- Page 1 Hello, I’ve arrived! Now that I’m here you are only one flat-pack away from transforming your home.
- Page 2 Thank you for supporting us. We believe design belongs to everyone. From materials and processes to safety testing, production and delivery, we are passionate and committed to bringing you the best possible product so you can create beautifully functional spaces to feel comfortably you. Here are a few assembly tips before you get started: Make Time Set The Mood...
- Page 3 Leon Dining Chair Thank you for purchasing Leon Dining Chair. Please follow the manufacturer’s assembly instructions in detail. spring 45mm screw 25mm screw screw pin washer washer dowel bracket screw allen key wood button felt pads Read instruction carefully. Remove all wrapping material, staples and straps from the HARDWARE SUPPLIED carton.
- Page 4 Leon Dining Chair Attach 4 x dowels (F) to 2 x strechers (3F - Front) and (3B - Back) and 2 x legs Attach assembled frame together as shown and secure with 4 x screws (A), (2) as shown. Panels number 3 are marked F and B, F is the panel for the front 4 x spring washers (C) and 4 x screw pins (D).
- Page 5 Leon Dining Chair Attach 1 x backrest (1) to assembled frame as shown and secure with Attach 1 x seat (4) to assembled frame, 4 x felt pads (K) as shown and secure 4 x screws (B), 4 x spring washers (C) and 4 x washers (E). Tighten with an Allen with 2 x screws (A) and 2 x spring washers (C).
- Page 6 Leon Dining Chair Attach 1 x seat (4) to assembled frame and secure with 4 x brackets (G) and 8 x Once assembled lift furniture into place, do not drag. Ensure unit is screws (H). Tighten with a screwdriver. balanced and steady before use. You’re done, enjoy!
