3.2 Overflow Protection Function:
When water in the water pan exceeds the warning level, the machine will
automatically sound an alarm, and the "FULL" indicator light will flash. At this point,
you need to move the drainage pipe connecting the machine or the water outlet to
sewer or other drainage area to empty the water (details see Drainage Instructions at
the end of this chapter). After the water is emptied, the machine will automatically
return to the original state.
3.3 Automatic Defrosting (heating models have this function): The machine has
automatic defrosting function. Defrosting can be achieved through four - way valve
reversing.
3.4 Protection Function of the Compressor:
To increase the service life of the compressor, it has a 3-minute delay booting
protection function after the compressor is turned off.
V. Installation and adjustment
1. Installation:
Warning: before using the mobile air conditioning, keep it upright for at least two hours.
The air conditioning can be easily moved in the room. In the moving process, ensure that
the air conditioning is in the upright position and the air conditioning should be placed on
a flat surface. Do not install and use the air conditioning in the bathroom or other humid
environments.
1.1 Install the heat pipe assembly (as shown in Fig.1)
1) Take out the outer connector assembly and the exhaust pipe assembly, and remove
the plastic bags;
2) Insert the heat pipe assembly (the end of the exhaust joint) into the back panel vent
slot (push to the left) and complete the assembly (as shown in figure 1).
1.2 Installation of window sealing plate components
1) Half open the window, and mount the window sealing plate assembly to the window (as
shown in Fig.2 and Fig.3).Components can be placed in horizontal and vertical
direction.
2) Pull various components of the window sealing plate assembly open, adjust their
opening distance to bring both ends of the assembly into contact with the window
frame, and fix various components of the assembly.1.2 Install the window sealing plate
assembly.
Figure 1
