Read this manual carefully before operating this vehicle.
OWNER'S MANUAL
MTT9K
MTT9KC
LIT-11626-32-10
B5C-28199-10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TRACER MTT9K 2019 and is the answer not in the manual?

Questions and answers

Related Manuals for Yamaha TRACER MTT9K 2019

Summary of Contents for Yamaha TRACER MTT9K 2019

  • Page 1 Read this manual carefully before operating this vehicle. OWNER’S MANUAL MTT9K MTT9KC LIT-11626-32-10 B5C-28199-10...
  • Page 2 EAU10045 Operating, servicing and maintaining a passenger vehicle or off-road vehicle can expose you to chemicals including engine exhaust, carbon monoxide, phthalates, and lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. To minimize exposure, avoid breathing exhaust, do not idle the engine except as necessary, service your vehicle in a well-ventilated area and wear gloves or wash your...
  • Page 3 Yamaha has met these standards without reducing the performance or economy of operation of the motorcycle. To maintain these high standards, it is important that you and your Yamaha dealer pay close attention to the recommended maintenance schedules and operating instructions contained within this manual.
  • Page 4 Important manual information EAU10134 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
  • Page 5 Important manual information EAU10194 MTT9K / MTT9KC OWNER’S MANUAL ©2019 by Yamaha Motor Corporation, U.S.A. 1st edition, February 2018 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Corporation, U.S.A. is expressly prohibited. Printed in Japan.

  • Page 6: Table Of Contents

    Table of contents Location of important labels... 1-1 Windshield ........4-29 Canister (for California) ....7-11 Adjusting the headlight beams ..4-30 Engine oil ........7-11 Safety information......2-1 Handlebar position .......4-30 Coolant ......... 7-13 Adjusting the front fork ....4-30 Air filter element......7-15 Description ........
  • Page 7 Checking the steering ....7-29 STREET & DUAL-PURPOSE Checking the wheel bearings ..7-29 MOTORCYCLE LIMITED Battery ...........7-29 WARRANTY....... 10-8 Replacing the fuses.......7-31 YAMAHA EXTENDED SERVICE Headlights ........7-33 (Y.E.S.)........10-10 Auxiliary lights .......7-33 Brake/tail light .......7-33 Index ..........11-1 Replacing a turn signal light bulb ..........7-34...

  • Page 8: Location Of Important Labels

    Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label is available from your Yamaha dealer.
  • Page 9 Location of important labels 2 California only NOTICE VACUUM HOSE ROUTING Cleaning with alkaline or acid cleaner, gasoline or PRESS. SENSOR solvent will damage windshield. Use neutral detergent. 4B5-2815K-00 INTAKE MANIFOLD 1RC-21684-00 3 California only EMISSION HOSE ROUTING CHARCOAL CANISTER FUEL TANK THROTTLE BODY...
  • Page 10 Location of important labels WARNING TIRE INFORMATION Cold tire normal pressure should be set Improper loading can cause loss of control. as follows. Read owner’s manual for proper loading. • Up to 90 kg (198 lbs) load 3JJ-28446-A1 FRONT : 225 kPa, (2.25 kgf/cm²), 33 psi REAR : 250 kPa, (2.50 kgf/cm²), 36 psi •...

  • Page 11: Safety Information

    Safety information  Never operate a motorcycle with- pears to be very effective in reduc- EAU1028C out proper training or instruction. ing the chance of this type of Take a training course. Beginners accident. Be a Responsible Owner should receive training from a cer- Therefore: As the vehicle’s owner, you are re- tified instructor.
  • Page 12 Safety information  Many accidents involve inexperi- • Always signal before turning or Protective Apparel enced operators. In fact, many op- changing lanes. Make sure that The majority of fatalities from motorcy- erators who have been involved in other motorists can see you. cle accidents are the result of head in- ...
  • Page 13 Safety information  Do not run engine outdoors where Avoid Carbon Monoxide Poisoning When loading within this weight limit, All engine exhaust contains carbon engine exhaust can be drawn into keep the following in mind:  Cargo and accessory weight monoxide, a deadly gas.
  • Page 14 Yamaha accessories, which are avail- performed to your vehicle that change able only from a Yamaha dealer, have any of the vehicle’s design or operation should be kept to a minimum. been designed, tested, and approved characteristics can put you and others •...
  • Page 15 Safety information  Remove all loose items from the operator and may limit control ability, therefore, such accesso- motorcycle.  Check that the fuel cock (if ries are not recommended.  Use caution when adding electri- equipped) is in the off position and cal accessories.

  • Page 16: Description

    Description EAU10411 Left view 1. Windshield (page 4-29) 9. Shift pedal (page 4-18) 2. Rebound damping force adjuster (page 4-32) 10.Engine oil drain bolt (page 7-11) 3. Battery (page 7-29) 11.Engine oil filter cartridge (page 7-11) 4. Fuses (page 7-31) 5.

  • Page 17: Right View

    Description EAU10421 Right view 1. Rear brake fluid reservoir (page 7-21) 9. Engine oil filler cap (page 7-11) 2. Fuel tank cap (page 4-22) 10.Brake pedal (page 4-18) 3. Rebound damping force adjuster (page 4-30) 4. Spring preload adjuster (page 4-30) 5.

  • Page 18: Controls And Instruments

    Description EAU10431 Controls and instruments 1. Clutch lever (page 4-17) 9. Main switch/steering lock (page 4-1) 2. Left handlebar switches (page 4-16) 3. Auxiliary DC jack (page 4-36) 4. Multi-function meter unit (page 4-4) 5. Front brake fluid reservoir (page 7-21) 6.

  • Page 19: Instrument And Control Functions

    Instrument and control functions To lock the steering EAU10462 EAU10662 Main switch/steering lock All electrical systems are off. The key can be removed. EWA10062 WARNING Never turn the key to “OFF” or “LOCK” while the vehicle is moving. Otherwise the electrical systems will LOCK be switched off, which may result in loss of control or an accident.

  • Page 20: Indicator Lights And Warning Lights

    If and “ ” key can be turned to “ ”. this occurs, have a Yamaha dealer Each indicator light will flash when its ECA20760 check the vehicle. NOTICE corresponding turn signal lights are flashing.
  • Page 21 10 check the vehicle. If the traction control system becomes km/h (6 mi/h), have a Yamaha dealer disabled while riding, or if a problem is check the vehicle. detected in the traction control system, EAU73172 Engine trouble warning light “...

  • Page 22: Multi-Function Meter Unit

    Instrument and control functions  eco indicator EAU78451 Multi-function meter unit  transmission gear display  drive mode display 5 6 7  TCS display  information display GEAR  setting mode display A.TEMP °F EWA12423 C.TEMP °F WARNING TIME TRIP 0:00 Be sure to stop the vehicle before making any setting changes to the...
  • Page 23 Instrument and control functions High-r/min zone: 11250 r/min and Fuel meter above To switch between kilometers and miles, see page 4-10. Clock Tachometer 1. Fuel meter The fuel meter indicates the amount of fuel in the fuel tank. The display seg- 1.
  • Page 24 Drive mode display  Select the transmission gear that meter electrical circuit, the fuel meter will flash repeatedly. If this is appropriate for the vehicle occurs, have a Yamaha dealer speed. check the vehicle. Transmission gear display Eco indicator GEAR A.TEMP...
  • Page 25 Instrument and control functions TCS display Information display You can select which items are shown GEAR in each information display. See Set- TRIP-1 mile ting mode on page 4-10. TRIP-2 mile mile Odometer and tripmeters GEAR GEAR A.TEMP ˚F mile mile C.TEMP ˚F...
  • Page 26 Instrument and control functions button briefly so that the tripmeter In this case, push the select switch to flashes, and then push the “RESET” switch the display in the following or- There are also “TIME–2” and “TIME–3” button again for two seconds. der: elapsed time displays, but they cannot be set to the information display.
  • Page 27  The “km/L” display shows the av- C.TEMP ˚F be continuously displayed. Have a erage distance that can be trav- Yamaha dealer check the vehicle. eled on 1.0 L of fuel.  The “L/100km” display shows the Instantaneous fuel consumption average amount of fuel necessary to travel 100 km.
  • Page 28 Have a miles. When kilometers are will be saved. Unit Yamaha dealer check the vehicle. selected, the fuel con- sumption units can be Push and hold the menu switch switched between “MENU” for 2 seconds to enter the set- “L/100km”...
  • Page 29 Instrument and control functions 2. Push the menu switch to display This function allows you to change the items shown in “TIME–2” and “TIME–3”. To reset Display Maintenance 3 information displays. a time trip, push the “RESET” but- mile This function allows you to ton to select the item to reset.
  • Page 30 Instrument and control functions  When miles are selected, the fuel consumption display units will be MENU  Keep kilometers selected: Skip to set to “MPG”. Skip to step 6. Maintenance step 5. Time Trip  Select miles or kilometers: Conti- 4.
  • Page 31 Instrument and control functions MENU Display-1 Display-1 Maintenance Time Trip A.TEMP Unit Display C.TEMP C.TEMP Brightness Clock TIME TRIP TIME TRIP All Reset 2. Push the menu switch, then use 4. Use the select switch to select the 6. Use select switch the select switch to highlight the...
  • Page 32 Instrument and control functions 6. Push the menu switch to return to the setting mode menu. MENU MENU Maintenance Maintenance Resetting all of the display items Time Trip Time Trip Unit Unit 1. Use the select switch to highlight Display Display “All Reset”.

  • Page 33: D-Mode (Drive Mode)

    Instrument and control functions This mode allows the rider to enjoy EAU47636 D-mode (drive mode) smooth and sporty drivability from the The odometer and the clock cannot be D-mode is an electronically controlled low-speed range to the high-speed reset. engine performance system with three range.

  • Page 34: Handlebar Switches

    Instrument and control functions Right ter position. To cancel the turn signal EAU1234M Handlebar switches lights, push the switch in after it has re- turned to the center position. Left EAU12501 Horn switch “ ” Press this switch to sound the horn. EAU54212 Stop/Run/Start switch “...

  • Page 35: Clutch Lever

    Instrument and control functions Using this switch changes the drive ECA10062 EAU12822 Clutch lever NOTICE mode to “STD”, “A”, or “B” in the fol- lowing order: Do not use the hazard lights for an STD → A → B → STD extended length of time with the en- gine not running, otherwise the bat- The throttle grip must be completely...

  • Page 36: Shift Pedal

    Instrument and control functions EAU12875 EAU26826 EAU12944 Shift pedal Brake lever Brake pedal The brake lever is located on the right side of the handlebar. To apply the front brake, pull the lever toward the throttle grip. 1. Shift pedal 1.

  • Page 37: Abs

    Instrument and control functions EAU63040  The ABS performs a self-diagno- The Yamaha ABS (Anti-lock Brake sis test each time the vehicle first System) features a dual electronic con- starts off after the key is turned to trol system, which acts on the front and “ON”...

  • Page 38: Traction Control System

    Instrument and control functions TCS “1” minimizes traction control EAU76315 Traction control system system assist. The traction control system (TCS) helps maintain traction when acceler- TCS “2” ating on slippery surfaces, such as un- TCS “2” maximizes traction control as- paved or wet roads.
  • Page 39 “ ” warning light will come on. accident. ble. TCS settings can be changed only 4. Have a Yamaha dealer check the when the vehicle is stopped and the vehicle and turn off the “ ” throttle closed. warning light.

  • Page 40: Fuel Tank Cap

    Instrument and control functions EAU13076 EAU13222 Fuel tank cap Fuel The fuel tank cap cannot be closed un- Make sure there is sufficient gasoline in less the key is in the lock. In addition, the tank. the key cannot be removed if the cap is EWA10882 WARNING not properly closed and locked.
  • Page 41 EWA15152 as well as to the exhaust system. WARNING Gasoline is poisonous and can cau- Your Yamaha engine has been de- se injury or death. Handle gasoline signed to use premium unleaded gas- with care. Never siphon gasoline by oline with a pump octane number mouth.

  • Page 42: Fuel Tank Breather Hose And Overflow Hose

    Instrument and control functions EAU51182 EAU13434 ECA10702 Fuel tank breather hose and Catalytic converter NOTICE overflow hose This model is equipped with a catalytic Use only unleaded gasoline. The use converter in the exhaust system. of leaded gasoline will cause unre- EWA10863 pairable damage to the catalytic WARNING...

  • Page 43: Seats

    Instrument and control functions EAU65800 Seats Passenger seat To remove the passenger seat 1. Insert the key into the seat lock, and then turn it counterclockwise. 1. Projection 1. Cap 2. Seat holder 2. Rider seat lock lever 2. Remove the key. To install the rider seat 1.

  • Page 44: Adjusting The Rider Seat Height

    Instrument and control functions EAU63050 Adjusting the rider seat height The rider seat height can be adjusted to one of two positions to suit the rid- er’s preference. The rider seat height was adjusted to the lower position at delivery. 1.
  • Page 45 Instrument and control functions 4. Insert the projection on the front of the rider seat into seat holder B as shown. 1. Projection 1. Rider seat height position adjuster 2. “H” position slot 2. Projection 3. Grommet 6. Install the passenger seat. 1.

  • Page 46: Helmet Holder

    Instrument and control functions 5. Align the projection on the bottom 3. Place the helmet on the right side EAU63060 Helmet holder of the rider seat with the “L” posi- of the vehicle, and then install the The helmet holder is located under the tion slot, and then push the rear of seat.

  • Page 47: Storage Compartment

    Instrument and control functions  Do not exceed the maximum EAU14465 EAU83932 Storage compartment Windshield load of 180 kg (397 lb) for the ve- This model is equipped with an adjust- hicle. able windshield. 1. Storage compartment The storage compartment is located 1.

  • Page 48: Adjusting The Headlight Beams

    It may be neces- erence. Have a Yamaha dealer adjust Always adjust the spring preload on sary to adjust the headlight beams to the position of the handlebar.
  • Page 49 Instrument and control functions Spring preload setting: Rebound damping setting: Minimum (soft): Minimum (soft): Distance A = 19.0 mm (0.75 in) 12 click(s) in direction (b) Standard: Standard: Distance A = 16.0 mm (0.63 in) 7 click(s) in direction (b) Maximum (hard): Maximum (hard): Distance A = 4.0 mm (0.16 in)

  • Page 50: Adjusting The Shock Absorber Assembly

    Instrument and control functions Rebound damping force EAU57943 Adjusting the shock absorber 3 2 1 To increase the rebound damping for- 7 6 5 4 assembly ce and thereby harden the rebound This shock absorber assembly is damping, turn the adjusting screw in equipped with a spring preload adjust- direction (a).

  • Page 51: Auxiliary Dc Connector

    DC connector. Consult your damping performance. tion (a) until it stops, and then Yamaha dealer before installing any  Do not dispose of a damaged or count the turns in direction (b). accessories.

  • Page 52: Sidestand

    EAU15306 EAU44895 Sidestand Ignition circuit cut-off system Yamaha dealer repair it if it does not The sidestand is located on the left This system prevents in-gear engine function properly. side of the frame. Raise the sidestand...
  • Page 53 The neutral switch may not be working. 6. Move the sidestand up. The motorcycle should not be ridden until 7. Pull the clutch lever. checked by a Yamaha dealer. 8. Shift transmission into gear. 9. Move the sidestand down. Does the engine stall? The sidestand switch may not be working.

  • Page 54: Auxiliary Dc Jack

    Instrument and control functions 4. Insert the accessory plug into the EAU49454 Auxiliary DC jack auxiliary DC jack. 1. Auxiliary DC jack cap 1. Auxiliary DC jack A 12-V accessory connected to the 5. Turn the main switch on, and start auxiliary DC jack can be used when the the engine.

  • Page 55: For Your Safety - Pre-Operation Checks

    • If necessary, add recommended coolant to specified level. 7-13 • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary.
  • Page 56 • Make sure that operation is smooth. • Check throttle grip free play. Throttle grip 7-15, 7-25 • If necessary, have Yamaha dealer adjust throttle grip free play and lubricate ca- ble and grip housing. • Make sure that operation is smooth. Control cables 7-25 •...
  • Page 57 • Tighten if necessary. Instruments, lights, signals • Check operation. — and switches • Correct if necessary. • Check operation of ignition circuit cut-off system. Sidestand switch 4-34 • If system is not working correctly, have Yamaha dealer check vehicle.

  • Page 58: Operation And Important Riding Points

    To start the engine with  a lean angle sensor. This sensor understand, ask your Yamaha dealer. the transmission in gear, the sidestand stops the engine in case of a vehi- EWA10272 must be up and the clutch lever pulled.

  • Page 59: Shifting

    If a warning or indicator light does not work as described above, have a the neutral position, do not Yamaha dealer check the vehicle. coast for long periods of time with the engine off, and do not 3. Shift the transmission into neutral.
  • Page 60 Operation and important riding points 4. At the recommended shift points clutch lever in, use the brakes to EAU64150 Recommended shift points shown in the following table, close slow the motorcycle, and continue The recommended shift points during the throttle, and at the same time, to downshift as necessary.

  • Page 61: Engine Break-In

    Yamaha dealer check the vehi-  Do not park on a slope or on soft During this period, prolonged full-throt- cle.

  • Page 62: Periodic Maintenance And Adjustment

    To avoid possible burns, let tivities incorrectly may increase brake components cool before your risk of injury or death during touching them. service or while using the vehicle. If you are not familiar with vehicle ser- vice, have a Yamaha dealer perform service.

  • Page 63: Tool Kit

    However, a torque wrench and other tools are necessary to perform certain maintenance work correctly. If you do not have the tools or experi- ence required for a particular job, have your Yamaha dealer perform it for you.

  • Page 64: Periodic Maintenance Chart For The Emission Control System

     From 24000 mi (37000 km) or 36 months, repeat the maintenance intervals starting from 8000 mi (13000 km) or 12 months.  Items marked with an asterisk require special tools, data and technical skills, have a Yamaha dealer perform the ser- vice.
  • Page 65 Periodic maintenance and adjustment INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months •...

  • Page 66: General Maintenance And Lubrication Chart

    30 months • Perform dynamic inspection us- Diagnostic system √ √ √ √ √ √ ing Yamaha diagnostic tool. check • Check the error codes. Air filter element • Replace. Every 24000 mi (37000 km) • Check operation. √ √...
  • Page 67 Periodic maintenance and adjustment INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months •...
  • Page 68 Periodic maintenance and adjustment INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months Shift pedal pivot...
  • Page 69 (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months • Apply Yamaha cable lubricant or √ √ √ √ √ √ 28 * Control cables other suitable cable lubricant thoroughly.

  • Page 70: Removing And Installing The Panel

    Periodic maintenance and adjustment EAU18752 Removing and installing the panel The panel shown needs to be removed to perform some of the maintenance jobs described in this chapter. Refer to this section each time the panel needs to be removed and installed. 1.

  • Page 71: Checking The Spark Plugs

    1/2 turn past finger tight. However, the Yamaha dealer. Since heat and depos- with a wire thickness gauge and, if spark plug should be tightened to the its will cause any spark plug to slowly necessary, adjusted to specification.

  • Page 72: Canister (For California)

    Periodic maintenance and adjustment To check the engine oil level EAU19683 EAU1990E Canister (for California) Engine oil 1. After warming up the engine, wait The engine oil level should be checked a few minutes for the oil to settle. regularly. In addition, the oil must be 2.
  • Page 73 An oil filter wrench is available at a oil filler cap and add oil. Yamaha dealer. 5. Check the engine oil filler cap O- 5. Apply a thin coat of clean engine ring. Replace if damaged.

  • Page 74: Coolant

    7. Install the engine oil drain bolt with NOTICE: Do not operate the ve- If genuine Yamaha coolant is not avail- a new gasket, and then tighten the able, use an ethylene glycol antifreeze hicle until you know that the en- bolt to the specified torque.
  • Page 75 The coolant must be changed at the in- tervals specified in the periodic main- tenance and lubrication chart. Have a Yamaha dealer change the coolant. WARNING! Never attempt to remove the radiator cap when the engine is 1. Coolant reservoir cap hot.

  • Page 76: Air Filter Element

    Check the engine idling speed and, if Measure the throttle grip free play as maintenance and lubrication chart. necessary, have it corrected by a shown. Have a Yamaha dealer replace the air Yamaha dealer. filter element. Engine idling speed: 1100–1300 r/min 1.

  • Page 77: Valve Clearance

    90 kg (198 lb) to maximum load: To prevent this from occurring, have Front: your Yamaha dealer check and adjust Tire air pressure 250 kPa (2.50 kgf/cm², 36 psi) Rear: the valve clearance at regular intervals.
  • Page 78 WARNING  It is dangerous to ride with a worn-out tire. When a tire tread begins to show crosswise lines, have a Yamaha dealer replace the tire immediately.  The replacement of all wheel and brake-related parts, includ- ing the tires, should be left to a Yamaha dealer, who has the 1.

  • Page 79: Cast Wheels

    If any damage is found, have high speeds. After extensive tests, only the tires list- a Yamaha dealer replace the  Brand-new tires can have a rel- ed below have been approved for this wheel. Do not attempt even the atively poor grip on certain road model by Yamaha.

  • Page 80: Adjusting The Clutch Lever Free Play

    Measure the clutch lever free play as clutch does not operate correctly, have shown. a Yamaha dealer check the internal clutch mechanism. 1. No brake lever free play There should be no free play at the 1.

  • Page 81: Brake Light Switches

    EAU36891 Front brake pads Yamaha dealer. 1. Brake pad wear indicator Each front brake pad is provided with wear indicators, which allows you to check the brake pad wear without hav- ing to disassemble the brake.

  • Page 82: Checking The Brake Fluid Level

    Rear brake EAU40262 Checking the brake fluid level Yamaha dealer replace the brake pads Before riding, check that the brake fluid as a set. is above the minimum level mark. Check the brake fluid level with the top...

  • Page 83: Changing The Brake Fluid

    EAU22734 Changing the brake fluid id; otherwise, the rubber seals Yamaha dealer check the cause before Have a Yamaha dealer change the further riding. may deteriorate, causing leak- brake fluid every 2 years. In addition, age.

  • Page 84: Drive Chain Slack

    EAU63122 To adjust the drive chain slack each side of the swingarm in di- Consult a Yamaha dealer before ad- rection (a). To loosen the drive justing the drive chain slack. chain, turn the adjusting bolt on 1.

  • Page 85: Cleaning And Lubricating The Drive Chain

    Periodic maintenance and adjustment EAU23026 Cleaning and lubricating the drive chain The drive chain must be cleaned and lubricated at the intervals specified in the periodic maintenance and lubrica- tion chart, otherwise it will quickly wear out, especially when riding in dusty or wet areas.

  • Page 86: Checking And Lubricating The Cables

    Yamaha dealer at the intervals cated if necessary. If a cable is specified in the periodic maintenance damaged or does not move smoothly, chart.

  • Page 87: Checking And Lubricating The Brake And Shift Pedals

    Periodic maintenance and adjustment EAU44276 EAU23144 Recommended lubricant: Checking and lubricating the Checking and lubricating the Lithium-soap-based grease brake and shift pedals brake and clutch levers The operation of the brake and shift The operation of the brake and clutch pedals should be checked before each levers should be checked before each ride, and the pedal pivots should be lu-...

  • Page 88: Checking And Lubricating The Centerstand And Sidestand

    EWA10742 WARNING If the centerstand or sidestand does not move up and down smoothly, have a Yamaha dealer check or re- pair it. Otherwise, the centerstand or sidestand could contact the ground and distract the operator, resulting in a possible loss of control.

  • Page 89: Lubricating The Swingarm Pivots

    The swingarm pivots must be lubricat- ce and hold it in an upright posi- fork does not operate smoothly, ed by a Yamaha dealer at the intervals tion. WARNING! To avoid injury, have a Yamaha dealer check or re- specified in the periodic maintenance securely support the vehicle so pair it.

  • Page 90: Checking The Steering

    If any free seat. (See page 4-25.) hub or if the wheel does not turn play can be felt, have a Yamaha This model is equipped with a VRLA smoothly, have a Yamaha dealer dealer check or repair the steer- (Valve Regulated Lead Acid) battery.
  • Page 91 To charge the battery 3. Fully charge the battery before installation. NOTICE: When in- Have a Yamaha dealer charge the bat- tery as soon as possible if it seems to stalling the battery, be sure to have discharged. Keep in mind that the...

  • Page 92: Replacing The Fuses

    Periodic maintenance and adjustment EAU63134 Replacing the fuses The fuse boxes and individual fuses are located under the rider seat (see page 4-25) and behind panel A (see page 7-9). To access fuse box 1, the main fuse, and the fuel injection system fuse, re- move the rider seat.
  • Page 93 2. Remove the blown fuse, and then 4. If the fuse immediately blows install a new fuse of the specified again, have a Yamaha dealer amperage. WARNING! Do not check the electrical system. use a fuse of a higher amperage...

  • Page 94: Headlights

    If a headlight does not come on, check If the brake/tail light does not come on, the fuses and then have a Yamaha have a Yamaha dealer check it. dealer check the vehicle. When the headlights are set to low beam, one headlight will come on.

  • Page 95: Replacing A Turn Signal Light Bulb

    Periodic maintenance and adjustment 6. Install the turn signal light unit by EAU43006 Replacing a turn signal light installing the screw. NOTICE: Do bulb not overtighten the screw, oth- 1. Remove the turn signal light unit erwise the lens may break. by removing the screw.

  • Page 96: Replacing The License Plate Light Bulb

    3. Insert a new bulb into the socket. self. However, should your motorcycle 4. Install the socket (together with require any repair, take it to a Yamaha the bulb) by pushing it in, and then dealer, whose skilled technicians have...
  • Page 97 Periodic maintenance and adjustment heaters or furnaces. Gasoline or gasoline vapors can ignite or ex- plode, causing severe injury or prop- erty damage. 7-36...

  • Page 98: Troubleshooting Charts

    Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the compression. 4. Compression The engine does not start. There is compression.
  • Page 99 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended cool- ant as soon as possible.

  • Page 100: Motorcycle Care And Storage

    Be performance and extend the useful life  high-pressure washers sure to consult a Yamaha dealer for of many components. Washing, clean- steam-jet cleaners. Excessive ing, and polishing will also give you a advice on what products to use be-...
  • Page 101 Motorcycle care and storage chemicals such as, solvents, Washing strong chemicals to clean the gasoline, rust removers, brake 1. Rinse off any degreaser and spray windshield. Additionally, some down the vehicle with a garden fluid, or antifreeze, etc. cleaning compounds for plastic hose.

  • Page 102: Storage

    Motorcycle care and storage surfaces. WARNING! Do not ap- 10. Let the vehicle dry completely be- EAU84140 Storage ply silicone or oil spray to seats, fore storing or covering it. Always store the vehicle in a cool, dry hand grips, rubber foot pegs or ECA26320 NOTICE place.
  • Page 103 Motorcycle care and storage 1. Make all necessary repairs and b. Pour a teaspoonful of engine not available, turn the wheels a lit- perform any outstanding mainte- oil into the spark plug bore. tle once a month in order to pre- nance.

  • Page 104: Specifications

    Specifications Dimensions: Compression ratio: Coolant quantity: 11.5 : 1 Overall length: Coolant reservoir (up to the maximum level Starting system: 2160 mm (85.0 in) mark): Electric starter Overall width: 0.25 L (0.26 US qt, 0.22 Imp.qt) Lubrication system: 850 mm (33.5 in) Radiator (including all routes): Wet sump Overall height:...
  • Page 105 Specifications Final drive: Rear tire: Front brake: Chain Type: Type: Secondary reduction ratio: Tubeless Hydraulic dual disc brake 2.813 (45/16) Size: Specified brake fluid: Transmission type: 180/55ZR17 M/C (73W) DOT 4 Constant mesh 6-speed Manufacturer/model: Rear brake: Gear ratio: DUNLOP/D222 Type: 1st: Loading:...
  • Page 106 Specifications Charging system: Traction control system indicator light: Plug +12V fuse: AC magneto 2.0 A Battery: Fuse(s): Model: Main fuse: YTZ10S 50.0 A Voltage, capacity: Headlight fuse: 12 V, 8.6 Ah (10 HR) 7.5 A Bulb wattage: Fog lamp fuse: 2.0 A Headlight: Signaling system fuse:...

  • Page 107: Consumer Information

    Vehicle identification number ed when registering the vehicle with the authorities in your area and when EAU26442 Engine serial number ordering spare parts from a Yamaha dealer. VEHICLE IDENTIFICATION NUMBER: 1. Vehicle identification number ENGINE SERIAL NUMBER: The vehicle identification number is 1.
  • Page 108 This label shows specifica- ing spare parts from a Yamaha dealer. key. tions related to exhaust emissions as required by federal law, state law and Environment Canada.

  • Page 109: Diagnostic Connector

     Vehicle status and engine perfor- shown. mance data  Fuel-injection and emission-relat- ed data Yamaha will not disclose this data to a third party except:  With the consent of the vehicle owner  Where obligated by law  For use by Yamaha in litigation ...

  • Page 110: Reporting Safety Defects

    If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immedi- ately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Yamaha Motor Corporation, U.S.A. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.

  • Page 111: Motorcycle Noise Regulation

    Consumer information EAU26561 Motorcycle noise regulation TAMPERING WITH NOISE CONTROL SYSTEM PROHIBITED: Federal law prohibits the following acts or the causing thereof: (1) The removal or rendering inoperative by any person other than for purposes of maintenance, repair, or replacement of any device or element of design incorporated into any new vehicle for the purpose of noise control prior to its sale or delivery to the ultimate purchaser or while it is in use or (2) the use of the vehicle after such device or element of design has been removed or rendered inoperative by any person.

  • Page 112: Maintenance Record

    Consumer information EAU26633 Maintenance record Copies of work orders and/or receipts for parts purchased and installed on your vehicle will be required to document that maintenance has been completed in accordance with the emissions warranty. The chart below is printed only as a reminder that maintenance work is required.
  • Page 113 Consumer information Maintenance Date of Servicing dealer Mileage Remarks interval service name and address 36000 mi (55000 km) or 54 months 40000 mi (61000 km) or 60 months 10-7...
  • Page 114 Consumer information EAU61802 YAMAHA MOTOR CORPORATION, U.S.A. 2015 AND LATER MODEL STREET & DUAL-PURPOSE MOTORCYCLE LIMITED WARRANTY Yamaha Motor Corporation, U.S.A. hereby warrants that CUSTOMER’S RESPONSIBILITY under this ENGINE each new Yamaha motorcycle purchased from an warranty shall be to:...

  • Page 115: Yamaha Motor

    CUSTOMER SERVICE What costs are my responsibility during the warranty period? If your machine requires warranty service, you must take it to any authorized Yamaha The customer’s responsibility includes all costs of normal maintenance services, motorcycle dealer within the continental United States. Be sure to bring your warranty non-warranty repairs, accident and collision damages, and oil, oil filters, air filters, registration card or other valid proof of the original date of purchase.

  • Page 116: Yamaha Extended Service (Y.e.s.)

    This excellent Y.E.S. plan coverage is only available to warranty. See the sample contract at your Yamaha Yamaha owners like you, and only while your Yamaha is still dealer to see how comforting uninterrupted factory- within the Yamaha Limited Warranty period. So visit your backed protection can be.
  • Page 117 TRIP coverage right away, and you’ll rest easy knowing you’ll have strong factory-backed protection even after your Yamaha Limited Warranty expires. A special note: If visiting your dealer isn’t convenient, contact Yamaha with your VIN number and we’ll be happy to help you get the YAMAHA EXTENDED SERVICE Y.E.S.

  • Page 118: Index

    Index D-mode (drive mode) ......4-15 Drive chain, cleaning and lubricating ... 7-24 ABS............4-19 Labels, location........1-1 Drive chain slack ........7-23 ABS warning light ........4-3 License plate light bulb, replacing ..7-35 Air filter element ........7-15 Auxiliary DC connector ......4-33 Engine break-in ........6-4 Main switch/steering lock .......4-1 Auxiliary DC jack........4-36 Engine idling speed, checking .....
  • Page 119 Index Specifications ......... 9-1 Starting the engine ......... 6-1 Steering, checking........ 7-29 Stop/Run/Start switch ......4-16 Storage ........... 8-3 Storage compartment ......4-29 Swingarm pivots, lubricating ....7-28 Throttle grip and cable, checking and lubricating........... 7-25 Throttle grip free play, checking... 7-15 Tires ............
  • Page 121 Yamalube – Take care of your Yamaha with legendary Yamalube oils, lubricants, and care products. They’re formulated and approved by the toughest judges we know: the Yamaha engineering teams that know your Yamaha from the inside out.
  • Page 122 PRINTED ON RECYCLED PAPER PRINTED IN JAPAN 2018.04-0.5×1 CR...

This manual is also suitable for:

Tracer mtt9kc 2019

Table of Contents
