One Zone Connections Location Of Screw Terminals, Option Switches And Music Volume Control - Valcom V-9970 User Manual

Dipswitches (shown with Default Settings)
J1
12V
IN
VP-412A
Power
Supply
OR
Up to 150 Valcom
-24VDC
+ Amplified Speakers
Power
Supply
OPTION SWITCHES AND MUSIC VOLUME CONTROL
(Refer to Chart for actual times)
OFF 8 7 6 5 4 3 2 1
ON
R13
24V Option
(If used)
COM SIG
- +
COM 24V
PAGE OUT MUSIC IN
Line Level
Music
Source
FIGURE 1 - ONE ZONE CONNECTIONS
LOCATION OF SCREW TERMINALS,
5
SW1
SW2
LED designates
page in process
Power On LED
Music
Volume
J2
Connection made
USER
via an RJ11C jack
CONTACT
Incoming Telephone
Line or PABX Station
