Axxess AX-JP901 Installation Instructions Manual

Jeep renegade data interface with swc & factory display retention2015
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
Jeep Renegade Data Interface with SWC & Factory Display Retention
INTERFACE FEATURES
• Provides accessory power
• Designed for non-amplified models
• Provides NAV outputs (parking brake, reverse, speed sense)
• Retains audio controls on the steering wheel
• Retains parking sensor chimes
* Attention! The aftermarket radios backup camera input will be used to display the vehicle settings. If the radio doesn't have a backup camera
Input, then there will be no visualization of the vehicle settings. An externally mounted screen could be substituted in this situation.
INTERFACE COMPONENTS
• AX-JP901 interface
• ASWC-1 interface
• AX-JP901 harness
• ASWC-1 harness
• Female 3.5mm connector with stripped leads
• Chime speaker
AxxessInterfaces.com
2015
• Retains balance and fade
• Retains most of the vehicle settings that was displayed on the
factory radio *
• Micro "B" USB updatable
© COPYRIGHT 2018 METRA ELECTRONICS CORPORATION
AX-JP901
I N S TA L L AT I O N I N S T R U C T I O N S
TABLE OF CONTENTS
Connections to be made ....................................2-3
Installing the AX-JP901 interface ..........................3
Programming the ASWC-1 interface ................. 3-4
Screen operation ................................................4-6
TOOLS REQUIRED
• Wire cutter • Crimp tool • Solder gun • Tape
• Connectors (example: butt-connectors, bell
caps, etc.)
CAUTION!
All accessories, switches, climate
controls panels, and especially air bag indicator
lights must be connected before cycling the
ignition. Also, do not remove the factory radio
with the key in the on position, or while the
vehicle is running.
REV. 4/10/18 INSTAX-JP901

Advertisement

loading

Related Manuals for Axxess AX-JP901

Summary of Contents for Axxess AX-JP901

  • Page 1 I N S TA L L AT I O N I N S T R U C T I O N S Jeep Renegade Data Interface with SWC & Factory Display Retention 2015 TABLE OF CONTENTS Connections to be made ........2-3 Installing the AX-JP901 interface ......3 Programming the ASWC-1 interface ....3-4 INTERFACE FEATURES Screen operation ..........4-6 • Provides accessory power •...

  • Page 2: Connections To Be Made

    CONNECTIONS TO BE MADE From the aftermarket radio to the AX-JP901 harness: From the aftermarket radio to the ASWC-1 harness: • Connect the Black wire to the ground wire. This harness is only to be used if the vehicle is equipped with steering wheel controls or a backup camera.

  • Page 3: Installing The Ax-Jp901 Interface

    With the key in the off position: at axxessinterfaces.com for customizing the buttons, if so desired. • Connect the AX-JP901 harness to the AX-JP901 interface, and then to the wiring harness in the vehicle. • Tie wrap the chime speaker under the dash to a location where it will be heard clearly by the driver, then route the harness to the radio location.

  • Page 4: Screen Operation

    PROGRAMMING THE ASWC-1 SCREEN OPERATION INTERFACE (CONT.) L.E.D. feedback Configuration Menu The (18) Red L.E.D. flashes represent what brand radio the ASWC-1 believes it is connected Vehicle Settings to. Each flash represents a different radio manufacturer. For example, if you are installing Interface Settings a JVC radio, the ASWC-1 will flash (5) times.
  • Page 5 SCREEN OPERATION (CONT.) Vehicle Settings Interface Settings Screen Size/Position Display Screen Size/Position Horizontal Size Clock Picture Settings Horizontal Position Doors and Locks Preferences Vertical Size Lights <Back Vertical Position Safety and Driving Assistance < Back Vehicle Off Options < Back Vehicle Settings Interface Settings Screen Size/Position...
  • Page 6 SCREEN OPERATION (CONT.) Picture Settings Preferences Brightness Park Assist Version Contrast Camera Connected Saturation Reverse Priority Park Assist < Back Park Brake Source Speed Restore factory settings < Back Picture Settings Preferences • Adjust brightness, contrast, and color saturation. • Park Assist Version - Select according to the color configuration of the park assist fitted to the vehicle.
  • Page 7 REV. 4/10/2018 INSTAX-JP901...
  • Page 8 AX-JP901 I N S TA L L AT I O N I N S T R U C T I O N S IMPORTANT If you are having difficulties with the installation of this product, please call our Tech Support line at 1-800-253-TECH. Before doing so, look over the instructions a second time, and make sure the installation was performed exactly as the instructions are stated.
