Installation instructions for AX-MLINK-HD
Car audio Wi-Fi A/V mirror interface through HDMI
With this Wi-Fi interface you will be able to mirror your IOS or Android device on your aftermarket in-dash
mobile video screen.
Note: This will not allow the mobile device to be operated from the aftermarket screen. All operations
(button presses) will need to be executed from the mobile device.
Mirroring capabilities are determined by the smart devices' (phone, tablet, etc.) software and the network
provider's permissions given to the device. Software updates can change the devices ability to mirror
certain types of video/audio.
• Wi-Fi mirror interface
• Cable to Car Audio (power connection)
1. Power LED: Blue light on when power on.
2. Antenna connector: Connect external
Wi-Fi antenna.
3. Reset:
(a) Press 1 second for reset.
(b) Press 5 seconds for factory
default settings.
4. Mode/Upgrade:
(a) Press once for switching between IOS Air
Play system and Android Miracast system.
METRA. The World's best kits.™
AX-MLINK-HD
Interface components
• Wi-Fi antenna
Interface DescrIptIon
(b) Press 5 seconds for upgrading software.
5. USB: Charge (5-volts 1-amp)/software upgrade.
6. Power/AV-IN: Power cable connections
to car audio ACC/GND.
7. HDMI port: Output to radio (HDMI cable
s old separately).
1-800-221-0932
Installation to the aftermarket radio:
• Connect the Red wire to the accessory wire.
Note: It is suggested to add a 3A fuse in-line with
the accessory wire.
• Connect the Black wire to the ground wire.
• Connect an HDMI cable (not supplied), to the the
HDMI port in the AX-MLINK-HD.
Note: Make sure to place the interface in an area
you can easily access it in case the "Mode" needs
to be changed from IOS to Android, or vice versa.
CAUTION: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
NOTE: Refer to the instructions included with the
aftermarket radio.
metraonline.com
© COPYRIGHT 2004-2015 METRA ELECTRONICS CORPORATION
WIrInG tHe aX-mLInK-HD
(continued on next page)
