2.3 Wiring diagram
VZ max 5A (3A) 230 Vac
KEY:
Relay contact for the valve/zone circulator pump (if pres-
VZ
ent)
SIME boiler remote control connection (it is not possi-
CR
ble to connect multiple SIME LINKER PLUS devices to the
same boiler)
(cable: 2x0.75 mm
28
CR
non-polarised; max length: 50 m)
2
2.4 Wall mounting
The SIME LINKER PLUS remote control unit can be installed on
any wall, however the most suitable point should be chosen:
– avoid air draughts (A);
– do not install it above heat sources (B);
– avoid direct sunlight (C);
– position it at the proper height (D).
A
C
The SIME LINKER PLUS remote control unit can be installed
exclusively in combination with SIME boilers (check the com-
patible models on the price list).
EN
B
~1,5m
