MULTISPAN VR-3KN Manual page 2

Terminal Connection:
VR-3KN
100V AC (L-N)
Control Function:
Over Voltage
Hysteresis
L1-L2
L2-L3
L3-L1
Hysteresis
Under Voltage
07
08
09
T
P
Phase Loss
Phase Asymmetry
Hysteresis
160 To 300V AC (L-N)
ø
3 -4W
230V AC (L-N)
N
ON
T
< 100V AC (L-N)
±
40V AC (L-L)
6 V
Delay Time :
Power ON Delay: 5 Sec.
Trip Delay : 0 to 15 Sec Selectable
Trip Delay : <200ms (For PS & PL)
Trip Delay : 5 Sec (Asymmetry)
Recovery Time : 2 Sec
LED Indication:
R: Relay
UV : Under Voltage
OV : Over Voltage
PL : Phase Loss
AS : Asymentery
PS : Phase Sequence
ON
ON
T
T = Power ON Delay (5 sec)
P
T = Trip Delay (0 to 15 sec selectable)
(For OV & UV)
Phase
Loss
ON
(For OV & UV)
