Yamaha Tracer MTT850D 2019 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Read this manual carefully before operating this vehicle.
OWNER'S MANUAL
MTT850D
B0S-F8199-30

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tracer MTT850D 2019 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Yamaha Tracer MTT850D 2019

Summary of Contents for Yamaha Tracer MTT850D 2019

  • Page 1 Read this manual carefully before operating this vehicle. OWNER’S MANUAL MTT850D B0S-F8199-30...
  • Page 2 EAU46091 Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold. EAU46091 EAU46091 Baca buku panduan dengan teliti sebelum mengendalikan motosikal ini. Buku panduan diberi bersama dengan pembelian motosikal.
  • Page 4 EAU10103 Welcome to the Yamaha world of motorcycling! As the owner of the MTT850D, you are benefiting from Yamaha’s vast experience and newest technology regarding the design and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.
  • Page 5 Important manual information EAU10134 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
  • Page 6 Important manual information EAU10201 MTT850D OWNER’S MANUAL ©2018 by Yamaha Motor Co., Ltd. 1st edition, December 2018 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd. is expressly prohibited. Printed in Malaysia.

  • Page 7: Table Of Contents

    Table of contents Safety information......1-1 Storage compartment ....3-38 General maintenance and Windshield ........3-38 lubrication chart ......6-5 Description ........2-1 Adjusting the headlight beams ..3-38 Removing and installing the Left view ......... 2-1 Handlebar position .......3-39 panel..........6-9 Right view........2-2 Adjusting the front fork ....3-39 Checking the spark plugs.....
  • Page 8 Table of contents Checking and lubricating the Specifications ........8-1 throttle grip and cable....6-25 Checking and lubricating the Consumer information..... 9-1 brake and shift pedals ....6-26 Identification numbers ....9-1 Checking and lubricating the Diagnostic connector...... 9-2 brake and clutch levers....6-26 Vehicle data recording ....

  • Page 9: Safety Information

    Safety information who did not see the motorcycle. Never operate a motorcycle with- EAU1028C Making yourself conspicuous ap- out proper training or instruction. Take a training course. Beginners pears to be very effective in reduc- Be a Responsible Owner should receive training from a cer- ing the chance of this type of As the vehicle’s owner, you are re- accident.
  • Page 10 Safety information ed by road and traffic condi- Many accidents involve inexperi- Protective Apparel tions. enced operators. In fact, many op- The majority of fatalities from motorcy- Always signal before turning or erators who have been involved in cle accidents are the result of head in- changing lanes.
  • Page 11 Safety information Avoid Carbon Monoxide Poisoning ports. When loading within this weight limit, All engine exhaust contains carbon keep the following in mind: Do not run engine outdoors where monoxide, a deadly gas. Breathing Cargo and accessory weight engine exhaust can be drawn into carbon monoxide can cause head- should be kept as low and close to a building through openings such...
  • Page 12 Yamaha accessories, which are avail- characteristics can put you and others Bulky or large accessories may able only from a Yamaha dealer, have at greater risk of serious injury or seriously affect the stability of been designed, tested, and approved death.
  • Page 13 Safety information operator and may limit control Remove all loose items from the ability, therefore, such accesso- motorcycle. ries are not recommended. Check that the fuel cock (if Use caution when adding electri- equipped) is in the off position and cal accessories.

  • Page 14: Description

    Description EAU10411 Left view 1. Windshield (page 3-38) 8. Rebound damping force adjuster (page 3-41) 2. Battery (page 6-29) 9. Shift pedal (page 3-26) 3. Fuses (page 6-31) 10.Engine oil drain bolt (page 6-11) 4. Storage compartment (page 3-38) 11.Engine oil filter cartridge (page 6-11) 5.

  • Page 15: Right View

    Description EAU10421 Right view 3,4,5 1. Rear brake fluid reservoir (page 6-21) 8. Coolant reservoir (page 6-13) 2. Fuel tank cap (page 3-30) 9. Engine oil level check window (page 6-11) 10.Engine oil filler cap (page 6-11) 3. Rebound damping force adjuster (page 3-39) 11.Brake pedal (page 3-27) 4.

  • Page 16: Controls And Instruments

    Description EAU10431 Controls and instruments 1. Clutch lever (page 3-25) 8. Throttle grip (page 6-15) 2. Left handlebar switches (page 3-3) 9. Grip warmer (page 3-14) 3. Auxiliary DC jack (page 3-43) 10.Main switch/steering lock (page 3-2) 4. Instrument panel (page 3-5, 3-11) 5.

  • Page 17: Immobilizer System

    If all keys safe place. When necessary, take the vehicle along with all three keys to a have been lost or damaged, the en- Yamaha dealer to have them re-regis- tire immobilizer system must be re- placed. Therefore, handle the keys tered.

  • Page 18: Main Switch/Steering Lock

    Instrument and control functions EAU10474 EAU84031 EAU1068B Main switch/steering lock LOCK All electrical circuits are supplied with The steering is locked and all electrical power and the vehicle lights are turned systems are off. The key can be re- on. The engine can be started. The key moved.

  • Page 19: Handlebar Switches

    Instrument and control functions ECA20760 EAU66055 Handlebar switches NOTICE If the steering will not lock, try turning Using the hazard or turn signal lights Left the handlebars back to the right slight- for an extended length of time may cause the battery to discharge. To unlock the steering 1.
  • Page 20 Instrument and control functions Right EAU66030 ECA10062 Horn switch “ ” NOTICE Press this switch to sound the horn. Do not use the hazard lights for an extended length of time with the en- EAU84240 TCS switch “ ” gine not running, otherwise the bat- See page 3-28 for an explanation of tery may discharge.

  • Page 21: Indicator Lights And Warning Lights

    If the lights do 8. Right turn signal indicator light “ ” tion on the main screen and its not come on, have a Yamaha dealer 9. Left turn signal indicator light “ ” functions.
  • Page 22 Yamaha dealer check the vehi- verts to conventional braking. If ei- cle. ther of the above occurs, or if the...
  • Page 23 Let the en- vehicle and all 3 keys to a Yamaha tor light will flash in a pattern), have a gine cool. Check the coolant dealer to have the standard keys Yamaha dealer check the vehicle.

  • Page 24: Cruise Control System

    This model is equipped with a cruise confirming the proper oil level, control system designed to maintain a have a Yamaha dealer check set cruising speed. the vehicle. Do not continue to The cruise control system operates...
  • Page 25 Instrument and control functions Activating and setting the cruise You can also manually increase your control system traveling speed using the throttle. After 1. Push the cruise control power you have accelerated, you can set a switch “ ” located on the left new cruising speed by pushing the handlebar.
  • Page 26 Instrument and control functions Apply the front or rear brake. When traveling with a set cruising Disengage the clutch. speed, if the cruise control system is Pushing the power switch while the Push the power switch to turn off the deactivated under the above condi- system is operating will turn the sys- cruise control system.

  • Page 27: Display

    Instrument and control functions ing speed. If this occurs, acceler- normal for a small number of pixels to EAU84301 Display ate to the desired traveling speed be inactive. The following items can be found on using the throttle. the display. When the vehicle is traveling Speedometer downhill,...
  • Page 28 If all the fuel meter display segments TRIP-1 and TRIP-2 will reset and hicle first powered flash repeatedly, have a Yamaha deal- continue counting after 9999.9 tachometer will sweep across the r/min er check the related circuits. has been reached.
  • Page 29 Transmission gear display available. Have a Yamaha dealer check After refueling and traveling some This shows which gear the transmis- the vehicle. distance, F-TRIP will automatically sion is in.
  • Page 30 Instrument and control functions TCS display If the handlebar grip or throttle Display Setting This display indicates which traction grip becomes worn or dam- control system setting has been se- aged, stop using the grip warm- lected: “1”, “2” or “OFF”. (See page ers and replace the grips.

  • Page 31: Menu Screen

    MENU access and operation Display Setting warning icon will flash repeatedly. The following wheel switch operations Brightness Have a Yamaha dealer check the vehi- are common operations for accessing, cle. The MENU screen contains the follow- selecting, and moving within the ECA26400 ing setting modules.
  • Page 32 Instrument and control functions 12 : 00 MENU 12 : 00 Maintenance The MENU screen can be ac- km/h km/h Maintenance Maintenance cessed by long pushing the wheel 0 km Unit switch, except when the grip INTERVAL 1 123456 km warmer display is selected or the Wallpaper INTERVAL 2...
  • Page 33 Instrument and control functions 3. Select the units you want to use. 12 : 00 MENU km/h 12 : 00 Maintenance Unit km/h Unit Unit km or mile Wallpaper Shift Indicator km/L or L/100km km/L Display Setting Brightness 1. Photo sensor 2.
  • Page 34 Instrument and control functions “Shift indicator” The shift indicator module contains the 12 : 00 12 : 00 Wallpaper Shift Indicator km/h km/h following items. Shift IND Setting Display Description NIGHT Shift IND Brightness Set the shift indicator pat- Tach IND Setting tern to “ON”, “Flash”, or Shift IND “OFF”...
  • Page 35 Instrument and control functions Shift Indicator 12 : 00 Shift Indicator 12 : 00 12 : 00 Shift Indicator km/h km/h km/h 1000 r/min 1000 r/min Shift IND Setting Shift IND Brightness Shift IND Setting Shift IND Setting IND Mode IND Mode Tach IND Setting 6000...
  • Page 36 Instrument and control functions black or white (depending on wallpa- 3. Select ON to turn the tachometer up to the “Tach IND 2nd” setting per settings). When turned on, the mid color display mode on (or select value (or the red zone), will be dis- and mid-to-high r/min zones can be OFF to turn this function off).
  • Page 37 Instrument and control functions 7. Set the orange color starting r/min “Peak Rev IND Setting” “Display Setting” by rotating and then short pushing This module allows you to turn the rev- This module allows you to set how the the wheel switch. All r/min above olution peak hold indicator on or off.
  • Page 38 Instrument and control functions 12 : 00 MENU 12 : 00 12 : 00 Display Setting Display Setting km/h km/h km/h Maintenance DISPLAY-1 DISPLAY-1 Unit 1 - 1 A.TEMP 1 - 1 A.TEMP Wallpaper 1 - 2 C.TEMP 1 - 2 C.TEMP Shift Indicator Display Setting...
  • Page 39 Instrument and control functions To set the grip warmer temperature levels 12 : 00 MENU Grip Warmer Setting 12 : 00 km/h km/h 1. From the MENU screen, select Maintenance Level 1 “Grip Warmer Setting”. Unit MIDDLE Level 5 Wallpaper HIGH Level 10 12 : 00...
  • Page 40 Instrument and control functions 12 : 00 12 : 00 12 : 00 MENU Clock Clock km/h km/h km/h Shift Indicator Display Setting Brightness Grip Warmer Setting Clock Clock All Reset 2. When “Clock” is selected, the 4. The minutes figure will become 6.

  • Page 41: D-Mode (Drive Mode)

    Instrument and control functions This mode allows the rider to enjoy EAU84420 EAU12822 D-mode (drive mode) Clutch lever smooth and sporty drivability from the D-mode is an electronically controlled low-speed range to the high-speed engine performance system with three range. mode selections: “STD”, “A”, and “B”.

  • Page 42: Shift Pedal

    Instrument and control functions EAU84320 EAU84330 EAU26826 Shift pedal Quick shift system Brake lever The quick shift system (QS) allows for The brake lever is located on the right full-throttle, clutch lever-less, electron- side of the handlebar. To apply the ically-assisted upshifts.

  • Page 43: Brake Pedal

    EAU12944 EAU63040 Brake pedal tional braking if a malfunction occurs. The Yamaha ABS (Anti-lock Brake System) features a dual electronic con- The ABS performs a self-diagno- trol system, which acts on the front and sis test each time the vehicle first rear brakes independently.

  • Page 44: Traction Control System

    Instrument and control functions EAU84341 Traction control system sensor or wheel sensor rotor; other- wise, improper performance of the The traction control system (TCS) ABS will result. helps maintain traction when acceler- ating on slippery surfaces, such as un- paved or wet roads. If sensors detect that the rear wheel is starting to slip (uncontrolled spinning), the traction control system assists by regulating...
  • Page 45 Instrument and control functions When the traction control system has ECA16801 Push the TCS switch “ ” for two NOTICE been set to “OFF”, the “ ” indicator seconds to turn the traction con- light will come on. Use only the specified tires. (See trol system off.

  • Page 46: Fuel Tank Cap

    Instrument and control functions 4. Have a Yamaha dealer check the EAU13076 Fuel tank cap vehicle and turn off the “ ” warning light. 12:00 1000 r/min km/h 1234.5 TRIP-1 1234.5 TRIP-2 MODE- TCS 1 In °C 25 1. Traction control system indicator light “...

  • Page 47: Fuel

    Instrument and control functions EAU13222 the sun can cause fuel to spill out Fuel of the fuel tank. The fuel tank cap cannot be closed un- Make sure there is sufficient gasoline in less the key is in the lock. In addition, the tank.
  • Page 48 Check that gasoline nozzle has Fuel reserve amount: the same identifier when fueling. 2.6 L (0.69 US gal, 0.57 Imp.gal) Your Yamaha engine has been de- ECA11401 signed to use premium unleaded gas- NOTICE oline with a research octane number of Use only unleaded gasoline.

  • Page 49: Fuel Tank Overflow Hose

    Instrument and control functions EAU72972 EAU13434 ECA10702 Fuel tank overflow hose Catalytic converter NOTICE This model is equipped with a catalytic Use only unleaded gasoline. The use converter in the exhaust system. of leaded gasoline will cause unre- EWA10863 pairable damage to the catalytic WARNING converter.

  • Page 50: Seats

    Instrument and control functions EAU65800 Seats Passenger seat To remove the passenger seat 1. Insert the key into the seat lock, and then turn it counterclockwise. 1. Projection 1. Cap 2. Seat holder 2. Rider seat lock lever 2. Remove the key. To install the rider seat 1.

  • Page 51: Adjusting The Rider Seat Height

    Instrument and control functions EAU63050 Adjusting the rider seat height The rider seat height can be adjusted to one of two positions to suit the rid- er’s preference. The rider seat height was adjusted to the lower position at delivery. 1.
  • Page 52 Instrument and control functions 4. Insert the projection on the front of the rider seat into seat holder B as shown. 1. Projection 1. Rider seat height position adjuster 2. “H” position slot 2. Projection 3. Grommet 6. Install the passenger seat. 1.

  • Page 53: Helmet Holder

    Instrument and control functions 5. Align the projection on the bottom 3. Place the helmet on the right side EAU63060 Helmet holder of the rider seat with the “L” posi- of the vehicle, and then install the The helmet holder is located under the tion slot, and then push the rear of seat.

  • Page 54: Storage Compartment

    Instrument and control functions EAU62550 EAU83932 EAU39612 Storage compartment Windshield Adjusting the headlight beams This model is equipped with an adjust- The headlight beam adjusting knobs able windshield. are used to raise or lower the height of the headlight beams. It may be neces- sary to adjust the headlight beams to increase visibility and help prevent blinding oncoming drivers when carry-...

  • Page 55: Handlebar Position

    EWA14671 each fork leg in direction (b). WARNING of two positions to suit the rider’s pref- erence. Have a Yamaha dealer adjust Always adjust the spring preload on the position of the handlebar. both fork legs equally, otherwise poor handling and loss of stability may result.
  • Page 56 Instrument and control functions Although a damping force adjust- er may click beyond the stated Be sure to perform this adjustment on minimum settings, such adjust- the right front fork leg. ments are ineffective and may damage the suspension. Compression damping force The compression damping force is ad- justed on the left front fork leg only.

  • Page 57: Adjusting The Shock Absorber Assembly

    Instrument and control functions Although a damping force adjust- EAU84350 Adjusting the shock absorber er may click beyond the stated assembly minimum settings, such adjust- This shock absorber assembly is ments are ineffective and may equipped with a spring preload adjust- damage the suspension.
  • Page 58 Instrument and control functions direction (a). To decrease the rebound Although a damping force adjust- damping force and thereby soften the er may click beyond the stated rebound damping, turn the adjusting minimum settings, such adjust- screw in direction (b). ments are ineffective and may damage the suspension.

  • Page 59: Auxiliary Dc Jack

    3. Turn the accessory off. 4. Insert the accessory plug into the sembly yourself. Take the shock absorber assembly to a Yamaha auxiliary DC jack. dealer for any service. 1. Auxiliary DC jack cap A 12-V accessory connected to the 1.

  • Page 60: Auxiliary Dc Connector

    This vehicle is equipped with an auxil- The sidestand is located on the left Yamaha dealer repair it if it does not iary DC connector. Consult your side of the frame. Raise the sidestand function properly.

  • Page 61: Ignition Circuit Cut-Off System

    Instrument and control functions EAU57952 Ignition circuit cut-off system This system prevents in-gear engine starts unless the clutch lever is pulled and the sidestand is up. Also, it will stop the running engine should the sidestand be lowered while the trans- mission is in gear.
  • Page 62 The neutral switch may not be working. 6. Move the sidestand up. The motorcycle should not be ridden until 7. Pull the clutch lever. checked by a Yamaha dealer. 8. Shift transmission into gear. 9. Move the sidestand down. Does the engine stall? The sidestand switch may not be working.

  • Page 63: For Your Safety - Pre-Operation Checks

    Failure to inspect or maintain the vehicle properly increases the possibility of an accident or equipment damage. Do not operate the vehicle if you find any problem. If a problem cannot be corrected by the procedures provided in this manual, have the vehicle inspected by a Yamaha dealer. Before using this vehicle, check the following points: Check fuel level in fuel tank.
  • Page 64 Make sure that operation is smooth. Check throttle grip free play. Throttle grip 6-15, 6-25 If necessary, have Yamaha dealer adjust throttle grip free play and lubricate ca- ble and grip housing. Make sure that operation is smooth. Control cables 6-25 Lubricate if necessary.
  • Page 65 Make sure that all nuts, bolts and screws are properly tightened. Chassis fasteners — Tighten if necessary. Instruments, lights, signals Check operation. — and switches Correct if necessary. Check operation of ignition circuit cut-off system. Sidestand switch 3-44 If system is not working correctly, have Yamaha dealer check vehicle.

  • Page 66: Operation And Important Riding Points

    To start the engine with a lean angle sensor to stop the en- understand, ask your Yamaha dealer. the transmission in gear, the sidestand gine in case of a turnover. In this EWA10272 must be up and the clutch lever pulled.

  • Page 67: Shifting

    Even with the transmission in not work as described above, have a the neutral position, do not Yamaha dealer check the vehicle. coast for long periods of time with the engine off, and do not 3. Shift the transmission into neutral.

  • Page 68: Tips For Reducing Fuel Consumption

    Yamaha dealer check the vehi- to the correct operating clearances. gine. cle. During this period, prolonged full-throt-...

  • Page 69: Parking

    Operation and important riding points EAU17214 Parking When parking, stop the engine, and then remove the key from the main switch. EWA10312 WARNING Since the engine and exhaust system can become very hot, park in a place where pedestri- ans or children are not likely to touch them and be burned.

  • Page 70: Periodic Maintenance And Adjustment

    To avoid possible burns, let your risk of injury or death during brake components cool before service or while using the vehicle. If touching them. you are not familiar with vehicle ser- vice, have a Yamaha dealer perform service.

  • Page 71: Tool Kit

    However, a torque wrench and other tools are necessary to perform certain maintenance work correctly. If you do not have the tools or experi- ence required for a particular job, have your Yamaha dealer perform it for you.

  • Page 72: Periodic Maintenance Charts

    EAU71033 Periodic maintenance charts Items marked with an asterisk should be performed by your Yamaha dealer because these items require special tools, data, and technical skills. From 50000 km (30000 mi), repeat the maintenance intervals starting from 10000 km (6000 mi).
  • Page 73 Periodic maintenance and adjustment ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) Check control system for dam- Evaporative emis- √...

  • Page 74: General Maintenance And Lubrication Chart

    (12000 mi) (18000 mi) (24000 mi) Perform dynamic inspection us- Diagnostic system √ √ √ √ √ √ ing Yamaha diagnostic tool. check Check the error codes. 2 * Air filter element Check operation. √ √ √ √ √ Clutch Adjust.
  • Page 75 Periodic maintenance and adjustment ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) Check operation and for exces- √ √ √...
  • Page 76 Periodic maintenance and adjustment ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) Check operation and replace if √ √ √...
  • Page 77 Periodic maintenance and adjustment ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) Check operation and free play. Adjust the throttle cable free play Throttle grip hous- √...

  • Page 78: Removing And Installing The Panel

    Periodic maintenance and adjustment EAU18752 Removing and installing the panel The panel shown needs to be removed to perform some of the maintenance jobs described in this chapter. Refer to this section each time the panel needs to be removed and installed. 1.

  • Page 79: Checking The Spark Plugs

    Before installing a spark plug, the checked periodically, preferably by a spark plug gap should be measured Yamaha dealer. Since heat and depos- with a wire thickness gauge and, if If a torque wrench is not available its will cause any spark plug to slowly necessary, adjusted to specification.

  • Page 80: Canister

    Periodic maintenance and adjustment EAU36112 EAU1990E Engine oil To check the engine oil level Canister 1. After warming up the engine, wait The engine oil level should be checked a few minutes for the oil to settle. regularly. In addition, the oil must be 2.
  • Page 81 5. Check the engine oil filler cap O- An oil filter wrench is available at a ring. Replace if damaged. Yamaha dealer. 5. Apply a thin coat of clean engine oil to the O-ring of the new oil filter cartridge.

  • Page 82: Coolant

    7. Install the engine oil drain bolt with NOTICE: Do not operate the ve- If genuine Yamaha coolant is not avail- a new gasket, and then tighten the able, use an ethylene glycol antifreeze hicle until you know that the en- bolt to the specified torque.
  • Page 83 Have a 1. Coolant reservoir cap Yamaha dealer change the coolant. WARNING! Never attempt to remove 4. Add coolant to the maximum level the radiator cap when the engine is mark.

  • Page 84: Air Filter Element

    Check the engine idling speed and, if Measure the throttle grip free play as maintenance and lubrication chart. necessary, have it corrected by a shown. Have a Yamaha dealer replace the air Yamaha dealer. filter element. Engine idling speed: 1100–1300 r/min 1.

  • Page 85: Valve Clearance

    225 kPa (2.25 kgf/cm², 33 psi) To prevent this from occurring, have Rear: your Yamaha dealer check and adjust Tire air pressure 250 kPa (2.50 kgf/cm², 36 psi) 2 persons: the valve clearance at regular intervals.
  • Page 86 “broken used or have only been used occasion- wall is cracked, have a Yamaha dealer in” for it to develop its optimal ally. Cracking of the tread and sidewall replace the tire immediately.

  • Page 87: Cast Wheels

    If any damage is found, have high speeds. After extensive tests, only the tires list- a Yamaha dealer replace the Brand-new tires can have a rel- ed below have been approved for this wheel. Do not attempt even the atively poor grip on certain road model by Yamaha.

  • Page 88: Adjusting The Clutch Lever Free Play

    Measure the clutch lever free play as clutch does not operate correctly, have shown. a Yamaha dealer check the internal clutch mechanism. 1. No brake lever free play There should be no free play at the 1.

  • Page 89: Brake Light Switches

    EAU36891 tem, they should only be serviced by a Front brake pads Yamaha dealer. 1. Brake pad wear indicator Each front brake pad is provided with wear indicators, which allows you to check the brake pad wear without hav- ing to disassemble the brake.

  • Page 90: Checking The Brake Fluid Level

    Rear brake EAU40262 Checking the brake fluid level Yamaha dealer replace the brake pads Before riding, check that the brake fluid as a set. is above the minimum level mark. Check the brake fluid level with the top...

  • Page 91: Changing The Brake Fluid

    Changing the brake fluid id; otherwise, the rubber seals brake system for leakage. If the brake Have a Yamaha dealer change the may deteriorate, causing leak- fluid level goes down suddenly, have a brake fluid every 2 years. In addition, age.

  • Page 92: Drive Chain Slack

    EAU63122 To adjust the drive chain slack each side of the swingarm in di- Consult a Yamaha dealer before ad- rection (a). To loosen the drive justing the drive chain slack. chain, turn the adjusting bolt on 1.

  • Page 93: Cleaning And Lubricating The Drive Chain

    Periodic maintenance and adjustment drive chain moves smoothly. EAU23026 Cleaning and lubricating the drive chain The drive chain must be cleaned and lubricated at the intervals specified in the periodic maintenance and lubrica- tion chart, otherwise it will quickly wear out, especially when riding in dusty or 1.

  • Page 94: Checking And Lubricating The Cables

    Yamaha dealer at the intervals could damage O-rings. cated if necessary. If a cable is...

  • Page 95: Checking And Lubricating The Brake And Shift Pedals

    Periodic maintenance and adjustment EAU44276 EAU23144 Recommended lubricant: Checking and lubricating the Checking and lubricating the Lithium-soap-based grease brake and shift pedals brake and clutch levers The operation of the brake and shift The operation of the brake and clutch pedals should be checked before each levers should be checked before each ride, and the pedal pivots should be lu-...

  • Page 96: Checking And Lubricating The Centerstand And Sidestand

    EWA10742 WARNING If the centerstand or sidestand does not move up and down smoothly, have a Yamaha dealer check or re- pair it. Otherwise, the centerstand or sidestand could contact the ground and distract the operator, resulting in a possible loss of control.

  • Page 97: Lubricating The Swingarm Pivots

    The swingarm pivots must be lubricat- face and hold it in an upright posi- fork does not operate smoothly, ed by a Yamaha dealer at the intervals tion. WARNING! To avoid injury, have a Yamaha dealer check or re- specified in the periodic maintenance securely support the vehicle so pair it.

  • Page 98: Checking The Steering

    If any free seat. (See page 3-34.) hub or if the wheel does not turn play can be felt, have a Yamaha This model is equipped with a VRLA smoothly, have a Yamaha dealer dealer check or repair the steer- (Valve Regulated Lead Acid) battery.
  • Page 99 To charge the battery 2. If the battery will be stored for burns. Avoid any contact with Have a Yamaha dealer charge the bat- more than two months, check it at skin, eyes or clothing and al- tery as soon as possible if it seems to...

  • Page 100: Replacing The Fuses

    Periodic maintenance and adjustment EAU63134 Replacing the fuses The fuse boxes and individual fuses are located under the rider seat (see page 3-34) and behind panel A (see page 6-9). To access fuse box 1, the main fuse, and the fuel injection system fuse, re- move the rider seat.
  • Page 101 2. Remove the blown fuse, and then check if the device operates. install a new fuse of the specified 4. If the fuse immediately blows amperage. WARNING! Do not again, have a Yamaha dealer check the electrical system. 6-32...

  • Page 102: Headlights

    If a headlight does not come on, check If the brake/tail light does not come on, the fuses and then have a Yamaha have a Yamaha dealer check it. dealer check the vehicle. When the headlights are set to low beam, one headlight will come on.

  • Page 103: Replacing A Turn Signal Light Bulb

    Periodic maintenance and adjustment EAU24205 EAU58010 Replacing a turn signal light Replacing the license plate bulb light bulb 1. Remove the turn signal light lens 1. Remove the license plate light unit by removing the screw. by removing the nuts and collars, and then remove the license plate light bulb socket (together with the bulb) by pulling it out.

  • Page 104: Troubleshooting

    3. Insert a new bulb into the socket. self. However, should your motorcycle 4. Install the socket (together with require any repair, take it to a Yamaha the bulb) by pushing it in, and then dealer, whose skilled technicians have...

  • Page 105: Troubleshooting Charts

    Remove the spark plugs and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the compression. 4. Compression The engine does not start. There is compression.
  • Page 106 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended cool- ant as soon as possible.

  • Page 107: Motorcycle Care And Storage

    Be ECA10773 even if high-quality components are NOTICE sure to consult a Yamaha dealer for used. A rusty exhaust pipe may go un- advice on what products to use be- Avoid using strong acidic wheel noticed on a car, however, it detracts fore cleaning the vehicle.
  • Page 108 For additional hoses and vents. Since sea salt or salt sprayed on roads cleaning, use Yamaha Windshield For motorcycles equipped with during winter are extremely corrosive Cleaner or another high-quality wind- a windshield: Do not use strong in combination with water, carry out shield cleaner.
  • Page 109 WARNING After cleaning Contaminants on the brakes or tires 1. Dry the motorcycle with a chamois Consult a Yamaha dealer for ad- can cause loss of control. or an absorbing cloth. vice on what products to use. Make sure that there is no oil or 2.

  • Page 110: Storage

    Motorcycle care and storage 2. Fill up the fuel tank and add fuel e. Remove the spark plug caps EAU26183 Storage stabilizer (if available) to prevent from the spark plugs, and then the fuel tank from rusting and the install the spark plugs and the Short-term fuel from deteriorating.
  • Page 111 Motorcycle care and storage Make any necessary repairs before storing the motorcycle.

  • Page 112: Specifications

    Specifications Dimensions Compression ratio: Fuel reserve amount: Overall length: 11.5 : 1 2.6 L (0.69 US gal, 0.57 Imp.gal) Starting system: 2160 mm (85.0 in) Fuel injection: Electric starter Overall width: Throttle body: 850 mm (33.5 in) Lubrication system: ID mark: Wet sump Overall height: B1J1 00...
  • Page 113 Specifications 6th: Rear: Wheel travel: 1.037 (28/27) 250 kPa (2.50 kgf/cm², 36 psi) 137 mm (5.4 in) 2 persons: Chassis: Rear suspension: Front: Frame type: Type: 250 kPa (2.50 kgf/cm², 36 psi) Diamond Swingarm (link suspension) Rear: Caster angle: Spring: 290 kPa (2.90 kgf/cm², 42 psi) 24.0 °...
  • Page 114 Specifications License plate light: Brake light fuse: 5.0 W 1.0 A Meter lighting: Signaling system fuse: 7.5 A Neutral indicator light: Ignition fuse: 15.0 A High beam indicator light: Parking lighting fuse: 7.5 A Turn signal indicator light: Radiator fan motor fuse: 15.0 A Engine oil and Coolant warning light: Fuel injection system fuse:...

  • Page 115: Consumer Information

    These identification numbers are needed when registering the vehicle with the authorities in your area and when ordering spare parts from a Yamaha dealer. VEHICLE IDENTIFICATION NUMBER: 1. Vehicle identification number 1. Engine serial number The vehicle identification number is The engine serial number is stamped stamped into the steering head pipe.

  • Page 116: Diagnostic Connector

    Vehicle status and engine perfor- shown. mance data Fuel-injection and emission-relat- ed data Yamaha will not disclose this data to a third party except: With the consent of the vehicle owner Where obligated by law For use by Yamaha in litigation...
  • Page 117 Index Helmet holder ........3-37 High beam indicator light ....... 3-5 ABS............3-27 Data recording, vehicle ......9-2 ABS warning light ........3-6 Diagnostic connector ......9-2 Horn switch ..........3-4 Air filter element ........6-15 Dimmer/Pass switch ......3-4 Auxiliary DC connector ......3-44 Display, main screen ......
  • Page 118 Index Shift indicator light ........3-6 Shifting ............5-2 Wheel bearings, checking ....6-29 Wheels..........6-18 Shift pedal..........3-26 Windshield ..........3-38 Shock absorber assembly, adjusting..3-41 Sidestand ..........3-44 Spark plugs, checking......6-10 Specifications ......... 8-1 Starting the engine ......... 5-1 Steering, checking........ 6-29 Stop/Run/Start switch ......
