INSTALLATION INSTRUCTIONS FOR PART TRIGGER
TRIGGER
The Trigger is a universal module that provides 15
different preset functions that are activated from a
positive or negative trigger. In addition to the preset
features, the Trigger has 8 custom modes with
customizable settings that allows the installer to
utilize their imagination.
TOOLS REQUIRED FOR INSTALLATION
Cutting Tool • Tape • Crimping Tool
Connectors (ie. butt connectors, bell caps, etc.)

Advertisement

loading

Related Manuals for Axxess TRIGGER

Summary of Contents for Axxess TRIGGER

  • Page 1 INSTALLATION INSTRUCTIONS FOR PART TRIGGER TRIGGER The Trigger is a universal module that provides 15 different preset functions that are activated from a positive or negative trigger. In addition to the preset features, the Trigger has 8 custom modes with customizable settings that allows the installer to utilize their imagination.

  • Page 2: Pin Diagram

    Pin 6: Green ((-) Output 500mA Max) Pin 7: Red ((-) Output 500mA Max) Pin 8: Blue ((+) output 2 amp Max) Pin 9: Brown (+ 0.8- 16v input trigger) Pin 10: Gray (- input trigger) Pin 11: Yellow (12 volt Constant/Switched)
  • Page 3 Description: Device will turn on when accessory turns on, and will not turn off until door opens or 10 minutes passes, whichever comes first. Connections: Interface wiring Pin 2 (Purple) Ground Pin 8 (Blue) Retained accessory output (2 amp max) Pin 9 (Brown) Vehicles accessory or ignition Pin 10 (Gray) Negative door trigger...
  • Page 4 Mode 2: Delayed turn-on Description: When the input is activated, there will be a 2-second delay before pin 8 turn-on. Connections: Interface wiring Pin 3 (White) Ground Pin 6 (Green) Negative delay turn-on output (500 mA max) Pin 7 (Red) Negative delay turn-on output (500mA max) Pin 8 (Blue) Positive delay turn-on output (2 amp max)
  • Page 5 Mode 4: Latched outputs Description: Allow the capability of making a pulsed signal a latched signal. Connections: Interface wiring Pin 4 (Pink) Ground Pin 6 (Green) Negative latched output (500 mA max) Pin 7 (Red) Negative latched output (500 mA max) Pin 8 (Blue) Positive latched output (2 amp max) Pin 9 (Brown)
  • Page 6 Pin 9 (Brown) Remote turn on from vehicle (see attached diagram) Pin 10 (Gray) Vehicle mute (see attached diagram) Connector 1 Connector 2 Vehicle Vehicle Connect connector number number Trigger Pin 11 (Yellow) Pin 1 (Black) Pin 9 (Brown) Pin 10 (Gray)
  • Page 7 Mode 6: Active edge pulse generator Description: Allow the capability of making an input signal a pulse signal. Connections: Interface wiring Pin 4 (Pink) Ground Pin 6 (Green) Negative pulsed output (500 mA max) Pin 7 (Red) Negative pulsed output (500 mA max) Pin 8 (Blue) Positive pulsed output (2 amp max) Pin 9 (Brown)
  • Page 8 Mode 8: Double pulse latch Description: Creates a latched signal from a double pulse signal. Connections: Interface wiring Pin 5 (Orange) Ground Pin 6 (Green) Negative latched output (500 mA max) Pin 7 (Red) Negative latched output (500 mA max) Pin 8 (Blue) Positive latched output (2 amp max) Pin 9 (Brown)
  • Page 9 Mode 10: Theft detection/closed loop trigger Description: When connected, if item loses ground the Trigger will send out a 12 volt constant signal which can be hooked to an audible device. Connections: Interface wiring Pin 3 (White) Ground Pin 5 (Orange)
  • Page 10 Mode 12: Simple data detector (amp turn on signal from data) Description: Produces a positive or negative signal out when data is detected. Note: Output will stay on 3 seconds after data stops transmitting. Connections: Interface wiring Pin 3 (White) Ground Pin 4 (Pink) Ground...
  • Page 11 Mode 14: Dome light delay Description: Keeps dome light on for 30 seconds after ignition is turned off Connections: Interface wiring Pin 3 (White) Ground Pin 4 (Pink) Ground Pin 5 (Orange) Ground Pin 6 (Green) Negative 30 second output (500 mA max) Pin 7 (Red) Negative 30 second output (500 mA max) Pin 8 (Blue)
  • Page 12 Mode 15: Custom program Description: Ability to custom program the Trigger using the Trigger program. Custom Program Modes: Custom Mode 1: Channel expander, latched Description: Measures pulses that occur during 5 second interval. One pulse per 5 seconds will toggle PIN 6 (GREEN), two pulses per 5 seconds will toggle PIN 7 (RED), and three pulses per 5 seconds will toggle PIN 8 (BLUE).
  • Page 13 Custom Mode 2: Channel expander, pulsed Description: Measures pulses that occur during 5 second interval. One pulse per 5 seconds will drive PIN 6 (GREEN) active for XX seconds, two pulses per 5 seconds will drive PIN 7 (RED) active for XX seconds, and three pulses per 5 seconds will drive PIN 8 (BLUE) active for XX seconds.
  • Page 14 Custom Mode 3: Delayed turn-off Connect active high input to pin 9, or active low input to pin 10. Use any output pin. When input goes high, output will turn on immediately. When input goes inactive, output turn-off will be delayed by XX seconds, where XX is definable between .1 and 300 seconds.
  • Page 15 Custom Mode 4: Delayed turn-on Description: Connect active high input to pin 9, or active low input to pin 10. Use any output pin. When input goes high, output will turn on after a delay of XX seconds. When input goes inactive, output turn-off will be immediate. XX is definable between .1 and 300 seconds.
  • Page 16 Custom Mode 5: Generic three-output delay/pulse width, edge driven (for use with linear actuators) Description: When either input goes active, each output will go active after a delay, and then stay active for a pulse width. Each output has an independent delay and pulse width, definable between .1 and 300 seconds.
  • Page 17 Custom Mode 6: Generic three-output delay/pulse width, level driven (validity) Description: When either input goes active, each output will go active after a delay, and then stay active for a pulse width. Each output has an independent delay and pulse width, definable between .1 and 300 seconds. Connections: Interface wiring Pin 2 (Purple)
  • Page 18 Custom Mode 7: Square wave-generator (sounds horns and blinks lights) Description: When either input goes active, all three outputs will toggle every XX seconds, where XX is definable between .1 and 300 seconds. Stops when input goes inactive. Connections: Interface wiring Pin 2 (Purple) Ground Pin 3 (White)
  • Page 19 Multiple Negative pulsed output (500 mA max) (1 pulse to activate) Pin 8 (Blue) Multiple Positive pulsed output (2 amp max) (3 pulses to activate) Pin 9 (Brown) Positive pulse input (use only one) Pin 10 (Gray) Negative pulse input (use only one) STEREOS AXXESS ACCESSORIES...
