Danfoss 088U0200 Manual page 7

Instruction CF-MC Master Controller
5. Installation Procedure (Sequential)
Important Note: Complete all the installations on the Master Controller
described below before connecting to a 230V power supply !
5.1 24V Actuators
• Connect the two actuator wires to an output ( g. 8)
• Fix the cable
Round cable ( g. 9)
Squared/ at cable ( g. 10)
Note: If NC (normally closed) actuators are installed for ON/OFF regula-
tion, no further actuator output con guration is needed (see 6.1) !
VI.UH.K1.52
Produced by Danfoss Floor Heating Hydronics 08.2005
