MULTISPAN ELR 19N-M1 Quick Start Manual

FEATURE
Earth Leakage Current Monitoring In 1Ø - 2W, 3Ø-3W
And 3Ø-4W System
Auto/Manual Triping Reset Facility.
Trip Reset Via Front Key
TECNICAL SPECIFICATION
INPUT SPECIFICATION :
Input Voltage
Display Voltage Range
Resolution
DISPLAY & KEYS :
Display
Keys
DIMENSION :
Size (mm)
Panel Cutout
OUTPUT SPECIFICATION :
Relay
Relay Type
Rating
Earth to Neutral Relay
EN-19N
0 To 10 V AC
0.00 To 10.00 V AC
0.01 V AC
Upper: 4 Digit , 7 Seg. 0.56" Red
Lower: 4 Digit , 7 Seg. 0.56"Green
SET, INC, DEC, ENT/RST
96(H) X 96(W) X 52(D)
92(H) X 92(W)
1 Nos.
1 C/O (NO-C-NC)
10A,230V AC Resistive Load
AUXILIARY SUPPLY :
Supply Voltage
Power Consumption
(VA Rating)
ENVIRONMENT CONDITION:
Operating Temp.
Relative Humidity
Protection Level
(As per request)
MECHANICAL INSTALLATION
Outline Dimension (mm)
EN 19N
1 8 3
Voltage
1 0 0 0 R
96
Set Value
Earth to Neutral Voltage Relay
ENT
SET
RST
96
3
TERMINAL CONNECTION
20 19 18 17
E N
I/P
0 To 10V AC
Input: 0 To 10V AC
Range: 0.00 To 10.00V AC
~
100
250V AC
50/60 HZ
!
4VA
NO
L N
3
1 2 4
100 To 250 V AC,50/60Hz
4VA @ 230 VAC MAX
0°C to 55°C
UP to 95% RH
(non-condensing)
IP-65 (Front side) As per IS/IEC
60529 : 2001
Panel Cutout
Dimension (mm)
92
92
52
16 15 14 13 12
www.multispanindia.com
Made
in
India
C NC
5 6 7 8
11
9
10
Page - 1
