• Residual risks can be minimised if the "Safety In-
structions" and the "Intended Use" together with the
operating manual as a whole are observed.
• Avoid accidental starting of the product: the oper-
ating button may not be pressed when inserting
the plug in a socket. Use the tool attachment that
is recommended in this operating manual. This is
how to ensure that your product provides optimum
performance.
• Keep your hands away from the working area when
the product is in operation.
7.

Technical data

Dimensions L x W x H
Table size L x W
Table height
Table width extension
dimensions L x W
Height adjustment spindle
Reduction pieces
Spindle speed
Max. cutter Ø
Weight approx.
Engine
Rated input
Subject to technical changes!
Noise and vibration
m Warning: Noise can have serious effects on your
health. If the machine noise exceeds 85 dB, please
wear suitable hearing protection.
Information about noise level measured in accord-
ance with EN 61029
Noise data
Sound power level L
WA
Sound pressure level L
pA
Uncertainty K
wa/pA

8. Unpacking

• Open the packaging and carefully remove the product.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
30 | GB
1030 x 475 x 530 mm
610 x 365 mm
315 mm
210 x 365 mm
0 - 40 mm
32 / 47 / 55 / 75 mm
11,500 - 24,000 rpm
80 mm
21 kg
230 - 240 V~ / 50 Hz
1500 W
106 dB
93 dB
3 dB
www.scheppach.com
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport
damage. In the event of complaints the carrier must
be informed immediately. Later claims will not be
recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the
operating manual before using for the first time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Spare parts
can be obtained from your specialist dealer.
• When ordering please provide our article number as
well as type and year of manufacture for the product.
m WARNING!
The product and the packaging material are not
children's toys! Do not let children play with plas-
tic bags, films or small parts! There is a danger of
choking or suffocating!
9.

Layout

m Warning!
Always remove the mains plug before carrying out ad-
justments on the product.
Tool required:
(Included in the scope of delivery)
- Open-ended spanner size 19 (24)
- Open-ended spanner size 24 (25)
- Allen key, 4 mm (26)
- Allen key, 5 mm (27)
(Not included in the scope of delivery)
- Open-ended spanner / socket spanner size 8
- Open-ended spanner / socket spanner size 10
- Open-ended spanner / socket spanner size 13
- Phillips screwdriver
9.1 Fastening the machine
For use, it is recommended to fix the machine on a
workbench by means of the four holes.
1. The mounting surface must be pre-drilled, taking
into account the spacing of the two mounting holes
in the frame.
2. Each fixing point must be tightened with screws
(not included in the scope of delivery).
3. The screws must be sufficiently long: Take into ac-
count the thickness of the work surface on which
the product is to be mounted.
