Application for programming
FA01251-EN
radio and Wi-Fi devices
QBESetUp
PROGRAMMING MANUAL
EN English

Advertisement

loading
Need help?

Need help?

Do you have a question about the QBESetUp and is the answer not in the manual?

Questions and answers

Related Manuals for CAME QBESetUp

Summary of Contents for CAME QBESetUp

  • Page 1 Application for programming FA01251-EN radio and Wi-Fi devices QBESetUp PROGRAMMING MANUAL EN English...
  • Page 2 Single network configuration Wi-Fi Single network configuration Wi-Fi 1 - Use the "QBESetUp" application to configure the system. 2 - Use the "QBE User" application to access the system and configure the Wi-Fi network. 3 - Register the device to CAMEConnect.
  • Page 3 APP USE Launch the application. Main Homepage commands 1 - It allows connection to an available QBE (ON- LINE) 2 - It opens an installation previously created and saved on the device (OFF-LINE) 3 - It allows access to the configuration pages of a new system without necessarily being connected to the network (OFF-LINE).

  • Page 4: Creating A New System

    Creating a new system Work area description 1 - It saves the system 2 - It opens a previously saved system structure 3 - It allows access to the system map view config- uration 4 - It filters the system structure view 5 - It allows to share the system structure 6 - It shows the icon representing the QBE in the middle of the work area...
  • Page 5 Accessing the QBE functions menu Functions menu commands Press and hold the icon representing QBE until the function menu appears. 1 - Name assigned to the device. 2 - It adds a device to the system structure 3 - It allows access the to the device's configuration options.
  • Page 6 Automatic search for connected devices 3 - It performs a network scan and compiles a list of detected devices Press the "+" button to insert the devices in the structure. Manual search for connected devices 4 - Press the button to put the QBE device in standby mode Press the "SERVICE"...
  • Page 7 Adding home automation modules to the system structure (off-line mode) 1 - It adds a device to the system structure. Select the type of devices required. Select the type of device to be added to the system structure.
  • Page 8 Accessing the functions menu of a connected module Press and hold the icon representing the connected module until the function menu appears. Functions menu commands 1 - It allows to add inputs or outputs to the module 2 - It allows to configure the module general parameters 3 - It allows to manage the connections to the module inputs and outputs...
  • Page 9 Creating connections between the module inputs and outputs Press and hold the icon representing the output 1 - Press the button and choose, among those avail- able, the input to be connected to the output. The connection between the module inputs and outputs can also be made by dragging the button icon (input) above the light icon (exit) that it has to command.
  • Page 10 Configuring the home automation module general parameters Press and hold the icon representing the connected module until the function menu appears. 1 - Press the button to access the module general parameters configuration options. Configuration window description 2 - Touch the area to manually enter the module serial number.
  • Page 11 Configuring the inputs connected to an output 5 - Touch the area to access the list of available functions for each input connected to the output 6 - No function 7 - Function [DIRECT] (monostable) As long as the input contact remains closed (ON), the relay remains energised (ON).
  • Page 12 Adding a timer to an output From the functions menu of the module select the but- ton that allows to add inputs or outputs to the module. 1 - Choose the output to which add the timer among those available 2 - Add a timer Assigning the same timer to multiple outputs From the functions menu of the module select the...
  • Page 13 Adding a generic relay If there is a need to drive a device other than a light, it is possible to use a generic relay. From the functions menu of the module select the but- ton that allows to add inputs or outputs to the module. 1 - Press the button that allows to add an output.
  • Page 14 Configuration of OH/2O16WL home automation devices for shutter control From the QBE functions menu, add a home automa- tion module with inputs that will be used to control the shutters. 1 - Add the shutters home automation module to the structure.
  • Page 15 4 - Choose one of the shutter statuses. The inputs to which it is possible to associate the shutter statuses are highlighted. 5 - Choose one of the available inputs to which connect the shutter status. Proceed in the same way for all roller shutter statuses. Access the shutter control module functions menu.
  • Page 16 Configuration window description 7 - Touch the area to manually enter the module serial number. 8 - Touch the area to edit the module's name. 9 - Press the button to set the times for the opening/ closing actions that the inputs connected to the output must respect.
  • Page 17 Configuration of heating control devices From the QBE functions menu, add a home automa- tion module with outputs that will be used to follow the commands sent by the thermostat. 1 - Add the heating control device to the structure. Access the function menu of the home automation module to be associated with the heating control device.
  • Page 18 4 - Choose which event should activate the output. If the same output has to be activated by more events (for example associated with the winter valve, to the summer valve), repeat the operation described above. Association and configuration of post-mounted devices The operations illustrated below must be car- ried out after assigning the channel and the upper and lower limits to each existing post-mounted...
  • Page 19 When required, press the STOP button on the remote control to allow the device to acquire the desired commands/channels. At the end of the acquisition procedure it is necessary to program all the acquired channels and post-mount- ed devices.
  • Page 20 4 - Press the button that adds a device to the system structure 5 - Choose the operators to be added to the system structure and/or the available inputs/outputs. The RSLV001 module remotely manages up to 3 CAME operators and is equipped with 2 digital inputs, 2 relay outputs.
  • Page 21 7 - Enter the address (CRP) assigned to the operator to be controlled. 8 - Choose the type of CAME operator to be con- trolled. 9 - Indicate the serial number of the RSLV001 mod- ule shown on the label on the back of the device.
  • Page 22 System map view configuration Once the system structure has been created and all the elements that compose it have been added, it is possi- ble to configure a map view of the system. The configuration application proposes a series of "example" images to be associated with the various areas of the house.
  • Page 23 Drag one or more desired elements into the available maps, taking them from the list. Removing a device from a map 1 - Drag the icon that represents the device to be removed into the red area.
  • Page 24 Pertinent Regulations. CAME SpA, the manufacturer, declares that the products described in this manual conforms to Directive 2014/53/EU. The complete wording of the EU declaration of conformity is available at the following Internet address: www.came.com Decommissioning and disposal. Dispose of the packaging and the device at the end of its life cycle responsibly, in compliance with the laws in force in the country where the product is used.
