3.1 Connecting with mobile device

3.1 BASIC Mode
APP Installation
Click "BASIC" icon in main screen to display measurement
Download and install uSpectrum PAR on the mobile device.
readings.
Integration mode(P21) Capture function(P21、22)
：Auto ：one time
：Manual
：Continuous
iOS system：
Turn on "Bluetooth" in Settings on the mobile device （ Do not
connect to PG200N_BT ）
Android system ：
Turn on "Bluetooth" in Settings on the mobile device and
connect to PG200N_BT.
Measure
1. Device connection symbol: Blue→Connected, Red→Not connected.
2. When connection failed, select the device connection symbol to
perform connection again.
15
uSpectrum PAR
：Continuous measurement in progress
Charge left (P07)
：Charging
：Charge left indicator
：Low charge indicator
This screen shows 4 items of
measurements recorded.
Bluetooth connection
- 13 -

3.2 Connecting to uSPECTRUM

3.1 BASIC Mode
Install uSPECTRUM PC software
Customize the four measurement items in BASIC mode.
Please visit the UPRtek official website at http://www.uprtek.com;
The 4 items on the Basic list can be customized with different
download the file and install it on your computer system to
units of measure according to your preference.
connect the computer and PG200N through USB and run
1
uSpectrum to perform measurements.
uSPECTRUM
Install file
Set USB PC connection mode
1. Select "OPTION".
2. Select "USB mode".
3. Select "PC connection"and press "  " Yes.
Click the item to be changed.
3
Measure
USB connection
Click items to be shown in
position ①. Click "
"
key at bottom of screen to
back to last page without
selecting any item.
2
List of available items displays,
click down arrow key "" to
scroll down to next page.
4
uSPECTRUM PC software
Default item changed.
Follow the same steps to
change other default items.
- 14 -
