Danfoss 088U0200 Manual page 10

Instruction CF-MC Master Controller
5.4 Input for Heating & Cooling
• Connect the two wires from an external switch (ON/OFF) to the two
terminals for the heating and cooling input. ( g. 15)
When this switch is closed (ON) the system will switch from heating to
cooling mode.
• Fix the cable. ( g. 16)
Note #1: When the system is in cooling mode the actuator output will be
activated (ON when NC actuators / OFF when NO actuators) when the
temperature in a room exceeds the set point.
Note #2: When the system is in cooling mode an independent dew-point
alarm function should be installed.
Danfoss o ers the below listed components (see example g. 17)
EDA-24V: Electronic dew-point alarm - 088H3001
EDA-S: Dew-point sensor - 088H3011
TWA-A: 24V-NO actuator – 088H3111
RA-C 20: Danfoss cooling valve* - 013G3096
• This valve must be dimensioned according to the placement on the
primary side if the application structure in the example is chosen!
10
VI.UH.K1.52
Produced by Danfoss Floor Heating Hydronics 08.2005
