INSTALLATION & OPERATORS
COPY YOUR MODEL AND SERIAL NUMBER HERE
No other WINCO generator has the same serial number as yours.
If you should ever need to contact us concerning this unit, it will
help us to respond to your needs faster.
MODEL __________________________________________________
SERIAL NUMBER _________________________________________
PURCHASE DATE _________________________________________
DEALER NAME ___________________________________________
DEALER PHONE # ________________________________________
MANUAL
www.wincogen.com
W6010KE-04/A
W6010KE-17/A
W6010KE-18/A
GENERATORS
16200-014
Advertisement
Table of Contents
Related Manuals for Winco W6010KE-04/A
Summary of Contents for Winco W6010KE-04/A
- Page 1 MANUAL COPY YOUR MODEL AND SERIAL NUMBER HERE No other WINCO generator has the same serial number as yours. If you should ever need to contact us concerning this unit, it will help us to respond to your needs faster.
-
Page 2: Table Of Contents
Should you experience a problem please follow the “Troubleshooting Tables” near the end of this manual. UNPACKING The warranty listed in the manual describes what you can LUBRICATION expect from WINCO should you need service assistance in OIL RECOMMENDATIONS the future. DIESEL FUEL LIFTING EYE INSTALLATION... -
Page 3: Safety Information
SAFETY INFORMATION This manual contains important information that should be FIRE HAZARD understood and followed before the installation, operation Gasoline and other fuels present a hazard of possible and maintenance of the generator. Failure to follow the explosion and/or fire. safety instructions in this manual could result in serious injury or death. -
Page 4: Specifications
SPECIFICATIONS W6010KE-04/A Volts 120/208 3PH Surge Watts 6,000 Continuous Watts 5,000 Amps @ 1.0 PF 20.8 Amps @ 0.8 PF 17.3 W6010KE-17/A Volts 129/230 3PH Surge Watts 6,000 Continuous Watts 5,000 Amps @ 1.0 PF 21.7 Amps @ 0.8 PF 15.7... -
Page 5: Introduction
INTRODUCTION TESTING POLICY Before any generator is shipped from the factory, it is fully checked for performance. The generator is loaded to its full capacity, and the voltage, current, and frequency are carefully checked. Rated output of generator is based on engineering tests of typical units, and is subject to, and limited by, the temperature, altitude, fuel, and other conditions specified by the manufacturer of applicable engines. -
Page 6: Unit Capabilities
UNIT CAPABILITIES GENERATOR CONNECTIONS amount of current to run them whether they are Repulsion Induction (RI), Capacitor (Cap), or Split-Phase (SP) type. The following chart shows the approximate current required to CAUTION: EQUIPMENT DAMAGE start and run various types and sizes of 120 Volt 60 cycle Check phase rotation. -
Page 7: Preparing The Unit
If any damage is noted, it is always easiest to refuse the shipment and let WINCO take care of the freight claim. If you sign for the unit, the transfer of the ownership requires that you file the freight claim 2. -
Page 8: Lifting Eye Installation
LIFTING EYE INSTALLATION In the bag of parts for the lifting eye, ensure all of the required materials are included: 2 qty - 5/16-18 x 2.25 button head socket screws (#1); 2 qty - washers (#2); 2 qty - .3125-18 flange (#3); 1 qty - lifting eye (#4). 1. -
Page 9: Battery Installation
BATTERY INSTALLATION This engine generator set is shipped with a battery tie down DANGER: EXPLOSIVE FIRE RISK for customer installation. Never smoke when near batteries. Do not cause a flame or spark in the battery area. Always discharge static electricity A customer supplied 12 Volt battery, BCI group U1 rated from your body before touching batteries by first touching at 300 CCA or larger is recommended for this electric start... -
Page 10: Initial Start Up
INITIAL START UP The throttle control on these generators is preset and 5. Return key to 1st position when engine is running (Ref A). locked to operate at 3600 RPM (nominal) with no load speed set at 3690 RPM. Only a trained service technician should be allowed to adjust this speed setting. -
Page 11: Connecting The Loads
The NFPA 70 250:34-35 are good technical references. STANDARD PORTABLE GENERATOR Your WINCO portable generator ships with a bonded neutral. You can safely use this generator without external grounding as long as all loads are powered through the receptacle panel. - Page 12 CAUTION: EQUIPMENT DAMAGE Check phase rotation. Improper phase rotation can result in equipment damage. 1. These engine-generator sets are designed for portable heavy duty commercial use. On 208/230V machines, receptacles are provided on the control panel to permit both L-N and L-L connections. Each of the three L-N receptacles is connected to one leg allowing for an evenly balanced loads.
-
Page 13: Engine Care
Be sure the oil level is maintained. Fill to the “FULL” mark on the dipstick. Outdoor temperatures determine the proper oil viscosity for the engines. Winco recommends our 5W-30 fully synthetic oil to give you excellent protection in cold temperatures AIR FILTER while maintaining excellent performance in warmer weather. -
Page 14: Generator Care
GENERATOR CARE B. Remove the wing nut. Proper care and maintenance of the generator is necessary to ensure a long trouble free life. EXERCISING THE GENERATOR The generator should be operated every three to four C. Remove the filter element. weeks. -
Page 15: Troubleshooting
TROUBLESHOOTING Problem Possible Causes Won’t start Low oil level Out of fuel Start switch in OFF position Fuel Valve turned off Plugged fuel filter Blown fuse in key switch Battery required to open solenoid Voltage too low Engine speed is too low Generator overloaded Defective stator Defective rotor (field) -
Page 16: Wiring Diagram
WIRING DIAGRAM 208V & 230V 480V OPM-133/F... -
Page 17: Ca Evapemission Control
In California, new equipment that uses small off-road engines must be designed, built, and equipped to meet the State’s stringent anti-smog standards. WINCO must warrant the evaporative emission control system on your generator for the period listed below provided there has been no abuse, neglect or improper maintenance of your equipment leading to the failure of the evaporative emission control system. -
Page 18: Limited Warranty
Air cooled units purchased for stock have 1 year to be sold. The warranty to the original retail customer commences on the date of sale of the product to them. All liquid cooled units have 180 days from the Winco invoice to submit a start up date. If no startup form is submitted, then warranty period starts on the Winco invoice date unit was sold. - Page 19 Note 2: 3rd Year warranty coverage is parts only/no labor. Note 3: Round trip mileage is limited to 200 miles per trip and a total of 2 trips per repair unless authorized in writing by the WINCO Service Dept.
- Page 20 225 S. CORDOVA AVE • LE CENTER, MN 56057 Sales: 507-357-6821• sales@wincogen.com Service: 507-357-6831 • service@wincogen.com www.wincogen.com OPM-133/F...
