door thickness, cut the night latch key pick in proper length and insert the key pick into the right mortise hole. Mounting screw Square shaft Pressure spring Connecting cable Cable Mortise cable Mortise cable Mounting screw Install the mounting plate with fixing screws tightly Notice: the switch of tamper alarming have to tight against against the door.Install the square shaft and pressure the door, otherwise the tamper alarming will be triggered...
- Page 10 Batteries Inside escutcheon cover Notice: Make sure the Inside escutcheon cover installed well, avoid it fall off when close the door. Install 4pcs batteries and Inside escutcheon cover. Check if all functions are working well, then installation is finished.
-
Page 11: Product Overview
2 Product Overview Outside escutcheon Inside escutcheon Indicator light Touchpad Card reader area Fingerprint sensor Reset button Mirco USB port Inside escutcheon cover Notice：Pictures above are just for reference, please refer to the real product as final. -
Page 12: How To Set Before Set
3 How to set Before set There are normal mode and security mode in the product. The default mode is normal mode. Safe mode Normal mode Master PIN code Master PIN code for Security Mode Default master PIN code:12345678 20 groups 20 groups PIN code capacity Normal User PIN code+One time PIN code... -
Page 13: User Setting
First time access to the Master Mode Press [1] to enroll user card, Place card on the card Default master PIN code is 12345678. icon area until beep sound and voice prompt 1. Wake up touchscreen keypad with “Enrollment succeed". palm. - Page 14 Change Master PIN code Access into master mode, Press [4] for delete all card , Voice prompt of “Delete succeed, Card data is empty". Press [4] for change the master pin code, Enter new master PIN code , and confirm with [#] key; Then Enable/Disable Dual verification Mode repeat above operations , Voice prompt of Access into master mode,...
-
Page 15: Access Into Master Mode By Master Fingerprint
Access into Master Mode by Master Fingerprint 1. Wake up touchscreen keypad with palm. 2 Press [*] twice, then Notice: Pls avoid master fingerprint same as the user press the already enrolled fingerprint master fingerprint, then enter into the master mode. -
Page 16: How To Use
4 How to use Open from outside PIN code opening Fingerprint opening Card opening Fingerprint Card reader area Enter PIN code sensor Press the handle Press the handle Press the handle to open to open to open Touch pad screen by palm to Place the enrolled finger properly on Place the enrolled card properly on the lighten keypad, Enter the... -
Page 17: Close Door From Outdoor/Close Door From Indoor
5 Other Features Close door from outdoor/Close door from indoor Reboot Close door from outdoor Press the reboot button to restart the lock, when the system is unresponsive. No user data is deleted. Turn the handle upward to lock the deadbolt. Mirco USB port Emergency Power Close door from indoor... - Page 18 Restore to factory setting Change the battery If you forget the master PIN code, pls open the When battery voltage is lower than 4.8V, voice prompts Inside escutcheon cover, quick double press the “Low battery,please replace all batteries” at each unlocking. [RES] button to make the lock restore to factory Please replace all batteries immediately, and do not mix setting.
