Kübler CODIX 52P Operating Instructions

Operating instructions
Electronic po si ti on indicator
and electronic frequency meter
CODIX 52P
1.1 Safety instructions and warnings
Only use this display
– in a way according to its intended
!
purpose
– if its technical condition is perfect
– adhering to the operating
instructions and the general
safety instructions.
1.2 General safety instructions
1. Before carrying out any installation or mainten-
ance work, make sure that the power supply of
the digital display is switched off.
2. Only use this digital display in a way according
to its intended purpose: If its technical condition
is perfect.Adhering to the operating in structions
and the general safety instructions.
3. Adhere to country or user specific regulations.
4. The digital display is not intended for use in
areas with risks of explosion and in the branch-
es excluded by the standard EN 61010 Part 1.
5. The digital display should only operate if it has
been correctly mounted in a panel, in accord-
ance with the chapter "Technical features".
1.3 Use according to the intended purpose
The digital display may be used only as a
panel-mounted device. Applications of this product
may be found in industrial processes and controls,
in manufacturing lines for the metal, wood, plastics,
paper, glass, textile and other processing indus-
tries. Over-voltages at the terminals of the digital
display must be kept within the limits in Category II.
If the digital display is used to monitor machines
or processes in which, in case of a failure of the
device or an error made by the operator, there
might be risks of damaging the machine or caus-
ing accidents to the operators, it is your respons-
ibility to take appropriate safety measures.
1
1.4 Description
• 6-digit position indicator and frequency meter
• Red LED display, character height 8 mm
• Display range -199 999...999 999
• Leading zeros suppression
• Programming via two setting keys
on the front side
• During programming, the display guides the
user with text prompts
• Position indicator operating modes
– Count input INP A + count direction input
INP B(Cnt.Dir)
– Differential count INP A - INP B (up.dn)
– Totalising INP A + INP B (up.up)
– Count Up/Down INP A 90° INP B x 1 (quad)
– Count Up/Down INP A 90° INP B x 2 (quad2)
– Count Up/Down INP A 90° INP B x 4 (quad4)
• Frequency meter
– Frequency input INP C
– Value conversion and display in 1/s or 1/min
2. Inputs
INP A
Dynamic count input.
INP B
Dynamic count input.
INP C
Dynamic frequency input.
3. Selection of the displayed value
Pressing the right key allows switching between
the totaliser display and the frequency meter
display. Press the key briefly to display for 2 sec-
onds the current function ("count" or "tAcho"). If,
during this period of time, the right key is pressed
a second time, the device switches to the current
function and displays a confirmation ("count" or
"tAcho") for 2 seconds. Then, the value of the
selected function is displayed.
