2.2 Basic Measurement

2.3 Setup Items in OPTION
Measurement
Click OPTION icon in main screen to set up this product.
Click "BASIC" mode to
enter measurement page.
1
Point optical sensor to light source to be tested.
■ Backlight Setting ■ Power Saving Setting
2
■ Date Setting ■ Time Setting
Press the measurement button at the bottom
center of the LCD screen or the measurement
key on the left hand side of the spectrometer to
take a measurement (You can press measurement
key at both sides).
13
Previous Back to
page main menu
■ Language Setting
3
＋/－：Adjust key
This product beeps once after
measurement is done and
displays results on screen.
- 11 -
2.2 Basic Measurement
2.3 Setup Items in OPTION
Save measurement data
1
Next
page
Press the "Save file" button at
lower right corner.
■ Check Storage Device
3
Measurement data is
now saved in the MicroSD
card. You may note down
file name if necessary.
Capacity of SD card displays once it is
inserted. In case message "Please insert
SD card" displays after a SD card has been
inserted the one you have inserted may be
failed to be identified by this product.
Charge left
■ Check Version
EXCEL file name：
ESPDY Y Y Y _ M M D D _ H H M M S S
.xls
regular ( year ) (month)(day) (hour/min/seconds)
▲
You may save entire source data.
JPG file name：
I MG Y Y Y Y _ M M D D _ H H M M S S
.JPG
regular ( year ) (month)(day) (hour/min/seconds)
1. You cannot set up battery. The screen remains intact after
▲
You may save measurement screen in "BASIC mode",
you tap it.
"SPECTRUM mode", "PPFD mode", "PPFD SPECTRUM
mode" and "CIE 1931.1976 mode".
- 12 -
2
■ USB Mode Setting
Please refer 5.1 for USB
mode setup.
