Controls and Indicators

C
ONTROLS AND
4
1 Drive Selectors
2. Horn Button
3. Lift/Lower Button
4. Emergency Stop Button
5. Display
6. Joystick
Chassis Controls
1. Keyswitch
2. Enable Button
3. Toggle Switch (Up & Down)
4. Emergency Stop Switch
Operation Manual
I
NDICATORS
3
1
1
Platform Controls
2
2 3
504165-002
Figure 2: Controls and Indicators
6
5
4
Page 5
